Toolots 3-point Disc Harrow Instructions

3-Point Disc Harrow

Product Information: 3-Point Disc Harrow

The 3-Point Disc Harrow is a farm machinery used for soil
preparation, seedbed preparation, and weed control. It is designed
to be attached to the 3-point hitch of a tractor and pulled behind
it. The harrow has a series of concave metal discs that are mounted
on a frame and rotated to cut, break, and mix soil. The machine is
durable, easy to use, and requires regular maintenance to ensure
optimal performance.

Product Usage Instructions

Before using the 3-Point Disc Harrow, it is important to read
and understand all the safety precautions and instructions provided
in the user manual. Below are some guidelines to follow:

Assembly

1. Select a clean area for assembly that is free of debris.
2. Do not lift heavy parts or assemblies. Use crane, jack, tackle,
   fork trucks, or other mechanical devices.
3. Preview the assembly instructions in the operator’s manual
   before proceeding further.
4. If the assembly instructions call for parts or assemblies to be
   blocked up, use only blocks material that is in good condition and
   is capable of handling the weight of the assembly to be blocked.
   Also, ensure that the blocking material is on a clean, dry
   surface.
5. Never put hands or any part of the body under blocked up
   assemblies if possible.
6. After completing assembly, thoroughly inspect the machine to be
   sure that all nuts, bolts, hydraulic fittings or any other fastened
   assemblies have been thoroughly tightened.

Equipment Safety Guidelines

1. Never use alcoholic beverages or drugs that can hinder
   alertness or coordination while operating this equipment. Consult
   your doctor about operating this machine while taking prescription
   medications.
2. Review the safety instructions with all users annually.
3. This equipment is dangerous to children and persons unfamiliar
   with its operation. The operator should be a responsible adult
   familiar with farm machinery and trained in this equipment’s
   operations. Do not allow persons to operate or assemble this unit
   until they have read this manual and have developed a thorough
   understanding of the safety precautions and of how it works.
4. Do not modify the equipment in any way. Unauthorized
   modification may impair the function and could affect the life of
   the equipment.

Operational Safety

1. The use of this equipment is subject to certain hazards that
   cannot be protected against by mechanical means or product design.
   All operators of this equipment must read and understand this
   entire manual, paying particular attention to operating, prior to
   using. If there is something in this manual you do not understand,
   ask your supervisor, or your dealer, to explain it to you.
2. Personal protection equipment including hard hat, safety
   glasses, safety shoes, and gloves are recommended during
   assembly.
3. Never permit any person other than the operator to ride or
   board the tractor or implement at any time. ALLOW NO RIDERS!
4. Always drive slowly-especially around turns. An unstable
   tractor could steer badly and possibly tip over, causing injury or
   death.
5. Most accidents occur because of neglect or carelessness. Keep
   all helpers and bystanders at a safe distance.

Maintenance Safety

1. Keep all persons away from operator control area while
   performing adjustments, service, or maintenance.

By following these guidelines, you can ensure safe and efficient
use of the 3-Point Disc Harrow. Regular maintenance and proper use
are essential for the longevity of the machine.

The Instruction of the 3-Point Disc Harrow
Please Read This Manual BEFORE Using This Tool

CAUTION
THE FOLLOWING SAFETY PRECAUTIONS SHOULD BE THOROUGHLY UNDERSTOOD BEFORE ATTEMPTING TO
BEGIN ASSEMBLING THIS MACHINE
1. Select an area for assembly that is clean and free of any debris which might cause persons working on the assembly to trip.
2. Do not lift heavy parts or assemblies. Use crane, jack, tackle, fork trucks or other mechanical devices.
3. Preview the assembly instructions in your operator’s manual before proceeding further.
4. If the assembly instructions call for parts or assemblies to be blocked up, use only blocks material that is good condition and is capable of handing the weight of the assembly to be blocked. Also insure that the blocking material is on a clean, dry surface.
5. Never put hands, or any part of body, under blocked up assemblies if at all possible.
6. After completing assembly, thoroughly inspect the machine to be sure that all nuts, bolts, hydraulic fittings or any other fastened assemblies have been thoroughly tightened.
7. Before operating the machine, thoroughly read the operation section of your operator’s manual.
8. Before operating, read the machine section of your operator’s manual to be sure that any parts requiring lubrication, such as gearbox, to avoid any possible damage.
9. Before operating equipment ­ if you have any questions regarding the proper assembly or operation, contact you dealer or representative.

EQUIPMENT SAFETY GUIDELINES
1. Never use alcoholic beverages or drugs which can hinder alertness or coordination while operating this equipment. Consult your doctor about operating this machine while taking prescription medications.
2. Review the safety instructions with all users annually.
3. This equipment is dangerous to children and persons unfamiliar with its operation. The operator should be a responsible adult familiar with farm machinery and trained in this equipment’s operations. Do not allow persons to operate or assemble this unit until they have read this manual and have developed a thorough understanding of the safety precautions and of how works.
4. Do not modify the equipment in any way. Unauthorized modification may impair the function and could affect the life of equipment.
OPERATIONAL SAFETY
1. The use of this equipment is subject to certain hazards which cannot be protected against by mechanical means or product design. All operators of this equipment must read and understand this entire manual, paying particular attention to operating, prior to using. If there is something in this manual you do not understand, ask your supervisor, or your dealer, to explain it to you.
2. Personal protection equipment including hard hat, safety glasses, safety shoes, and gloves are recommended during assembly.
3. Never permit any person other than the operator to ride or board the tractor or implement at any time. ALLOW NO RIDERS!
4. Always drive slowly-especially around turns. An unstable tractor could steer badly and possibly tip over, causing injury or death.
5. Most accidents occur because of neglect or carelessness. Keep all helpers and bystanders at a safe distance.

MAINTENANCE SAFETY
1. Keep all persons away from operator control area while performing adjustments, service, or maintenance.
2. Periodically tighten all bolts, nuts and screws and check that all cotter pins are properly installed to ensure unit is in a safe condition.
3. Never use your hands to locate a hydraulic leak on attachments. Use a small piece of cardboard or wood.
4. Never replace hex bolts with less than grade five bolts unless otherwise specified. Refer to bolt torque chart for head identification marking.
STORAGE SAFETY
1. Store the unit in an area away from human activity. Do not permit children to play on or around the stored unit.
2. Make sure all parked machines are on a hard, level surface and engage all safety devices.
3. If blocking is used, make sure it is solid and secure before leaving area.
ALWAYS OBEY ALL SAFETY RULES! ALWAYS BE CAREFUL!

Index
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25

Parts List
Description
Disc Harrow Frame Bolt M16×50 Lock Nut M16 A-Frame Brace Spacer A Frame Bolt M16×100 Lift Pin Flat Washer 22
Spring Washer 22 Nut M22
Disc Depth Bracket Bolt M12×90 Flat Washer 12 Lock Nut M12
Hub Mounting Body Grease Fitting Bolt M12×140 Nut M24
Spring Washer 24 Inner Hub End Disc Hub Axle Outer Hub End Axle Shaft

Quantity
1 1 2 1 2 2 1 2 2 2 2 8 16 32 32 8 16 16 4 4 4 16 12 4 4
