Vaxcel H0267 Light Chandelier Matte Black And Natural Brass Instruction Manual

H0267 Light Chandelier Matte Black and Natural Brass

Product Information

The product is a light fixture that requires assembly and
installation. The package includes a mounting plate unit, hardware
package, and spare parts for re-order if damaged or missing. The
fixture can be adjusted to a length of 18-1/2 to 72-1/2 inches
using the provided rods. The maximum wattage allowed is 60W per
bulb, and the fixture requires five candelabra bulbs (not
included).

Product Usage Instructions

1. Turn off the power at the fuse or circuit box.
2. Attach the mounting plate unit (A) to the outlet box using two
   mounting screws (B).
3. Attach the threaded pipe to the coupling of the main fixture
   and secure it with a washer and hex nut. Adjust the length of the
   threaded pipe if necessary.
4. Attach the tube, metal pad, and metal cap onto the coupling by
   inserting the threaded pipe and secure it with the metal ring.
5. Thread the fixture wire through the lower rod, middle rod, and
   upper rod, and secure them onto each other using the threaded pipe.
   Use fewer rods if a shorter length is desired. Note: The length is
   adjustable from 18-1/2 to 72-1/2 inches.
6. Thread the fixture wire through the canopy kit and secure it to
   the set threaded pipe of the canopy kit.
7. Connect the smooth-coated wire (marked) from the fixture to the
   black wire from the power source. Connect the ribbed-coated wire
   (unmarked) from the fixture to the white wire from the power
   source. Attach the fixture ground wire to the mounting plate unit
   (A) with the green ground screw, then connect it to the house
   ground wire with a wire connector (C). Carefully put the wires back
   into the outlet box.
8. Attach the fixture to the mounting plate unit (A) and secure it
   with two bolt nuts (D).
9. Install five candelabra bulbs (not included). See relamping
   label at socket area or packaging for maximum wattage allowed.
10. For a vaulted or angled ceiling, angled mounting is
    recommended. Refer to Fig. 1 in the manual.
11. Turn on the power at the fuse or circuit box.

ASSEMBLY AND INSTALLATION INSTRUCTIONS

H0267
WARNING: TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE.

NOTES: 1. Before installing, consult local electrical codes for wiring and grounding requirements.

2. READ AND SAVE THESE INSTRUCTIONS.

Outlet Box

Hardware Package (included):

House Ground Wire Green Ground Screw

Mounting Plate Unit (A) Fixture Mounting Screw Mounting Screw (B)

Mounting Plate Unit (A) Mounting Screw (B)

Fixture Ground Wire Wire Connector (C)

Wire Connector (C)

Bolt Nut (D)

Installation Steps
Turn off the power at fuse or circuit box
1. Attach the mounting plate unit (A) to the outlet box by using two mounting screws (B).
2. Attach the threaded pipe to the coupling of the main fixture, secure it with a washer and hex nut. Adjust the length of the threaded pipe if necessary.
3. Attach the tube, metal pad and metal cap onto the coupling by inserting the threaded pipe, and then secure with the metal ring.
4. Rod Connections: a. Thread the fixture wire from the fixture through the lower rod, then secure the lower rod onto fixture using the threaded pipe. b. Thread the fixture wire through the middle rod and then secure the middle rod onto the lower rod using the threaded pipe. c. Thread the fixture wire through the upper rod, then secure the upper rod onto the middle rod using the threaded pipe. Note: Length adjustable from 18-1/2″ to 72-1/2″. Use fewer rods if shorter length is desired.
5. Thread the fixture wire through the canopy kit, then secure the rod assembly to the set threaded pipe of the canopy kit.

Metal Ring Metal Cap Metal Pad
Tube

Canopy Kit Bolt Nut (D) Threaded Pipe Upper Rod Threaded Pipe
Middle Rod
Threaded Pipe
Max.60W Type B Bulb (not included)

Threaded Pipe
Hex Nut Washer

Coupling Fixture

Finial

220331

6. Pull out the source wires from the outlet box. Make wire connections using wire connectors (C) as follows:

—Connect the smooth-coated wire (marked) from the fixture to the black wire from the power source.

—Connect the ribbed-coated wire (unmarked) from the fixture to the white wire from the power source.

—Attach the fixture ground wire to the mounting plate unit (A) with the green ground screw, then connect it to

the house ground wire with a wire connector (C).

Carefully put the wires back into the outlet box.

Fig. 1

7. Attach the fixture to the mounting plate unit (A), and then secure it with two bolt nuts (D).

Support Brace

8. Install 5 x 60W max. candelabra bulb (not included). See relamping label at socket area or packaging for maximum wattage allowed.
9. Angled mounting recommended for a vaulted or angled ceiling. (See Fig.1)
Turn on the power at fuse or circuit box

Outlet Box Canopy Coupling Kit

The following parts are available for re-order if damaged or missing.
Spare Parts List:

Mounting Plate Unit (A)

Mounting Screw (B) Wire Connector (C) Bolt Nut (D)

Mounting Hardware 6487MM (1 SET)

12″ Rod 3333RD

6″ Rod 3334RD

3″ Rod 3335RD

A: 18-1/2″~72-1/2″ B: 25″
A

B 220331
