Kohler 581005-59 Sterling Meritor Frameless Sliding Bath Door Instruction Manual

KOHLER 581005-59 Sterling Meritor Frameless Sliding Bath Door

Features

• Frameless design emphasizes glass and creates a sleek, minimalist look.
• Center-guided mechanism for smooth, quiet sliding action and easy cleaning.
• ComforTrack® cushioned track enables you to sit, lean or kneel on the bottom track of the door to comfortably bathe children or clean the bathing space.
• Smooth, easy-to-clean wall jambs.
• Interior and exterior towel bars complete the look of this door.
• CleanCoat®+ glass coating creates a hydrophobic barrier that repels water, soap scum, and residue, saving time
  and protecting shower doors 10 times longer than original CleanCoat. (Based on 2021 internal wear/abrasion testing using a microfiber cloth.)

Material

• Frameless, 1/4″ (6 mm) thick tempered glass.
• Anodized aluminum prevents rust and corrosion.

Installation

• Fits opening widths 54-3/8″ – 59-3/8″ (1381 – 1508 mm).
• Out-of-plumb adjustability simplifies installation.
• Door can be installed to open to the left or right to suit your bathroom layout.
• For residential use only.
• Not for use in hospitality.

Included Components

• Additional Components:
  Hardware kit

Codes/Standards
ANSI Z97.1
CPSC 16CFR 1201
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.

Code   Description

• ADR
  Anodized Deep Bronze
• ADR
  Anodized Deep Bronze
• N
  Nickel
• N
  Nickel
• S
  Silver
• S
  Silver

1-800-STERLING (1-800-783-7546)
Kohler Co. reserves the right to make revisions without notice to product specifications. For the most current Specification Sheet, go to www.sterlingplumbing.com.
11-15-2021 04:44 – US/CA

Technical Information

All product dimensions are nominal.

• Installation type:
  For bath installation
• Opening style:
  Sliding/Bypass
• Opening Width – Min:
  54-3/8″ (1381 mm)
• Opening Width – Max:
  59-3/8″ (1508 mm)
• Walk-through – Min:
  22-1/2″ (572 mm)
• Walk-through – Max:
  27-1/2″ (698 mm)
• Base-To-Wall Radius – Max:
  5/8″ (16 mm)
• Glass thickness:
  1/4″ (6 mm)
• Glass coating:
  CleanCoat®

Notes
Install this product according to the installation guide.
