Pump Oil and Saver, Fittings and O-Rings

Product Information:

Pressure Washers

A pressure washer is a cleaning device that uses high-pressure
water to remove dirt and grime from surfaces. It is designed to
clean outdoor surfaces such as patios, driveways, decks, and
vehicles.

Pump Oil

Pump oil is a specially designed oil for pressure washer pumps.
It is formulated to keep pumps cooler than regular oil and is
suitable for all climates. It contains rust and corrosion
additives, anti-wear additives, foam suppressant, and dispersant
for system cleanliness. The AW-4085-0016 pump oil comes in 1-pint
size with a convenient pour spout and resealable cap. It is sold in
cases of 6 or 12.

Pump Saver

Pump saver is a product that provides longer pump life, prevents
harmful build-up of hard water mineral deposits, preserves seals
and pistons, and protects against freezing for safe, cold weather
storage. It is suitable for use with all pressure washers and comes
in a 16 oz. bottle. The AW-4070-0004 pump saver is sold in cases of
4.

Pump Winterizing Blowout Fitting

The pump winterizing blowout fitting is designed to allow you to
use an air chuck to clear the pump of any water remaining in the
system to avoid damage from freezing. It is suitable for use with
all pressure washers and has the product code AW-4070-0005.

High Temperature O-Rings

High temperature O-rings are used to ensure a tight fit and
prevent leaks with quick connect sockets. The 3/8-inch high temp
silicon O-ring with product code 25-0594 fits quick connect socket
17-0004 on hot water outlets, for hoses. The 1/4-inch high temp
silicon O-ring with product code 25-0595 fits quick connect socket
17-0028 on wands.

Long Range Chemical Nozzle

The long-range chemical nozzle is a quick-connect nozzle that
attaches to the end of the wand. It operates at low pressure and
has a range of 30-feet while drawing chemical. The product code for
the long-range chemical nozzle is 18-0373.

Digital Hour Meter/Tachometer

The digital hour meter/tachometer updates every 3 seconds and
measures RPM up to 9,900. The product code for the digital hour
meter/tachometer is 32-0416.

Product Usage Instructions:

Before using the pressure washer, ensure that all accessories,
fittings, and O-rings are properly installed and in good
condition.

Pump Oil Usage Instructions:

1. Turn off the pressure washer and let it cool down.
2. Locate the pump oil cap and remove it.
3. Pour the pump oil into the reservoir using a funnel to avoid
   spills.
4. Replace the pump oil cap and tighten it securely.

Pump Saver Usage Instructions:

1. Turn off the pressure washer and let it cool down.
2. Disconnect the water supply hose from the pump inlet.
3. Reconnect the water supply hose to the pump inlet.

Pump Winterizing Blowout Fitting Usage Instructions:

1. Turn off the pressure washer and let it cool down.
2. Disconnect the water supply hose from the pump inlet.
3. Remove the high-pressure hose from the pump outlet.
4. Screw the pump winterizing blowout fitting into the pump
   outlet.
5. Connect an air chuck to the fitting and blow out any remaining
   water from the system.
6. Remove the pump winterizing blowout fitting and replace the
   high-pressure hose.
7. Reconnect the water supply hose to the pump inlet.

High Temperature O-Rings Usage Instructions:

1. Turn off the pressure washer and let it cool down.
2. Locate the quick connect socket on the hot water outlet or
   wand.
3. Remove the old O-ring and replace it with a new high
   temperature O-ring.
4. Ensure that the O-ring is properly seated and that there are no
   leaks.

Long Range Chemical Nozzle Usage Instructions:

1. Attach the long-range chemical nozzle to the end of the
   wand.
2. Fill the chemical container with the desired cleaning
   solution.
3. Turn on the pressure washer and adjust the pressure to
   low.
4. Squeeze the trigger to draw in the cleaning solution and apply
   it to the surface to be cleaned.

Digital Hour Meter/Tachometer Usage Instructions:

1. Attach the digital hour meter/tachometer to the spark plug wire
   of the engine.
2. Turn on the pressure washer and allow it to run for a few
   minutes.
3. Read the RPM on the display of the hour meter/tachometer.

PRESSURE WASHERS

Pump Oil and Saver, Fittings and O-Rings

Pressure Washer
Accessories

Pump Oil
Specially designed for pressure washer pumps, it will keep pumps cooler than regular oil and is suitable for all climates.
AW-4085-0016 1-pint, 6 or 12 per case Convenient pour spout and resealable cap Contains rust and corrosion additives, anti-wear
additives, foam suppressant and dispersant for system cleanliness

Pump Saver
Provides longer pump life, prevents harmful build-up of hard water mineral deposits, preserves seals and pistons and protects against freezing for safe, cold weather storage.
AW-4070-0004 16 oz. bottle, 4 per case For use with all pressure washers Protects pressure washer when not in use

Pump Winterizing Blowout Fitting
This fitting allows you to use an air chuck to clear the pump of any water remaining in the system to avoid damage from freezing. AW-4070-0005 For use with all pressure washers
High Temperature O-Rings
O-rings ensure a tight fit and prevent leaks with quick connect sockets. 25-0594 3/8-inch high temp silicon Fits quick connect socket, 17-0004,
on hot water outlets, for hoses 25-0595 1/4-inch high temp silicon Fits quick connect socket, 17-0028, on wands

Long Range Chemical Nozzle
18-0373 Quick connects to the end of the wand Low pressure Has a range of 30-feet while drawing chemical
Digital Hour Meter/Tachometer
32-0416 Updates every 3 seconds RPM to 9,900
