Park Royal Wl401722tsh Close Coupled Traditional High Level Toilet User Manual

WL401722TSH Close Coupled Traditional High Level Toilet

Product Information

• Product Name: WL401722TSH
• Manufacturer: Croydex
• Model: TS 067 R03
• Address: Croydex, Central Way, Andover, Hampshire, SP10 5AW,
  UK
• Contact: +44 (0) 1264 365881, +44 (0) 1264 356437,
  [email protected]
• Website: www.croydex.com

Product Usage Instructions

1. Before installation, ensure that the seat is not opened beyond
   105 degrees. If accidentally opened beyond this angle, insert one
   of the seat hinge pins into the visible hole and rotate the barrel
   back round until the other hole is visible.
2. If you can access the underside of the fixing holes on the
   toilet pan, loosely fit the brackets using the top fixings.
   Otherwise, use the bottom fixings for standard pans.
3. Align the seat with the hinges and lift it upright while
   ensuring that the hinges do not move. Then, fully push and release
   the center button to detach the seat from the hinges.
4. Tighten the hinges securely in position.
5. Attach the metal covers over the hinges and re-attach the
   toilet seat.

Note: For cleaning instructions and utilizing
the quick release function to remove the seat, refer to step 3 in
the provided instructions.

decorative cover
o-rings Flush Pipe

pull handle

WALL

Inlet Hole Pan panel

Flush Cone o-rings

High lever Flush Pipe kit

long copper pipe 1x pull handle 1x

fixing sleeve 1x

bracket 2x

tube 1x panel 1x screw8x

decorative cover 1x pull rod 1x
plastic part 8x

gasket 1x little screw 2x
O-ring 2x

flat gasket 4x little plastic part 2x

WL401722TSH

SAFETY & CARE
1. To retain the best quality finish, clean product with a soft cloth and a mild soap solution. 2. Do not use abrasive or chemical cleaners as they may damage the surface of the toilet seat or hinges. 3. Spray cleaning liquids onto the cloth and not directly onto the product. 4. Take care when cleaning the toilet pan with chemical cleaners. Avoid contact of the chemical cleaners with the toilet seat or hinges. Immediately rinse off any splashes to avoid damage or discolouration to the surface of the toilet seat and hinge parts.

5. Please do not open beyond 105 degrees before installation. If you accidentally do this, please insert one of the seat hinge pins into the visible hole and rotate the barrel back round until the other hole is visible.
1050

1 Loosely fit the brackets to the pan using either the top or bottom fittings.

Use top fixings

if you cannot

I

access the

underside of the

fixing holes on

the toilet pan.

J

B

C

D

3 Once aligned, lift the seat upright whilst ensuring the hinges do not move. Then fully push and release the centre button and lift the seat away from the hinges.

Use bottom

fixings on

I

standard pans.

J B C

E F G H
4 Fully tighten the hinges in position.

FITTING PACK
Metal Cover
A (x2)

Rubber Grip
C (x2)

Hinge Base

Top Fix Plug

B (x2)

D (x2)

2 Attach the seat onto the hinges and adjust to fit your toilet pan.

E (x2)

Coned Flexible Washer

F (x2)

Metal Washer

G (x2)

Metal Nut

Key

H (x2)

Hex Key

Bolt

I (x2)

J (x2)

5 Place the metal covers over the hinges and re-attach the toilet seat.

FOR CLEANING
Look to step 3 for instructions on how to utilise the quick release function which allows you to remove the seat for cleaning.

A

Croydex, Central Way, Andover, Hampshire, SP10 5AW, UK

+44 (0) 1264 365881

+44 (0) 1264 356437

[email protected]

www.croydex.com

TS 067 R03
