Production Specifications
Eaton RT316036B22
Catalog number: RT316036B22
Eaton molded case circuit breaker accessory trip unit, Trip unit, 1600 A, 310+ Trip unit retro-fit kit, LSIG, GFA
General specifications
Product Name
Eaton molded case circuit breaker accessory trip unit
Catalog Number
RT316036B22
UPC
786685864662
Product Length/Depth
7.5 in
Product Height
5.376 in
Product Width
3.75 in
Product Weight
3 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
Contact Manufacturer
Certifications
IEC 60947-2 UL 489 CSA Std. C22.2 No. 5
defaultTaxonomyAttributeLabel
Type
Trip unit
Amperage Rating
1600 A
Trip Type
310+ trip unit retro-fit kit, LSIG, GFA
Resources
Application notes
Application of Tap Rules to Molded Case Breaker Terminals
Application of Multi-Wire Terminals for Molded Case Circuit Breakers
Brochures
Multi-wire lugs product aid
Motor protection circuit breakers product aid
High performance operating handles for Series G circuit breakers product aid
Series G MCCB quick selector
StrandAble terminals product aid
Comprehensive circuit protection for control panel applications
Molded case circuit breakers providing higher levels of selective coordination product aid
Power metering and monitoring with Modbus RTU product aid
Circuit breaker motor operators product aid
Current limiting molded case circuit breaker module for series G, JG and CL
Plug-in adapters for molded case circuit breakers product aid
Current limiting molded case circuit breaker module product aid
Breaker service centers
Catalogs
Molded case circuit breakers catalog
Eaton’s Volume 4–Circuit Protection
Multimedia
Flex shaft handle installation tutorial
Specifications and datasheets
MOEM MCCB product selection guide
Eaton Specification Sheet – RT316036B22
NG and ND-Frame molded case circuit breakers
