PLM-9702-HN G.hn Over Phone Line Ethernet Bridge
Product Information
| Brand | ZINWELL |
|---|---|
| Model | PLM-9702-HN |
| Description | G.hn over Phone Line Ethernet Bridge |
| Hardware Installation Guide | p.n.909904 |
Product Usage Instructions
Step 1:
Plug a G.hn over Phone Line Ethernet Bridge into an AC outlet
using the AC adapter provided. Use a phone-line cable to connect
its G.hn Link connector to a wall’s phone jack. Then use an
Ethernet cable to connect the Bridge to a router or modem.
Step 2:
Plug another G.hn over Phone Line Ethernet Bridge into another
AC outlet using the AC adapter provided. Use a phone-line cable to
connect its G.hn Link connector to the wall’s phone jack. Then use
an Ethernet cable to connect it to any network device such as a
streaming box, smart TV, or gaming console.
Pairing Two Bridges:
Users can easily create a G.hn network by pressing the Pairing
buttons on the Bridges in the proper order to pair them together.
To set up the network, follow the steps below:
- Verify that the Power LED initial state on both Bridges is
solid green. The G.hn Link LED is off when a G.hn over Phone Line
Ethernet Bridge does not have a secured link to a G.hn
network. - Press and hold the Pairing button on Bridge A for 3 seconds
until its G.hn Link LED starts blinking amber. - Press and hold the Pairing button on Bridge B for 3 seconds
until its G.hn Link LED starts blinking amber. - When a Bridge has paired to a network, its Power LED will be
solid amber. Note: The G.hn LED of Bridge A will continue to blink
for approximately 120 seconds.
Un-pairing/Removing a Device from the G.hn Network:
To un-pair/remove a device from the G.hn network, follow the
steps below:
- Press and hold the Reset button (inside the pinhole) of the
unit for 15 seconds until all of its LEDs turn off for 0.5 seconds
and then turn back on.
ZINWELL
PLM-9702-HN
G.hn over Phone Line Ethernet Bridge
PLM-9702-HN G.hn OVER PHONE LINE ETHERNET BRIDGE
HARDWARE INSTALLATION
p.n.909904
Ethernet LED G.hn Link LED Power LED
Installation Guide
This Installation Guide is used to install the PLM-9702-HN G.hn over Phone Line Ethernet Bridge.
Pairing button DC-in connector
Ethernet Port 2
Ethernet Port 1 Reset button G.hn Link connector
LED INDICATORS
Modem / Router
Network device
Step 1: Plug a G.hn over Phone Line Ethernet Bridge into an AC outlet using
the AC adapter provided. Use a phone-line cable to connect its G.hn Link connector to a wall’s phone jack. Then use an Ethernet cable to connect the Bridge to a router or modem.
Step 2: Plug another G.hn over Phone Line Ethernet Bridge into another AC
outlet using the AC adapter provided. Use a phone-line cable to connect its G.hn Link connector to the wall’s phone jack. Then use an Ethernet cable to connect it to any network device such as a streaming box, smart TV, or gaming console.
PAIRING TWO BRIDGES
Users can easily create a G.hn network–simply press the Pairing buttons on the Bridges in the proper order to “pair” them together. To set up the network, follow the steps below.
Bridge A
Bridge B
PLM-9702-HN
G.hn over Phone Line Ethernet Bridge
Power LED Green + Red
LED Behavior
Green ON: AC power is detected; can link to another G.hn over phone line device in unsecured mode.
Amber BLINKING: Security pairing procedure in progress Amber SOLID: Device is paired into a G.hn over phone line
network. OFF: No AC power is detected.
G.hn Link LED Green + Red
Green SOLID: G.hn over phone line PHY rate is > 300 Mbps; no data traffic over the phone-line cable.
Green BLINKING: G.hn over phone line PHY rate > 300 Mbps
Amber SOLID: G.hn over phone line PHY rate is 100 Mbps300 Mbps; no data traffic over the phone-line cable.
Amber BLINKING: G.hn over phone line PHY rate is 100 Mbps300 Mbps.
Red SOLID: G.hn over phone line link PHY rate is < 100 Mbps; no data traffic over the phone-line cable.
Red BLINKING: G.hn over phone line PHY rate is < 100 Mbps.
OFF: No G.hn over phone line link is detected. (Either other devices in the same network are too far to communicate, or it is alone in its logical network.)
Ethernet LED Green + Red
Green SOLID: Ethernet Port 1 link is detected. Green BLINKING: Ethernet Port 1 link is active. Red SOLID: Ethernet Port 2 link is detected. Red BLINKING: Ethernet Port 2 link is active. OFF: No Ethernet link is detected.
Modem / Router
Network device
Step 1 : Verify the Power LED initial state on both Bridges is solid green.
The G.hn Link LED is off when a G.hn over Phone Line Ethernet Bridge does not have a secured link to a G.hn network.
Step 2 : Press and hold the Pairing button on Bridge A for 3 seconds (refer to
the image above) until its G.hn Link LED starts blinking amber.
Step 3 : Press and hold the Pairing button on Bridge B for 3 seconds until its
G.hn Link LED starts blinking amber.
Step 4 : When a Bridge has paired to a network, its Power LED will be
solid amber.
Note: The G.hn LED of Bridge A will continue to blink for approx. 120 seconds.
During that time, you may add more bridges to the network by repeating Steps 14 above.
UN-PAIRING/REMOVING A DEVICE FROM THE G.hn NETWORK
Step 1 : Press and hold the Reset button (inside the pinhole) of the unit for
15 seconds until all of its LEDs turn off for 0.5 seconds and then turn back on.
Step 2 : The G.hn Link LED will then blink once in amber, then turn off.
V01
