PBH-350 Series Electromechanical Push Bar
Product Information
Product Name: Electromechanical Push Bar
Model: PBH-350 Series
Description: The PBH-350 Series
Electromechanical Push Bar is designed for use on emergency exit
doors. It provides a convenient means of escape by simply pushing
on a horizontal bar fitted across the width of a door. It also
features preload release capability that overcomes door preload
problems, such as air-conditioning pressure, changes in the
weather, warped doors, or doors with weather stripping.
Additional Features:
- PBH-350DE delayed egress exit device provides controlled egress
to prevent unauthorized exit. It sounds an audible alarm and stays
secure for 15 or 30 seconds, allowing time for personnel to
respond. - PBH-350LD features a large bi-color LED for clear indication
and easy operation in the dark. - Delayed egress functions (For PBH-350DE Only): Field selectable
nuisance delay, field selectable 15 or 30-second exit delay,
emergency signal input, manual reset input (key switch control),
door ajar alarm triggering input, built-in 95dB piezo buzzer.
Specifications:
| Model | Voltage | Current Draw | Output | Dimensions |
|---|---|---|---|---|
| PBH-350 | 12 or 24VDC | 285mA/12VDC Push bar 220mA/24VDC Latch status | 285mA/12VDC External alarm 220mA/24VDC 2nd fail-safe lock | Bar: 35 1/16 x 2 5/8 x 2 7/16 (890 x 66 x 61.5mm) Strike: 2 15/16 x 1 3/16 x 11/16 (75 x 30 x 17mm) |
| PBH-350DE | 12 or 24VDC | 285mA/12VDC Push bar 220mA/24VDC Latch status | N/A | Bar: 35 1/16 x 2 5/8 x 2 7/16 (890 x 66 x 61.5mm) Strike: 2 15/16 x 1 3/16 x 11/16 (75 x 30 x 17mm) |
| PBH-350LD | 12 or 24VDC | 285mA/12VDC Push bar 220mA/24VDC Latch status | Delayed Bi-Color LED Egress (Red/Green) | Bar: 35 1/16 x 2 5/8 x 2 7/16 (890 x 66 x 61.5mm) Strike: 2 15/16 x 1 3/16 x 11/16 (75 x 30 x 17mm) |
Warranty: The product is warranted against
defects in material and workmanship while used in normal service
for a period of 1 year from the date of sale to the original
client. The GEM policy is one of continual development and
improvement; therefore GEM reserves the right to change
specifications without notice.
Contact Information:
- Tel: +886-2-2267-7986
- Fax: +886-2-2267-9876
- Website: www.gianni.com.tw
- Email: [email protected]
Product Usage Instructions
To use the Electromechanical Push Bar, follow these steps:
- Locate the horizontal bar fitted across the width of the
emergency exit door. - Apply pressure by pushing on the bar to open the door.
Note: The PBH-350DE model provides controlled egress with
additional features. Refer to the product manual for specific
instructions on using the delayed egress functions.
Electromechanical Push Bar
PBH-350 Series
New Concept of Push to Exit Device
The PBH-350 Series Electromechanical Push Bar is designed for use on emergency exit doors. It provides a convenient means of escape by simply pushing on a horizontal bar fitted across the width of a door. It also features preload release capability that overcomes door preload problems, such as air-conditioning pressure, changes in the weather, warped doors or doors with weather stripping.
PBH-350DE Delayed Egress Electromechanical Push Bar
The PBH-350DE delayed egress exit device provides a controlled egress to prevent unauthorized exit. When armed, it sounds an audible alarm and stays secure for 15 or 30 seconds, allowing time for the personnel to respond. In an emergency, the device disarms and allows immediate egress.
PBH-350LD Electromechanical Push Bar features a large bi-color LED for clear indication and easy operation in the dark.
Delayed Egress Functions (For PBH-350DE Only)
Field selectable nuisance delay Field selectable 15 or 30 second exit delay Emergency signal input Manual reset input (key switch control) Door ajar alarm triggering input Built-in 95dB piezo buzzer
PBH-350 Series Specifications
Static strength 1,500 lbs (680Kg) Up to 500 lbs (227Kg) of preload Fail-safe mode Aluminum anodized push bar housing (US28)
Models PBH-350 PBH-350DE PBH-350LD
Voltage 12 or 24VDC 12 or 24VDC 12 or 24VDC
Current Draw
Output
285mA/12VDC Push bar 220mA/24VDC Latch status
285mA/12VDC External alarm 220mA/24VDC 2nd fail-safe lock
285mA/12VDC Push bar 220mA/24VDC Latch status
Delayed Bi-Color LED Egress (Red/Green)
Dimensions
Bar: 35 1/16″ x 2 5/8″ x 2 7/16″ (890 x 66 x 61.5mm)
Strike: 2 15/16″ x 1 3/16″ x 11/16″ (75 x 30 x 17mm)
Warranty The product is warranted against defects in material and workmanship while used in normal service for a period of 1 year from the date of sale to the original client. The GEM policy is one of continual development and improvement; therefore GEM reserves the right to change specifications without notice.
GIANNI INDUSTRIES, INC.
Tel: +886-2-2267-7986 Fax: +886-2-2267-9876 www.gianni.com.tw [email protected]
