Wellfor Ebc3630lr11 Led Lighted Medicine Cabinet Instruction Manual

EBC3630LR11 LED Lighted Medicine Cabinet

Product Information: LED Lighted Medicine Cabinet

The LED Lighted Medicine Cabinet is a wall-mounted cabinet
designed for indoor use only. It comes with a Z-Bar, Z-Hook, Layer
Board Supporting X4, Matching Screws x2 for spare, Side Panels x2,
Wire Caps x3, Anchor x7, Mirror Panel x2, Round Head Screw x5, Side
Panel Lids x4, and Matching Screws x10. The cabinet has glass
shelves that can be inserted between the layer board clips. The
doors and cabinet are separately packed to ensure safe
transportation.

Warnings and Safety Instructions:

• Before installing the LED Medicine Cabinet fixture, carefully
  read through the instruction sheet and refer back to it during
  installation to ensure safe and correct installation.
• All fittings must be installed in accordance with current IEE
  wiring regulations. If in doubt, consult a qualified
  electrician.
• Switch off the electrical supply at the main circuit board
  BEFORE installation and maintenance.
• This product should be positioned well away from curtains and
  fabrics.
• Never cover the mirror.
• Regularly check the cord, the transformer, and all other parts
  for damage. If any part is damaged, the product should not be
  used.

Installation Instructions:

Cabinet Installation Instructions for Hanging Walls:

Note: The doors and cabinet are separately packed. For easy
installation, it is recommended to install the cabinet
first.

1. Verify minimum clearances.
2. Secure the bar with round-head screws.
3. Align the slots inside of the side panels and cabinet.
4. Press down the side panels until they are clamped tightly with
   the cabinet.
5. For hanging walls version, follow STEP 5 to STEP 7 to install
   the side panels. For embedded installation, there is no need to
   install the side boards.
6. Insert the glass shelves between the layer board clips.

Cabinet Embedded Installation Instructions:

1. Determine the size of the opening.
2. Follow the instructions for assembling the doors and cabinet.
   Insert the hinges to the base, then connect the doors with the
   cabinet.

Installation and Operating Manual
W36”xH30” For easy and safe installation, please refer to the following:
Read all instructions thoroughly before installing the enclosed product. Read and take note of all safety, care and maintenance information.
PLEASE KEEP THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE DURING PRODUCT OPERATION AND MAINTENANCE.

INSTALLATION INSTRUCTIONS

LED Lighted Medicine Cabinet

WARNING AND SAFETY INSTRUCTIONS
Before installing your LED Medicine Cabinet fixture,please make sure that you carefully read through this instruction sheet, refer back to them during installation to ensure your product is fitted safely and correctly. Keep these instructions for future use.
WARNING Risk of Fire and Electric Shock
All fittings must be installed in accordance with current IEE wiring regulations. If in doubt, consult a qualified electrician. Switch off the electrical supply at the main circuit board BEFORE installation and maintenance. Suitable for indoor use only. This product should be positioned well away from curtains and fabrics. Never cover the mirror.
Regularly check the cord, the transformer and all other parts for damage, if any part is damaged the product should not be used.
INSTALLATION SAFETY
Inspect the product immediately upon receipt for any possible damage during transportation or missing parts. Handle the product with care and protect against knocks to all sides and edges of the glass. Ensure there are no hidden pipes or cables in the wall before drilling. Wear suitable eye protection when drilling. Take care if drilling on tiled surfaces in case the drill slips.
CAUTION
The light source of this product is non-changeable light diodes (LED). Do not disassemble the product, as the light diodes can cause damage to the eyes. NOTE:The important safeguards and instructions that appear in this manual are not meant to cover all possible conditions and situations that may occur. It must be understood that common sense, caution and care are factors that can’t be built into any product. These factors must be supplied by the person(s) caring for and operating the fixture. Do not install this fixture in hazardous locations.

REQUIRTOOLSED

LED Lighted Medicine Cabinet

PARTS SUPPLIED

Z-Bar x1

Z-Hook x1

Layer board supportingX4

Matching screws x2 for spare

Side panels x 2

Wire caps x3

Anchor x7

Mirror panel x2

Round head screw x5

Side panel lids x4 , Matching screws x10

LED Lighted Medicine Cabinet The doors and cabinet are separately packed,considering the huge weight, we suggest installing the cabinet first.
Cabinet installation Instructions for Hanging Walls
Verify minimum clearances
STEP 1
STEP 2

LED Lighted Medicine Cabinet Cabinet installation Instructions for Hanging Walls
Secure the bar with round-head screws

STEP 3

STEP 4

Align the slots inside of the side panels and cabinet.

Press down the side panels until they are clamped tightly with the cabinet.

STEP 5
The side panels and cabinets are individually packaged , you need follow the STEP 5 to STEP 7 to install the side panels for hanging walls version,for embedded installation no need install the side boards.

LED Lighted Medicine Cabinet Cabinet installation Instructions for Hanging Walls

STEP 7

STEP 8

LED Lighted Medicine Cabinet Cabinet installation Instructions for Hanging Walls
Insert the glass shelves between the layer board clips.

Cabinet embedded Installation Instructions
Determine the size of the opening

LED Lighted Medicine Cabinet

STEP 1

STEP 2

STEP 3

SSTTEEPP 44

*All diagrams are for reference only.All model dimensions and proportion sposition will vary.

LED Lighted Medicine Cabinet
Instructions for assembling the doors and cabinet -Insert the hings to the base ,then connect the doors with the cabinet

-Adjust corresponding screws on the hinge to align the doors, ensure that gaps are even and the doors open and close smoothly

-Insert the wire on the door into the terminal on the cabinet and tighten the screw

.

.

.

LED Lighted Medicine Cabinet
Manual to turn on/off light,dimming,CCT changing with touch switch
Short -touch the button to turn on/off the mirror. Adjusting color temperatures (CCT) between warm white and cool
white by long -touching the button for seconds. Finish setting by withdrawing your finger when the color reaches the
one you need. Optional to be wired to wall switch by ON/OFF memory function. Short-touch the button to turn on/off the mirror. Long touching the button to adjust the brightness (Dimming). Finish setting by withdrawing your finger when the brightness
reaches the one you need.
Mirror begins to be warm and defog after pressing the defogger button. Press again to quit the anti -fog function. Note: The defogger will stop automatically after 60
minutes of continuous operation to prevent any damage caused by prolonged high temperature.

LED Lighted Medicine Cabinet
Manual to setting clock with touch switch Choose and set the clock and temperature mode -Turn off the light. -Long-touch button 2 to choose and set the mode when it flash. There are two clock and temperature modes to choose. A: 12C/12F: Fahrenheit (F) and 12 hours B: 24C/24F: Celsius (C) and 24 hours The default mode is 12C/12F. Setting the clock -Turn off the light to set the clock. -Long touch button 1 for seconds,the Hour will flash, then short-touch button1 and 2 to set Hour. -Wait for seconds after setting up the Hour,then it will automatically switch to the Minute flash. -Short-touch button 1and 2 to set up the Minute. -Wait seconds after you finish the time setting,the time will be saved automatically. Turn on/off the touch switches’ blue background ligth -In default mode the touch switches is with blue background light , long-touch button 3 to turn on/off the blue background light. Remarks: *The clock shows for 5s, and shift to the temperature showing for 2s, then go back to show the clock. *It automatically displays the indoor temperature by auto sensing through the temperature sensor. *DO NOT cover the temperature sensor.

Button 1

Button 2

Button 3
