STAND-TDML2A Universal Laptop Desk for Treadmill with Cup Holder and Phone Slot
Product Information: Universal Laptop Desk for Treadmill with
Cupholder & Phone Slot
The Universal Laptop Desk for Treadmill with Cupholder &
Phone Slot is a sturdy and functional desk that allows you to work
or play on your laptop while walking or running on a treadmill. The
desk comes with a cup holder and a phone slot for added
convenience. It has a weight capacity of 22lbs (9.98kg) and should
not be exceeded to avoid serious injury. The package contents
include a keyboard tray, connecting plates, phone slot, cup holder
bracket, cup holder, rubber pad, strap bracket, strap, and
screws.
Product Usage Instructions:
- Assemble the keyboard trays (A) using connecting plates (B)
with M5x12mm screws (S-A) and keyboard tray connector (I) with
M5x12mm screws (S-E). Tighten with a Phillips screwdriver. - Insert the phone slot (C) into the opening on the keyboard tray
(A). - Measure the treadmill handlebar distance, then attach rubber
pads (F) to the keyboard tray (A) using M5x14mm screws (S-D).
Tighten with a Phillips screwdriver. - Mount strap brackets (G) to the corresponding middle row holes
in keyboard tray (A) using M5x14mm screws (S-D) and a Phillips
screwdriver. Make sure to match the handlebar distance as closely
as possible. - Secure straps (H) to strap brackets (G).
- Assemble cup holder bracket (D) to cup holder (E) using M3x10mm
screws (S-B) and a Phillips screwdriver. Secure cup holder bracket
(D) to keyboard tray (A) using M5x10mm screws (S-C) and a Phillips
screwdriver. - Secure the tray assembly to the treadmill handlebars using
straps (H).
If any parts are received damaged or defective, please contact
the manufacturer for replacement parts. For more information or to
check out other VIVO products, visit their website at
www.vivo-us.com.
Universal Laptop Desk for Treadmill with Cupholder & Phone Slot
Instruction Manual
SKU: STAND-TDML2A
Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tdml2a
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
www.vivo-us.com Chat live with an agent!
309-278-5303
WARNING!
If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect assembly, or inappropriate use.
WARNING: CHOKING HAZARD
SMALL PARTS – NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
PACKAGE CONTENTS
A (x1) Keyboard Tray
B (x2) Connecting Plate
C (x1) Phone Slot
D (x1)
E (x1)
Cup Holder Bracket Cup Holder
F (x4) Rubber Pad
G (x2) Strap Bracket
H (x2) Strap
I (x1) Keyboard Tray
Connector
S-A (x8) M5x12mm Countersunk
Screw
S-B (x4) M3x10mm Screw
S-C (x3) M5x10mm Screw
S-D (x8)
S-E (x4)
M5x14mm Screw M5x12mm Screw
Phillips Screwdriver
DO NOT EXCEED WEIGHT CAPACITY.
Failure to do so may result in serious injury.
22lbs (9.98kg)
Toltal
ASSEMBLY STEPS
STEP 1
Assemble Keyboard Trays (A) using Connecting Plates (B) with M5x12mm Screws (S-A) and Keyboard Tray Connector (I) with M5x12mm Screws (S-E). Tighten with a Phillips screwdriver.
S-E I
S-A B
3lbs (1.4kg)
Cup Holder
A
STEP 2
Insert Phone Slot (C) into the opening on
C
Keyboard Tray (A).
A
2
STEP 3
Measure the treadmill handlebar distance, then attach Rubber Pads (F) to Keyboard Tray (A) using M5x14mm Screws (S-D). Tighten with a Phillips screwdriver.
A
S-D F
STEP 4
Making sure to match the handlebar distance as closely as possible, mount Strap Brackets (G) to the corresponding middle row holes in Keyboard Tray (A) using M5x14mm Screws (S-D) and a Phillips screwdriver.
S-D G
A
STEP 5
Secure Straps (H) to Strap Brackets (G).
H G
STEP 6
Assemble Cup Holder Bracket (D) to Cup Holder (E) using M3x10mm Screws (S-B) and a Phillips screwdriver. Secure Cup Holder Bracket (D) to Keyboard Tray (A) using M5x10mm Screws (S-C) and a Phillips Screwdriver.
D
S-C
A
E S-B
STEP 7
Secure the tray assembly to the treadmill handlebars using Straps (H).
H
3
Love your new VIVO setup and want to share? Tag us in your photo! @vivo_us
LAST UPDATED: 09/12/2022 REV1
