SBL-0110 LED Bar Light

Product Information

The product is a barlight series LED light manufactured by MBJ
Imaging GmbH. The light is equipped with M4 threaded holes at each
end that can be used to fix the lighting to the specified position.
M2.5 threaded holes are provided at the two long sides to mount the
foil and filter holder set. The light is available in six different
sizes ranging from SBL-0110 to SBL-0150, with each size having a
different luminous area. The light emits white, red, infrared,
green, blue, and yellow colors.

For electrical connection, the lighting is equipped with a 4-pin
M8x1 connector with pin 1 (brown) being the standard for 24 VDC LED
(+), pin 2 (white) being used for dimming and operation mode
switch, pin 3 (blue) being the trigger for LED (-), and pin 4
(black) being the ground for LED (-).

The light has an operating temperature of 30% to 70% humidity
and is protected against the ingress of solids and water in
accordance with the selected protection class and applicable
standards. The degree of protection is IP54 or IP67 depending on
the model selected. The device is designed for indoor use only.

Product Usage Instructions

  1. Read the warning and application instructions carefully and
    completely before operating the device.
  2. Ensure that the light is mounted securely using the M4 threaded
    holes at each end.
  3. If using a foil and filter holder set, mount it on the two long
    sides using the M2.5 threaded holes.
  4. To ensure a long lifespan, additional heat transfer
    measurements at the holding positions are highly recommended.
  5. For electrical connection, use the 4-pin M8x1 connector and
    connect the pins according to the standard or direct wiring
    instructions provided in the manual.
  6. Use the recommended MBJ lighting cable for the connection and
    ensure that the cable length does not exceed 10m.
  7. Do not exceed the permissible input voltage Uin or ULED(+) as
    it can lead to the destruction of the device or to a significant
    shortening of the lifetime of the LEDs in the device.
  8. Clean the light emission surface with a standard glass cleaner
    and a soft cleaning cloth. Do not use other materials for cleaning
    as it will damage the device.

Mechanical Integration
The light is equipped with M4 threaded holes at each end. It can be used to fix the lighting to the specified position. In addition M2.5 threaded holes are provided at the two long sides to mount the foil and filter holder set. To ensure a long live time additionals heat transfer measurements at the holding positions are highly recommended.
Example: Model SBL-0120
More 2D and 3D drawings can be found online: www.mbj-imaging.com

Safety Notes
Before working with this unit, read the warning and application instructions carefully and completely before operating the device.

Specification Operating temperature
Certifications Degree of protection
Humidity

Barlight 10°C to 30°C / 45°C1)
CE, RoHS IP54 or IP672) 30 % to 70 %

1) Max. of 30°C is recommended for steady light operation w/o additional heat transfer measurements, for max. 45°C a thermal connection is mandatory. Max. of 45°C is also permissible for flash light operation with a max. 10 % duty cycle.
2) MBJ LED lights are protected against the ingress of solids and water in accordance with the selected protection class and applicable standards. Permanent protection against liquids containing solvents, such as cleaning agents, machine emulsions or other lubricants, cannot be guaranteed. IP is only valid with a connected cable (MBJ cable recommended).

1. The device is designed for indoor use only.
2. Light ­ Due to the risk of flash burn of the eyes it is not recommended to look directly into the light source. The lighting must be switched off before installation and/or maintenance. The device must not be used when a failure may cause a personal injury.
3. Heat – In case of insufficient heat dissipation or when running the light in flash mode with a too high duty cycle, the surface temperature may exceed 60 °C. Keep off flammable materials at any time.
4. Electricity – The housing is electrically isolated from the ground of the power supply. Exceeding the permissible input voltage Uin or ULED(+) can lead to the destruction of the device or to a significant shortening of the lifetime of the LEDs in the device.
5. Usage ­ Please prevent mechanical stress to the light surface during operation. This will lead to a inhomogenious light emission.
6. Cleaning – The light emission surface has to be cleaned with a standard glass cleaner and a soft cleaning cloth. Do not use other material for cleaning as it will damage the device.

03198.06 Manual MBJ Barlight SBL-Series, März 2023

MBJ Imaging GmbH

Jochim-Klindt-Straße 7

+49 4102 778 90 31

22926 Ahrensburg, Germany

[email protected]

www.mbj-imaging.com

Operating Manual Technical Data
Barlight Series
Optional:

Model Sizes in Series

The light is available in the following sizes 1)

SBL-0110

SBL-0115

SBL-0120

SBL-0130

SBL-0140

SBL-0150

1) Size definition: SBL-0120 refers to a luminous area of 10 mm x 200 mm.

Possible LED Colors

LED

Abbr.1)

Peak Wavelength2)

White

-WT

5000 K, CRI80

Red

-RD

near 625 nm

Infrared

-IR

near 850 nm

Green

-GN

near 525 nm

Blue

-BE

near 465 nm

Yellow

-YE

near 580 nm

1) Color option will be added to the model name after the size information. SBL-0120-IR refers to a barlight with 850 nm infrared light.
2) This is an approximated value. The exact value also depends on LED temperature and LED current.

Electrical Connection
The lighting is equipped with an 4 pin M8x1 connector.

Pin

Color 1)

Standard (-s)

Direct (-x) 2)

1

brown

24 VDC

LED (+)

2

white

Dim

LED (+)

3

blue

Trigger

LED (-)

4

black

Ground

LED (-)

1) Wire color of MBJ lighting cable 2) Connection to 24 VDC without external LED controller may destroy the unit

Additional Information:
Pin3 (Trigger) is an `active high’ input signal with 5…24 V=ON and 0…1 V=OFF, it is a high resistance current sink with 0.2 mA for 5 V and 5 mA for 24 V
Pin2 (DIM) is used as brightness control and operation mode switch, it is a high resistance current sink with 0.2 mA for 5 V and 1 mA for 24 V.
For the connection it is recommended to use the MBJ lighting cable with a maximum length of 10 m.

Integrated Controller (-s)
Supported operation modes with the integrated LED controller

Pin 2 (Dim)

Operation mode

24 V

steady light 1)

1…10V

steady light with brightness control 2)

24 V

triggered light

GND

triggered flash light with max. 20 ms and

up-to 100 % more light intensity 3)

1) Pin 3 (Trigger) needs permanent 24 V to activate steady light mode 2) PWM with 3.8 kHz clock is used, recommended minimal camera exposure is 5 ms 3) Latency between trigger and LED light ON is about 20…30 µs, the maximum recom-
mended clock speed is 1 kHz, the maximum recommended duty cycle is 25 % and the minimum recommended flash time is 100 µs

Application Samples for (-s) controller

Steady light
24 VDC

1 Power

2 Dim

MBJ

LED light 3 Trigger

4 GND

Steady light with brightness control

24 VDC 24 VDC

10k

1 Power

2 Dim

MBJ

10k

LED light 3 Trigger

4 GND

Specification

SBL-0110 / SBL-0110-IP

SBL-0115 / SBL-0115-IP

SBL-0120 / SBL-0120-IP

SBL-0130 / SBL-0130-IP

SBL-0140 / SBL-0140-IP

SBL-0150 / SBL-0150-IP

Optical parameter

Luminous area (A x B) Light emission

10 mm x 100 mm

10 mm x 165 mm

10 mm x 200 mm

10 mm x 300 mm

10 mm x 400 mm

10 mm x 500 mm

barlight with direct light emission, additional foils for light polarisation, collimation and diffusion are available as accessories

Recommended use

used in various applications for bright field as well as dark field lighting

Recommended light working distance

10 mm – 150 mm

10 mm – 200 mm

10 mm – 200 mm

10 mm – 250 mm

10 mm – 250 mm

10 mm – 300 mm

Luminous Flux of white LEDs1)

460 lm

765 lm

920 lm

1380 lm

1840 lm

2300 lm

Radiant Power of red LEDs 1)

1350 mW

2250 mW

2700 mW

4060 mW

5410 mW

6760 mW

Radiant Power of IR LEDs 1)

650 mW

1080 mW

1300 mW

1950 mW

2600 mW

3250 mW

Electrical parameter

Available interfaces

-s with integrated LED Controller and 4 operation modes; -x with direct LED access (external LED control is required)

Uin for -s Version

24 VDC +/- 5 %

ULed(+) range for -x version 2)

WT / BE / YE: 17 … 20 VDC; GN: 20 … 23 VDC; RD: 12 … 15 VDC; IR: 9 … 12 VDC

Typical Power (-s version)

Steady light operation (white / red / IR)3)

3 W / 3 W / 2 W

6 W / 4 W / 3 W

6 W / 5 W / 4 W

9 W / 7 W / 5 W

11 W / 9 W / 6 W

14 W / 11 W / 8 W

During ON time at flashed light operation4)

8 W

13 W

15 W

18 W

25 W

31 W

Recommended LED current (-x version)

Steady light (100 % duty cycle)

150 mA (225 mA for IR)

250 mA (300 mA for IR)

300 mA (450 mA for IR)

450 mA (600 mA for IR)

600 mA (900 mA for IR)

750 mA (1125 mA for IR)

Flash light (50 % duty cycle, < 500 ms pulse)

300 mA (225 mA for IR)

500 mA (300 mA for IR)

600 mA (450 mA for IR)

900 mA (600 mA for IR)

1200 mA (900 mA for IR)

1500 mA (1125 mA for IR)

Flash light (25 % duty cycle, < 50 ms pulse)

450 mA (225 mA for IR)

750 mA (300 mA for IR)

900 mA (450 mA for IR)

1350 mA (600 mA for IR)

1800 mA (900 mA for IR)

2250 mA (1125 mA for IR)

Flash light (10 % duty cycle, < 5 ms pulse)

600 mA (450 mA for IR)

1000 mA (600 mA for IR)

1200 mA (900 mA for IR)

1800 mA (1200 mA for IR)

2400 mA (1800 mA for IR)

3000 mA (2250 mA for IR)

General parameter

Dimension (H x W x D)

18 mm x 110 mm x 20 mm

18 mm x 175 mm x 20 mm

18 mm x 210 mm x 20 mm

18 mm x 310 mm x 20 mm

18 mm x 410 mm x 20 mm

18 mm x 510 mm x 20 mm

Weight

90 g

120 g

150 g

230 g

300 g

370 g

Material

Black anodized aluminum housing with PMMA light cover

Connector

M8x1 socket, 4 pin, male (for pinning details refer to chart “Electrical Connection”)

Accessories

For cable, foil holder brackets, light manipulation foils and external LED controller: please check www.mbj-imaging.com

1) Values are approximate with a +/- 7 % tolerance. 2) Lower voltage value refers to steady light, higher voltage value refers to flash light, please see max. allowed current in the rows below. 3) Power for Blue / Yellow is comparable to White, Power for Green is approx. 1,2 times higher. 4) Triggered flash light with max. 20 ms and up to 100 % more light intensity, calculated for White.

Triggered light with NPN sinking output (inverted strobe signal, open collector)
24 VDC

2k2

from Camera/ PLC etc

10 mA

1 Power

2 Dim

MBJ

LED light 3 Trigger

4 GND

Flashed light with PNP sourcing

24 VDC from Camera/ PLC etc

24 VDC

10 mA

2k2

1 Power

2 Dim

MBJ

LED light 3 Trigger

4 GND
