Visual Comfort Arn5520 Valencia Extra Large Three Light Chandelier Instruction Manual

ARN5520 Valencia Extra Large Three Light Chandelier

Product Information: Valencia Extra Large Three Light
Chandelier

Item Number: ARN5520

This product is a Valencia Extra Large Three Light Chandelier.
It is designed to be installed in accordance with applicable local
installation codes by a person familiar with the construction and
operation of light fixtures. Please inspect the item and its
contents carefully before installation. If any damage or defect is
found, do not install and retain all packaging material until
installation is complete and approved.

Tools Required (Not Included):

• Phillips Screwdriver
• Slotted Screwdriver
• Wire Strippers
• Slip-joint Pliers
• Wire Cutters

Product Usage Instructions:

1. Carefully remove all parts from the box and place them on a
   clean, soft surface.
2. Remove the mounting plate (B) from the canopy (I) by removing
   the collar ring (J).
3. Install the mounting plate (B) to the junction box and secure
   it with the provided mounting screws (F).
4. Install the fixture arms (M, N, O) to the fixture hub (X) and
   secure them with the lock washer (Y) and screws (Z) using the
   provided wrench (E). Refer to diagram 1 & 2 for guidance.
5. Connect the arm neutral wires (black) to the fixture neutral
   wire (black) and secure them using the wire nut (A).
6. Connect the hot wires (red) to the fixture hot wire (red) and
   secure them using the wire nut (A). CAUTION: Do not reverse the hot
   and neutral connections.
7. Install the metal plate (T) to the hub (X) and secure it with
   the hex nut (U).
8. Install the cap (V) to the hub (X) and secure it with the final
   (W).
9. Feed the electrical wires through the bottom rod (L) and thread
   them to the connector on top of the hub (X). Repeat this step for
   the middle rod (K), connecting it to the bottom rod (L).
10. Continue feeding the wires through the collar ring (J), canopy
    (I), and top rod (H).
11. Holding the fixture upright, slide the collar ring (J) and
    canopy (I) down the bottom rods (L) and rest them on the fixture.
    Then connect the top rod (H) to the middle rod (K). NOTE: Slide
    components down slowly to avoid damages.
12. Hang the fixture fan mount (G) to the center of the mounting
    plate (B) and secure it with the set screw (C) using the provided
    screwdriver (D). Refer to diagram 3 for guidance.
13. Cut excess wires, ensuring that there is enough length to reach
    the junction box. Separate the wires and strip insulation on each
    end by 5/8 inch.
14. Connect the supply ground wire (usually green or bare copper)
    around the green grounding screw. Tighten it securely. NOTE: It is
    imperative that the fixture is grounded.
15. Connect the fixture neutral wire (black) to the driver output
    wire (black) using the wire nut (A).
16. Connect the fixture hot wire (red) to the driver output wire
    (red) using the wire nut (A). CAUTION: Do not reverse the hot and
    neutral connections.
17. Connect the driver input neutral wire (white) to the supply
    neutral wire (usually white) using the wire nut (A).

ASSEMBLY INSTRUCTIONS
DC
N O
M Diagram 2
L
N MX

B FA
G H I
J

Valencia Extra Large Three Light Chandelier
Item # ARN5520
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.

TOOLS REQUIRED (NOT INCLUDED):

Phillips Screwdriver

Slotted Screwdriver

Wire Strippers

Slip-joint pliers

Wire Cutters

1. Carefully remove all parts from the box. Place on a clean, soft surface.

K

2. Remove mounting plate (B) from canopy (I) by removing collar ring (J).

3. Install mounting plate (B) to the junction box and secure with

mounting screws (F).

4. Install fixture arms (M & N & O) to fixture hub (X) and secure

X

with lock washer (Y) and screws (Z) using provided wrench (E).

See diagram 1 & 2.

Y Z E

5. Connect arm neutral wires (black) to fixture neutral wire (black) and secure using wire nut (A).
6. Connect hot wires (red) to fixture hot wire (red) and secure

Diagram 1

using wire nut (A). CAUTION: Do not reverse the hot and neutral connections.

7. Install metal plate (T) to hub (X) and secure with hex nut (U). O

P

8. Install cap (V) to hub (X) and secure with final (W).

A

Q

9. Feed electrical wires through bottom rod (L) and thread to connector

on top of hub (X). Repeat for middle rod (K), connecting to

T U

bottom rod (L).

10. Continue feeding wires through collar ring (J), canopy (I), and top

rod (H).

V W

11. Holding fixture upright, slide collar ring (J) and canopy (I) down bottom

S (Packaged separately)

rods (L) and rest on fixture. Then connect top rod (H) to middle

rod (K).

NOTE: Slide components down slowly to avoid damages.

M

LI ST ED

US

ASSEMBLY INSTRUCTIONS
DC Diagram 4
DC Diagram 3 L

B FA
G H I J
K

N MX
A T U
V W

Valencia Extra Large Three Light Chandelier
Item # ARN5520
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.

12. Hang fixture fan mount (G) to the center of mounting plate (B) and

secure with set screw (C) using provided screwdriver (D).

See diagram 3.

13. Cut excess wires, being sure to leave enough to reach the junction

box. Separate wires, and strip insulation on each 5/8″.

14. Connect supply ground wire (usually green or bare copper) around the

green grounding screw (see diagram 4). Tighten.

NOTE: It is imperative that the fixture is grounded.

15. Connect fixture neutral wire (black) to driver output wire (black)

using wire nut (A).

16. Connect fixture hot wire (red) to driver output wire (red) using wire

nut (A).

CAUTION: Do not reverse the hot and neutral connections.

17. Connect driver input neutral wire (white) to the supply neutral wire

(usually white) using wire nut (A).

18. Connect driver input hot wire (black) to the supply hot wire (usually

black) using wire nut (A).

O

CAUTION: Do not reverse the hot and neutral connections.

P

19. Make sure all wire connections are tight, then carefully tuck into the

Q

junction box.

20. Insert driver into the center of mounting plate (B).

21. Install canopy (I) to mounting plate (B) and secure with collar ring (J).

22. Thread rods (P) to fixture.

S (Packaged separately)

M

LI ST ED

US

ASSEMBLY INSTRUCTIONS
DC Diagram 4
DC Diagram 3 L

B FA
G H I J
K

N MX
A T U
V W

Valencia Extra Large Three Light Chandelier Item # ARN5520
NOTICE: This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
23. Remove thumbscrews (Q) from rods (P), then line up holes from bowl (S) to rods (P) and secure with thumbscrews (Q). Repeat with remaining parts.
Care Instructions: Clean only with a soft dry cloth or feather duster. Do not use abrasive or chemical agents.
