HQSW-T 4-5 Terminal Clapping Jaw Lever Bypass
Talon Meter Mounting Equipment General Catalog and Product
Schedule
The Talon Meter Mounting Equipment is a set of products designed
to help mount and connect electric meters. The Utility
specifications may vary, so it is advised to consult the utility
prior to installation.
Product Schedule 431
The product schedule 431 includes Type HQSW/T 4-5 Terminal
Clamping Jaw Lever Bypass — Offset Style. It is used to bypass
power around the meter socket. The product comes with
Anti-Inversion Wire Insert (optional). There are other available
options such as alternate hasp material, aluminum enclosures, 5
terminal devices, and special labeling which can be obtained by
consulting the factory.
Product Dimensions
The product has a width of 16.0 inches and a hub opening that
varies based on the model. The HD (Height and Depth) varies based
on the model as well. The product has knockouts (inches) labeled
with #H59676.
Product Specifications
The product has a continuous amp rating of 320 and can be used
in OH (Overhead) or UG (Underground) service. The terminal
connector varies based on the model. The product has a number of
terminals ranging from 4 to 5. The 5th Jaw Kit is included in some
models or can be installed separately using H35815-5. The enclosure
catalog number and material varies based on the model.
Product Usage Instructions
Follow the below steps to use Talon Meter Mounting
Equipment:
- Select the appropriate Talon Meter Mounting Equipment based on
your requirements and consult with the utility prior to
installation. - Install the equipment by following the instructions provided in
the user manual. - Connect the electric meter to the equipment by following the
terminal connector specifications provided in the user manual. - Ensure that the Anti-Inversion Wire Insert is installed (if
applicable). - Consult the factory for other available options such as
alternate hasp material, aluminum enclosures, 5 terminal devices,
and special labeling.
Talon Meter Mounting Equipment General Catalog and Product Schedule
Utility specifications may vary. Consult utility prior to installation.
Product Schedule 431
Type HQSW/T 4-5 Terminal Clamping Jaw Lever Bypass — Offset Style
Common Features · 320A continuous duty rated · Offset design for easier UG wiring · Silver-brazed connections · 100% rated lever bypass w/clamping action
on meter · Factory installed lugs or 3/8″ stud connection · Steel or aluminum construction · Glass-filled polyester block construction · Track-resistant lexan shield · Plated copper current path
48104-02
Knockouts (inches):
AC: 1/4, 1/2 EE: 2, 2-1/2, 3 HD: Ø4.281 HUB 0P RX: Ø2.750 HUB 0P
#H59676
Anti-Inversion Wire Insert (optional)
Consult the factory for other available options such as, but not limited to alternate hasp material, aluminum enclosures, 5 terminal devices and special labeling.
Cover Style Ringless Ringless Ringless Ringless Ringless Ringless Ringless Ringless Ringless Ringless Ringless Ringless Ringless Ringless Ringless Ringless Ringless Ringless
Cont. Amp Rating 320 320 320 320 320 320 320 320 320 320 320 320 320 320 320 320 320 320
Service OH/UG OH/UG OH/UG UG UG UG OH/UG OH/UG OH/UG OH/UG OH/UG OH/UG OH/UG OH/UG OH/UG OH/UG OH/UG OH/UG
Terminal Connector
Line 3/8-24 Stud #4-600 kcmil 3/8-24 Stud 3/8-24 Stud #4-600 kcmil #4-600 kcmil 3/8-24 Stud #4-600 kcmil #4-600 kcmil 3/8-24 Stud #4-600 kcmil 3/8-24 Stud #6-350 kcmil (2) #4-350 kcmil (2) #4-350 kcmil #4-600 kcmil #4-600 kcmil #4-600 kcmil
Load 3/8-24 Stud #4-600 kcmil 3/8-24 Stud 3/8-24 Stud (2) #4-350 kcmil (2) #4-350 kcmil 3/8-24 Stud (2) #4-350 kcmil #4-600 kcmil 3/8-24 Stud (2) #4-350 kcmil 3/8-24 Stud (2) #4-350 kcmil (2) #4-350 kcmil (2) #4-350 kcmil #4-600 kcmil #4-600 kcmil (2) #4-500 kcmil
Dimensions (in.)
W 16.0 16.0 16.0 16.0 16.0 16.0 16.0 16.0 16.0 16.0 16.0 16.0 16.0 16.0 16.0 16.0 16.0 16.0
HD 20.0 5.0 20.0 5.0 20.0 5.0 31.0 5.0 31.0 5.0 31.0 5.0 31.0 5.0 31.0 5.0 31.0 5.0 31.0 5.0 31.0 5.0 31.0 5.0 31.0 5.0 31.0 5.0 31.0 5.0 31.0 5.0 31.0 5.0 31.0 5.0
Hub Opening HD Cl. Plate HD Cl. Plate HD Opening HD Cl. Plate HD Cl. Plate HD Cl. Plate HD Cl. Plate HD Cl. Plate 3″ Hub Inst. HD Cl. Plate HD Cl. Plate HD Cl. Plate HD Cl. Plate HD Cl. Plate HD Cl. Plate HD Cl. Plate HD Cl. Plate HD Cl. Plate
Barrel Lock KO Prov. N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A 7/8″ N/A N/A N/A N/A 7/8″ N/A N/A
No. of Term. 4 4 5 4 4 5 4 4 4 5 4 4 4 4 4 5 4 4
5th Jaw Kit H35815-5 H35815-5 Installed H35815-5 H35815-5 Installed H35815-5 H35815-5 H35815-5 Installed H35815-5 H35815-5 H35815-5 H35815-5 H35815-5 Installed H35815-5 H35815-5
Enclosure Catalog Number Material
44604-02 l
Steel
44604-82 al Steel
44605-036 kl Steel
48004-02RG; Steel
48004-82a; Steel
48005-82a; Steel
48104-02 k
Steel
48104-82 s
Steel
48144-82 a
Steel
48105-02FL k Steel
48104-82BP s Steel
48104-82WI
Steel
48104-8201 fk Steel
48104-8203 gk Steel
48104-8263 hk Steel
48105-83BU a Steel
48104-82TS ad Steel
48104-82TX jk Steel
Type HQ4SW HQ4SW HQ4SW HQ4SW HQ4SW HQ4SW HQ4SWT HQ4SWT HQ4SWT HQ5SWT HQ4SWT HQ4SWT HQ4SWT HQ4SWT HQ4SWT HQ5SWT HQ4SWT HQ4SWT
a 60162 lugs are also rated for (2) 2/0-250 kcmil. s 60162 line lugs, 56732 load side lugs. d Anti-inversion clip, 59676D, included. f 58490-1 line lugs and 56732-2 load lugs, 13/32″
opening on lugs.
g 56732-2 line and load lugs (13/32″ opening). h 56732 line and load lugs (9/16″ opening). j 60162 line lugs and 56732M load lugs. k Ground lug included. l HQSW (446 prefix) are not UL listed for OH applications. ; 480XX Series – UG only – meter moved up in device.
