GFX-DIM Universal Dimmer
Product Information:
The Universal Dimmer is a device designed for controlling
horticultural lights. It allows users to adjust the dimming level
of the lights. The dimmer is compatible with various lighting
manufacturers and can be operated with or without an internet
connection. The package includes the Universal Dimmer, a screw
terminal adapter cable, a power adapter, and a quickstart
guide.
Safety Precautions:
- Always consult lighting manufacturer’s product documentation
before installing, servicing, or operating horticultural
lights. - Respect all locally applicable laws, codes, and
regulations. - Avoid staring at operating lights as they may emit hazardous
optical radiation, including invisible UV and IR light. Use proper
vision protection and light blocking protective clothing when
working near or below operating lights. - Take precautions to avoid electrical shock when servicing or
installing horticultural lights. Follow the safety precautions
provided by your lighting manufacturer and ensure AC power service
to lights is connected to (earth) ground.
What’s in the box:
- Universal Dimmer
- Screw terminal adapter cable
- Power Adapter
- Quickstart Guide
Product Usage Instructions:
Step 1: Plug in Dimmer
Only use the AC power adapter included with your Dimmer. If
waterproof power connection is required, use an IP67 power cable
available separately from GrowFlux.
Step 2: Connect Dimmer to Light(s)
Before servicing wiring, disconnect AC power from your lights.
Consult your lighting manufacturer’s documentation to verify proper
signal connections.
Connect the Dimmer to your light(s) using the supplied adapter
cable or dimming signal cabling (sold separately). Follow the
wiring diagram provided on the next page for the included
cable.
Unscrew the cable gland from the adapter cable, insert the
dimming signal cable through the seal, and connect the wires to the
internal terminals. Use a Philips screwdriver to secure the wires
in the screw terminals on the included cable. The cable gland seal
accepts wires with a diameter of 4mm to 6.5mm.
For most lights, connect the Violet wire to the copper terminal
(DIM +) and connect the Black/Gray/White wire to the silver
terminal (DIM -). Refer to your lighting manufacturer’s
documentation for specific instructions.
Step 3 (Only for Connected Control): Make Sure Your Access
Point is Powered On and Connected
If you have not set up your Access Point, follow the
instructions to add it to your account. Visit
growflux.com/access-point for more details.
Step 4 (Only for Connected Control): Invite the Dimmer to
GrowFlux Mesh
Open the GrowFlux App or web app at https://panel.growflux.com. If you
have multiple Access Points, select the desired one for
provisioning your device. Navigate to “Add New Devices” and follow
the steps on the interface.
Factory Reset:
To perform a factory reset, hold the up button while plugging in
the DC power cable to the device. Continue holding the up button
for about 5 seconds. The Network Status LED will begin flashing
red. Press and hold for 5 seconds while applying power.
FAQ:
Does the Dimmer work without an internet
connection?
Yes, the Universal Dimmer can be operated without an Access Point
using push-button control.
What about the buttons?
If the Universal Dimmer is not connected to a GrowFlux Mesh
network, the dimming level can be adjusted with push-button
control. The set light level will stay fixed indefinitely, even
through power cycling the Universal Dimmer.
Universal Dimmer
Safety Precautions
CAUTION. Always consult lighting manufacturer’s product documentation before installing, servicing, or operating horticultural lights. Respect all locally applicable laws, codes and regulations.
CAUTION. Possibly hazardous optical radiation, including invisible UV and IR light, emitted from horticultural lights. Do not stare at operating lights. Staring at operating lights may be harmful to the eye. Use proper vision protection when working near lights. Use light blocking protective clothing when working directly below operating lights.
1
Safety Precautions
DANGER. Risk of lethal or severe electrical shock when servicing or installing horticultural lights. Follow all safety precautions provided by your lighting manufacturer. Do not service wet wiring. Ensure AC power service to lights are connected to (earth) ground.
2
What’s in the box
Universal Dimmer
Screw terminal adapter cable
Power Adapter 3
Quickstart Guide
STEP 1
PLUG IN DIMMER
Only use the AC power adapter included with your Dimmer. Waterproof power connection to the Dimmer requires an IP67 power cable, available separately from GrowFlux.
4
STEP 2
CONNECT DIMMER TO LIGHT(S)
Before servicing wiring, disconnect AC power from your lights. Consult your lighting manufacturer’s documentation to verify proper signal connections.
Connect the Dimmer to your light(s) using the supplied adapter cable or dimming signal cabling, sold separately. See the next page for a wiring diagram for the included cable.
Unscrew cable gland from adapter cable, insert dimming signal cable through seal, and connect wires to internal terminals. A Philips screwdriver is required to secure wires in screw terminals on the included cable. The cable gland seal accepts wires 4mm to 6.5mm diameter.
5
STEP 2
DIM +
DIM Copper colored terminal: +10V (DIM +) Silver colored terminal: 0V (DIM -)
For most lights: Connect Violet wire to copper terminal Connect Black / Gray / White wire to silver terminal
Consult your lighting manufacturer’s documentation
6
STEP 2
CONNECT AND TEST YOUR LIGHTS
Unused wires on your light should be trimmed or isolated; ensure that unused wires are not short circuited. Up to 50 lights can be connected to the Universal Dimmer. Use Universal Dimmer signal tees and extension cables to daisy chain dimming signal to many lights, sold separately. Test dimming functionality with buttons on Universal Dimmer before proceeding to the next steps for connected control. The buttons should turn your light off, then step through 5 intensity settings in 20% increments to 100% output.
7
STEP 3 ONLY FOR CONNECTED CONTROL
MAKE SURE YOUR ACCESS POINT IS POWERED ON AND CONNECTED.
If you have not set up your Access Point, follow the instructions to add the Access Point to your account. See growflux.com/access-point
8
STEP 4 ONLY FOR CONNECTED CONTROL
INVITE THE DIMMER TO GROWFLUX MESH
Open the GrowFlux App or web app (located at https://panel.growflux.com)
If you have multiple Access Points, first select the Access Point on which you would like to provision your device.
Navigate to `Add New Devices’. Follow the steps on the interface.
9
Factory Reset
Hold the up button while plugging in the DC power cable to the device. Continue holding the up button for about 5 seconds. The Network Status LED will begin flashing red.
Press and hold for 5 seconds while applying power
10
FAQ
IS THE UNIVERSAL DIMMER COMPATIBLE WITH MY GROW LIGHT? The Universal dimmer is compatible with any light that accepts analog 0 10V dimming. Most horticultural lights support dim-to-off; this feature is supported by the Universal Dimmer. Pick from a library of compatible lights in the GrowFlux dashboard to estimate the output in horticultural units (micromoles), including photosynthetic photon flux density (PPFD), daily light integral (DLI), and power consumption. If your light is not already in the light library, input the light’s wattage and PPFD measurements to create a custom light model.
11
FAQ
HOW CAN I GET ACCURATE PPFD CALCULATIONS IN THE INTERFACE? PPFD measurements taken at the canopy level can be entered into the interface to calculate PPFD within Light Formulas. See the PAR Calculation Guide at growflux.com/dimmer for more information or ask your lighting designer for these values. IS THE DIMMER WATERPROOF? When powered with the included AC adapter with a 2.5mm x 5.5mm barrel jack connector, the Universal Dimmer is NOT waterproof. When connected with an IP67 power cable (available from GrowFlux), the Universal Dimmer is fully waterproof. Contact GrowFlux or your authorized distributor for a waterproof power cable.
12
FAQ
DOES THE DIMMER WORK WITHOUT AN INTERNET CONNECTION?
Yes – the Universal Dimmer can be operated without an Access Point with push-button control.
WHAT ABOUT THE BUTTONS?
If the Universal Dimmer is not connected to a GrowFlux Mesh network, dimming level can be adjusted with push-button control. The set light level will stay fixed indefinitely, even through power cycling the Universal Dimmer.
If the Universal Dimmer is connected to a GrowFlux Mesh network, the buttons are disabled. Buttons are enabled if the Universal Dimmer loses Mesh connectivity.
13
FAQ
WHAT DOES THE NETWORK LED COLOR MEAN?
Blinking red Upon power-on. Dimmer is not bonded to an Access Point
Blinking blue Upon power-on. Dimmer is currently bonded to an Access Point and is attempting to connect
Green Dimmer has successfully connected to Access Point
Blinking Yellow Dimmer could not connect to Access Point. Try moving the Dimmer closer to the Access Point and power cycle the device to establish the GrowFlux Mesh connection for the first time. Once the light turns green, move the Dimmer to your desired location.
White Dimmer has received invitation and is bonding to Access Point
14
Support
See our self help center at support.growflux.com
Email: [email protected] Phone: (215) 337-3999 Hours: M-F 9am-5pm EST
More resources at growflux.com/dimmer
print rev 1.3
15
