ACCU MINI-PAR 12TC Mk2 Ultra Compact Battery Powered Projector
Product Information:
- Product Name: ACCU MINI-PAR 12TC Mk2 / MINI-PAR COB Mk2
- Version: 1.0
- Manufacturer: JB-SYSTEMS
- Website: www.jb-systems.eu
Safety Instructions:
CAUTION: To reduce the risk of electric shock, do not remove the
top cover. No user-serviceable parts inside. Refer servicing to
qualified service personnel only.
The lightning flash with arrowhead symbol within the equilateral
triangle is intended to alert the user of the presence of
un-insulated dangerous voltage within the product’s enclosure that
may be of sufficient magnitude to constitute a risk of electric
shock.
The exclamation point within the equilateral triangle is
intended to alert the user to the presence of important operation
and maintenance (servicing) instructions in the literature
accompanying this appliance.
This symbol means: indoor use only. This symbol means: Read
instructions.
Important: Never look directly into the light source! Don’t use
the effect in the presence of persons suffering from epilepsy.
Description:
- MAINS CABLE: Connect the cable to the mains to power the
unit. - DMX INPUT: 3pin male XLR-connector used to connect universal
DMX-cables. This input receives instructions from a DMX-controller
or from the Master unit in Master/slave mode. - DMX OUTPUT: 3pin male XLR-connector used to connect universal
DMX-cables. Use this output to connect the next unit in the DMX
chain. - BRACKET: Use the hole in this bracket to fix the unit to a
mounting clamp or use the double bracket as a floor stand. - DISPLAY: Shows the various menus and the selected
functions. - NAVIGATION BUTTONS:
- [MENU]: To browse the different menu options
- [UP]: To increase a value
- [DOWN]: To decrease a value
- [ENTER]: To confirm the selected functions or to go to the next
submenu
- USB-C Connector: Connect the supplied USB-C cable (with power
adapter) here to charge the battery or to power the unit via 230V
(only on the ACCU version). - BATTERY LED: Shows the status of the battery when
charging.
Product Usage Instructions:
Overhead Rigging:
Before using the unit for the first time, consult an expert for
proper rigging and safety precautions. The installations should be
inspected every year by a skilled person to ensure optimal
safety.
Setting Up and Controlling the Unit:
- Manual Mode: Use the navigation buttons on the
unit to manually control various functions. - Automatic Modes: The unit automatically runs
preprogrammed sequences. Different automatic modes are
available. - Static Color Modes: Set a static color in two
different ways. - IR Remote Controller: The unit can be used
with an Infra-Red remote controller (not included, available for
separate purchase). Functions include switching the effect On or
Off, selecting automatic programs, and selecting sound activated
programs.
Note:
Refer to the complete user manual for detailed instructions on
each mode and function.
ACCU MINI-PAR 12TC Mk2 MINI-PAR 12TC Mk2 MINI-PAR COB Mk2
ENGLISH
Operation Manual
Other languages can be downloaded from: WWW.JB-SYSTEMS.EU
Version: 1.0
ENGLISH
USER MANUAL
OPERATION MANUAL
Thank you for buying this JB Systems® product. To take full advantage of all possibilities and for your own safety, please read these operating instructions very carefully before you start using this unit.
FEATURES
· Ultra-compact RGB LED projector. o 12TC version with 12 high power led’s and a beam of 17° o COB version with a powerful single beam of 38°
· The ACCU MINI-PAR 12TC is equipped with a rechargeable Lithium battery ! Battery run time @ full power / single color (red, green or blue) = 7 hours Battery run time @ full power / color fade = > 5 hours Charging time: 3-4 hours
· Use the unit in any way you like it ! · Standalone: sound activated (internal mic) or automatic shows. · Can be controlled with the optional IR REMOTE controller (order code B05545) · Master/slave function for wonderful synchronized shows when several units are used. · DMX-control: via 3, 4 or 5 Channels.
· Prepared for wireless DMX: just plug-in an optional WTR-DMX DONGLE ! (Briteq® code: B04645) · 4-digit LED display for easy menu navigation · Compatible with the LEDCON-02 Mk2 and LEDCON-XL controllers · Double hanging bracket that can be used as a floor stand
BEFORE USE
· Before you start using this unit, please check if there’s no transportation damage. Should there be any, do not use the device and consult your dealer first.
· Important: This device left our factory in perfect condition and well packaged. It is absolutely necessary for the user to strictly follow the safety instructions and warnings in this user manual. Any damage caused by mishandling is not subject to warranty. The dealer will not accept responsibility for any resulting defects or problems caused by disregarding this user manual.
· Keep this booklet in a safe place for future consultation. If you sell the fixture, be sure to add this user manual.
Check the contents: Check that the cardboard box contains the following items: · MINI-PAR unit · Power Supply + USB-C cable (only for the ACCU MINI-PAR 12TC) · Operating instructions
JB SYSTEMS®
1/10
(ACCU) MINI-PAR 12TC / COB
ENGLISH
USER MANUAL
SAFETY INSTRUCTIONS:
CAUTION
CAUTION: To reduce the risk of electric shock, do not remove the top cover. No user-serviceable parts inside. Refer servicing to qualified service
personnel only.
The lightning flash with arrowhead symbol within the equilateral triangle is intended to alert the use
or the presence of un-insulated “dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
The exclamation point within the equilateral triangle is intended to alert the user to the presence of
important operation and maintenance (servicing) instructions in the literature accompanying this
appliance.
This symbol means: indoor use only. This symbol means: Read instructions.
This symbol determines: the minimum distance from lighted objects. The minimum distance between light-output and the illuminated surface must be more than 1 meter. · To protect the environment, please try to recycle the packing material as much as possible. · A new light effect sometimes causes some unwanted smoke and/or smell. This is normal and disappears after some minutes. · To prevent fire or shock hazard, do not expose this appliance to rain or moisture. · To avoid condensation to be formed inside, allow the unit to adapt to the surrounding temperatures when bringing it into a warm room after transport. Condense sometimes prevents the unit from working at full performance or may even cause damages. · This unit is for indoor use only. · Don’t place metal objects or spill liquid inside the unit. Electric shock or malfunction may result. If a foreign object enters the unit, immediately disconnect the mains power. · Locate the fixture in a well ventilated spot, away from any flammable materials and/or liquids. The fixture must be fixed at least 50cm from surrounding walls. · Don’t cover any ventilation openings as this may result in overheating. · Prevent use in dusty environments and clean the unit regularly. · Keep the unit away from children. · Inexperienced persons should not operate this device. · The save ambient temperature is between 15° & 40°C. Don’t use this unit at higher ambient temperatures. · Make sure the area below the installation place is free from unwanted persons during rigging, de-rigging and servicing. · Always unplug the unit when it is not used for a longer time or before replacing the bulb or start servicing. · The electrical installation should be carried out by qualified personal only, according to the regulations for electrical and mechanical safety in your country. · Check that the available voltage is not higher than the one stated on the rear panel of the unit. · The power cord should always be in perfect condition. Switch the unit immediately off when the power cord is squashed or damaged. It must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. · Never let the power-cord come into contact with other cables! · This fixture must be earthed to in order comply with safety regulations. · Don’t connect the unit to any dimmer pack. · Always use an appropriate and certified safety cable when installing the unit. · In order to prevent electric shock, do not open the cover. Apart from the lamp and mains fuse there are no user serviceable parts inside. · Never repair a fuse or bypass the fuse holder. Always replace a damaged fuse with a fuse of the same type and electrical specifications! · In the event of serious operating problems, stop using the fixture and contact your dealer immediately. · The housing and the lenses must be replaced if they are visibly damaged. · Please use the original packing when the device is to be transported. · Due to safety reasons it is prohibited to make unauthorized modifications to the unit.
Important: Never look directly into the light source! Don’t use the effect in the presence of persons suffering from epilepsy.
JB SYSTEMS®
2/10
(ACCU) MINI-PAR 12TC / COB
ENGLISH
DESCRIPTION
USER MANUAL
1. MAINS CABLE: Connect the cable to the mains to power the unit. 2. DMX INPUT: 3pin male XLR-connector used to connect universal DMX-cables. This input receives
instructions from a DMX-controller or from the Master unit in Master/slave mode. 3. DMX OUTPUT: 3pin male XLR-connector used to connect universal DMX-cables. Use this output to
connect the next unit in the DMX chain 4. BRACKET: use the hole in this bracket to fix the unit to a mounting clamp or use the double bracket as a
floor stand 5. DISPLAY: shows the various menus and the selected functions. 6. NAVIGATION BUTTONS:
To browse the different menu options To increase a value To decrease a value To confirm the selected functions or to go to the next submenu
7. USB-C Connector: connect the supplied USB-C cable (with power adapter) here to charge the battery or to power the unit via 230V (only on the ACCU version)
8. BATTERY LED: shows the status of the battery when charging
· RED: the battery is still charging
· GREEN: the battery is fully charged. The unit can be powered via its internal battery 9. POWER SWITCH: to switch the unit ON or OFF (only on the ACCU version) 10. M-DMX INPUT: Please note that this USB-connector is NOT used for updates or to
connect the unit to a PC! Instead this USB-connector makes it very easy to add wireless DMX to the unit! Just add the (optional) WTR-DMX DONGLE from BRITEQ® and you will get wireless DMX! Moreover, you will be able to connect other DMX-controlled equipment to the DMX-output so you can share the wireless DMX function with all connected units! No extra settings to be made in the setup menu, just follow the procedure in the user manual supplied with the WTR-DMX DONGLE from BRITEQ®. The separate WTR-DMX DONGLE is available from WWW.BRITEQ-LIGHTING.COM (order code: 4645)
JB SYSTEMS®
3/10
(ACCU) MINI-PAR 12TC / COB
ENGLISH
USER MANUAL
OVERHEAD RIGGING
· Important: The installation must be carried out by qualified service personal only. Improper installation can result in serious injuries and/or damage to property. Overhead rigging requires extensive experience! Working load limits should be respected, certified installation materials should be used, the installed device should be inspected regularly for safety.
· Make sure the area below the installation place is free from unwanted persons during rigging, de-rigging and servicing.
· Locate the fixture in a well ventilated spot, far away from any flammable materials and/or liquids. The fixture must be fixed at least 50cm from surrounding walls.
· The device should be installed out of reach of people and outside areas where persons may walk by or be seated.
· Before rigging make sure that the installation area can hold a minimum point load of 10times the device’s weight.
· Always use a certified safety cable that can hold 12 times the weight of the device when installing the unit. This secondary safety attachment should be installed in a way that no part of the installation can drop more than 20cm if the main attachment fails.
· The device should be well fixed; a free-swinging mounting is dangerous and may not be considered! · Don’t cover any ventilation openings as this may result in overheating. · The operator has to make sure that the safety-relating and machine-technical installations are approved by
an expert before using them for the first time. The installations should be inspected every year by a skilled person to be sure that safety is still optimal.
HOW TO SET UP AND CONTROL THE UNIT
1) SOUND CONTROLLED MODE A4: The unit runs a preprogrammed sequence to the rhythm of the music. Select this mode when only 1 unit is used (standalone) or when the unit is placed as the first (master) unit in a chain with several units. · Press the [MENU] button until the display shows: [A4.00] (A4. Followed by 2 numbers) · Now use the [UP] or [DOWN] to select on of the 19 different sound modes.
2) FULL AUTOMATIC MODES A2. A3. A5. A6. A7. The unit automatically runs a preprogrammed sequence. Different automatic modes are available:
COLOR CHANGE A2. · Press the [MENU] button until the display shows [A2.00] (A2. Followed by 2 numbers) · Now use the [UP] or [DOWN] to select the desired speed. (01=slowest, 32=fastest)
COLOR FADE A3. · Press the [MENU] button until the display shows [A3.00] (A3. Followed by 2 numbers) · Now use the [UP] or [DOWN] to select one of the 19 different modes. · Press the [ENTER] button · Now use the [UP] or [DOWN] to select the desired speed. (01=slowest, 32=fastest)
COLOR CHANGE + STROBE A5. · Press the [MENU] button until the display shows [A5.00] (A5. Followed by 2 numbers) · Now use the [UP] or [DOWN] to select one of the 19 different modes. · Press the [ENTER] button · Now use the [UP] or [DOWN] to select the desired strobe speed. (01=slowest, 32=fastest)
AUTOMATIC RANDOM MODE A6. · Press the [MENU] button until the display shows [A6.01] · A show of different types of effects (fade, color change, strobe, …) will start
COLOR CHANGE + PULSE EFFECT A7. · Press the [MENU] button until the display shows [A7.00] (A7. Followed by 2 numbers) · Now use the [UP] or [DOWN] to select one of the 19 different modes.
JB SYSTEMS®
4/10
(ACCU) MINI-PAR 12TC / COB
ENGLISH
USER MANUAL
· Press the [ENTER] button · Now use the [UP] or [DOWN] to select the desired pulse speed. (01=slowest, 32=fastest)
3) STATIC COLOR MODES A1. & RGBW. You can set a static color in 2 Different ways:
PRESET COLOR A1. · Press the [MENU] button until the display shows [A1.00] (A1. Followed by 2 numbers) · Now use the [UP] or [DOWN] to select the desired color
MANUAL CUSTOM COLOR. If you need a color that is not available in the presets, you can compose your own color by adapting the intensity of each individual color (Red, Green, Blue) · Press the [MENU] button until the display shows [rxxx] (r Followed by 3 numbers) · Now use the [UP] or [DOWN] to set the intensity of the Red color · Press the [MENU] button until the display shows [Gxxx] (G Followed by 3 numbers) · Now use the [UP] or [DOWN] to set the intensity of the Green color · Press the [MENU] button until the display shows [bxxx] (b Followed by 3 numbers) · Now use the [UP] or [DOWN] to set the intensity of the blue color
4) MASTER / SLAVE MODE: Several units can be connected together to create nice synchronized shows. The (slave) units will follow the instructions given by the first unit (master) in the chain. NOTE: it is important to execute the next steps in the correct order · Set the DMX address of all the slave units to [d001] before to connect them to the master unit . · Connect the DMX output of the master unit to the infput of the first Slave unit. · Connect the DMX output of the first Slave unit to the infput of the second Slave unit. · Etc. · Select the desired working mode in your master unit (fixed color, color fade, color change, etc…) · All the connected slave devices will follow the program of the master unit. You can connect up to 32 units together.
JB SYSTEMS®
5/10
(ACCU) MINI-PAR 12TC / COB
ENGLISH
USER MANUAL
5) IR REMOTE CONTROLLER: The unit can be used with an Infra-Red remote controller. The IR remote controller is not included but can be ordered separately (IR REMOTE, order code B05545)
Functions:
To switch the effect On or Off Press to select the automatic programs Press to select the sound activated programs
Select Red and use
to adjust its intensity in your custom color
Select Green and use
to adjust its intensity in your custom color
Select Blue and use
to adjust its intensity in your custom color
Use these buttons to modify the program / speed.
When A, B or C is selected it will modify the intensity of the color
To pause the program
Toggle between program and speed when automatic programs are running.
Use
to adjust
1
Preset color: Red
2
Preset color: Green
3
Preset color: Light Blue
4
Preset color: Orange
5
Preset color: Blue
6
Preset color: White
7
Preset color: Purple
8
Preset color: Pink
9
Preset color: Yellow
0
Preset color: Cyan
-/– Preset color: Warm White
6) DMX CONTROLLED: The projector can be controlled by any standard DMX-controller in different DMX-modes. To do this, you need to set the desired start address and dmx mode for each unit · Press the [MENU] button until the display shows [dMH] · Press the [ENTER] button · Use the [UP] or [DOWN] buttons to select the DMX mode you want to use. [03Ch], [05Ch] or [LC02] (check the DMX charts below for more information about these DMX modes) · Press the [ENTER] button · Use the [UP] or [DOWN] buttons to select the desired DMX address
JB SYSTEMS®
6/10
(ACCU) MINI-PAR 12TC / COB
ENGLISH
USER MANUAL
Some more information on DMX512: The DMX-protocol is a widely used high speed signal to control intelligent light equipment. You need to “daisy chain” your DMX controller and all the connected light effects with a good quality XLR M/F balanced cable. To prevent strange behavior of the light effects, due to interferences, you must use a 90 to 120 terminator at the end of the chain. Never use Y-splitter cables, this simply won’t work! Each effect in the chain needs to have its proper starting address so it knows which commands from the controller it has to decode.
03CH Mode:
DMX Channel
1
2 3
DMX-value
000-255 000-255 000-255
function
Red color dimmer Green color dimmer Blue color dimmer
LC-02 Mode: To be used with the Ledcon-02 Mk2
DMX Channel
1 2 3
4
DMX-value
000-255 000-255 000-255 000-190 191-200 201-247 248-255
function
Red color dimmer Green color dimmer Blue color dimmer
Master Dimmer Sound
Strobe Slow to fast Master Dimmer 100% (full on)
05CH Mode
DMX Channel
1 2 3 4
5
DMX-value
000-255 000-255 000-255 000-255
000 001-010 011-255
function
Red color dimmer Green color dimmer Blue color dimmer
Master Dimmer No Effect
Sound Control Strobe Slow to fast
JB SYSTEMS®
7/10
(ACCU) MINI-PAR 12TC / COB
ENGLISH
06CH Mode DMX
Channel 1 2 3 4
5
DMX-value
000-255 000-255 000-255 000-255 000-010 011-013 014-016 017-019 020-022 023-025 026-028 029-031 032-034 035-037 038-040 041-043 044-067 068-070 071-073 074-076 077-079 080-082 083-085 086-088 089-092 093-095 096-098 099-101 102-104 105-107 108-110 111-113 114-116 117-119 120-122 123-125 126-128 129-131 132-134 135-137 138-140 141-143
JB SYSTEMS®
USER MANUAL
function
Red color dimmer Green color dimmer Blue color dimmer
Master Dimmer MANUAL MODE (use CH1-CH4)
Color macro 1 Color macro 2 Color macro 3 Color macro 4 Color macro 5 Color macro 6 Color macro 7 Color macro 8 Color macro 9 Color macro 10 Color macro 11 Color Change (Speed Control = Channel 6) Color Fade A3.01 (Speed Control = Channel 6) Color Fade A3.02 (Speed Control = Channel 6) Color Fade A3.03 (Speed Control = Channel 6) Color Fade A3.04 (Speed Control = Channel 6) Color Fade A3.05 (Speed Control = Channel 6) Color Fade A3.06 (Speed Control = Channel 6) Color Fade A3.07 (Speed Control = Channel 6) Color Fade A3.08 (Speed Control = Channel 6) Color Fade A3.09 (Speed Control = Channel 6) Color Fade A3.10 (Speed Control = Channel 6) Color Fade A3.11 (Speed Control = Channel 6) Color Fade A3.12 (Speed Control = Channel 6) Color Fade A3.13 (Speed Control = Channel 6) Color Fade A3.14 (Speed Control = Channel 6) Color Fade A3.15 (Speed Control = Channel 6) Color Fade A3.16 (Speed Control = Channel 6) Color Fade A3.17 (Speed Control = Channel 6) Color Fade A3.18 (Speed Control = Channel 6) Color Fade A3.19 (Speed Control = Channel 6)
Sound mode A4.01 Sound mode A4.02 Sound mode A4.03 Sound mode A4.04 Sound mode A4.05 Sound mode A4.06
8/10
(ACCU) MINI-PAR 12TC / COB
ENGLISH JB SYSTEMS®
144-146 147-149 150-152 153-155 156-158 159-161 162-164 165-167 168-169 170-171 172-173 174-175 176-177 178-179 180-181 182-183 184-185 186-187 188-189 190-191 192-193 194-195 196-197 198-199 200-201 202-203 204-205 206-207 208-209 210-211 212-213 214-215 216-217 218-219 220-221 222-223 224-225 226-227 228-229 230-231 232-233 134-235 236-237 238-239
USER MANUAL
Sound mode A4.07 Sound mode A4.08 Sound mode A4.09 Sound mode A4.10 Sound mode A4.11 Sound mode A4.12 Sound mode A4.13 Sound mode A4.14 Sound mode A4.15 Sound mode A4.16 Sound mode A4.17 Sound mode A4.18 Sound mode A4.19 Random mode A5.01 (Speed Control = Channel 6) Random mode A5.02 (Speed Control = Channel 6) Random mode A5.03 (Speed Control = Channel 6) Random mode A5.04 (Speed Control = Channel 6) Random mode A5.05 (Speed Control = Channel 6) Random mode A5.06 (Speed Control = Channel 6) Random mode A5.07 (Speed Control = Channel 6) Random mode A5.08 (Speed Control = Channel 6) Random mode A5.09 (Speed Control = Channel 6) Random mode A5.10 (Speed Control = Channel 6) Random mode A5.11 (Speed Control = Channel 6) Random mode A5.12 (Speed Control = Channel 6) Random mode A5.13 (Speed Control = Channel 6) Random mode A5.14 (Speed Control = Channel 6) Random mode A5.15 (Speed Control = Channel 6) Random mode A5.16 (Speed Control = Channel 6) Random mode A5.17 (Speed Control = Channel 6) Random mode A5.18 (Speed Control = Channel 6) Random mode A5.19 (Speed Control = Channel 6) Random mode A6 A7.01 Color Change + Pulse (Speed Control = Channel 6) A7.02 Color Change + Pulse (Speed Control = Channel 6) A7.03 Color Change + Pulse (Speed Control = Channel 6) A7.04 Color Change + Pulse (Speed Control = Channel 6) A7.05 Color Change + Pulse (Speed Control = Channel 6) A7.06 Color Change + Pulse (Speed Control = Channel 6) A7.07 Color Change + Pulse (Speed Control = Channel 6) A7.08 Color Change + Pulse (Speed Control = Channel 6) A7.09 Color Change + Pulse (Speed Control = Channel 6) A7.10 Color Change + Pulse (Speed Control = Channel 6) A7.11 Color Change + Pulse (Speed Control = Channel 6)
9/10
(ACCU) MINI-PAR 12TC / COB
ENGLISH
USER MANUAL
240-241
A7.12 Color Change + Pulse (Speed Control = Channel 6)
242-243
A7.13 Color Change + Pulse (Speed Control = Channel 6)
244-245
A7.14 Color Change + Pulse (Speed Control = Channel 6)
246-247
A7.15 Color Change + Pulse (Speed Control = Channel 6)
248-249
A7.16 Color Change + Pulse (Speed Control = Channel 6)
250-251
A7.17 Color Change + Pulse (Speed Control = Channel 6)
252-253
A7.18 Color Change + Pulse (Speed Control = Channel 6)
254-255
A7.19 Color Change + Pulse (Speed Control = Channel 6)
6
000-255
Auto Program SPEED
MAINTENANCE
· Make sure the area below the installation place is free from unwanted persons during servicing. · Switch off the unit, unplug the mains cable and wait until the unit has been cooled down. During inspection the following points should be checked: · All screws used for installing the device and any of its parts should be tightly fastened and may not be
corroded. · Housings, fixations and installations spots (ceiling, truss, suspensions) should be totally free from any
deformation. · When an optical lens is visibly damaged due to cracks or deep scratches, it must be replaced. · The mains cables must be in impeccable condition and should be replaced immediately when even a
small problem is detected. · In order to protect the device from overheat the cooling fans (if any) and ventilation openings should be
cleaned monthly. · The interior of the device should be cleaned annually using a vacuum cleaner or air-jet. · The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surroundings can cause greater accumulation of dirt on the unit’s optics.
· Clean with a soft cloth using normal glass cleaning products. · Always dry the parts carefully. · Clean the external optics at least once every 30 days. · Clean the internal optics at least every 90 days. Attention: We strongly recommend internal cleaning to be carried out by qualified personnel!
SPECIFICATIONS
This device was designed to produce decorative effect lighting and is used in light show systems. This unit is radio-interference suppressed. This product meets the requirements of the current European and national guidelines. Conformity has been established and the relevant statements and documents have been deposited by the manufacturer.
Mains Input MINI-PAR 12TC Mk2: Mains Input ACCU MINI-PAR 12TC / COB: Max. Power consumption 12TC version: Max. Power consumption COB version: Sound Control: DMX connections: DMX channels: 12TC version LEDs: COB version LED: Working temperature: Size: Weight:
AC 100~240V, 50/60Hz DC 5V 10W 22W Internal microphone 3pin XLR male / female 3 / 5 channels + Ledcon-02 Mk2 mode 12x 3Watt RGB Leds 15Watt RGB COB Led 10°C to 40°C 150x160x90mm 0.4 kg / 0.7 kg (accu version)
All the information is subject to change without prior notice You can download the latest version of this user manual on our website: www.jb-systems.eu
JB SYSTEMS®
10/10
(ACCU) MINI-PAR 12TC / COB
