CM-4200-0MMB Cold Water Pressure Washer
Product Information
The CM-4200-0MMB is a professional high pressure, cold water
pressure washer designed for quality and performance. It has a 420
cc Mi-T-M engine with a displacement of 3.4 liters and a maximum
no-load RPM of 3700 (+/- 100). The pump uses Mi-T-M pump oil
#AW-4085-0016 and has a capacity of 16 oz. The nozzle size is #3.5
and the unit has a water volume of 3.5 GPM. The pressure washer
weighs 139 lbs and has dimensions of 25.83Lx22.5Wx25.25H
inches.
Product Usage Instructions
Before attempting to use or repair the pressure washer, read and
follow the safety warnings listed in the user manual. Only use
genuine manufacturer parts for repairs to avoid hazardous operating
conditions and voiding the warranty. When servicing the unit, turn
it off, relieve the water pressure, and allow it to cool down. Do
not make repairs while the unit is running.
To use the pressure washer, start by filling the fuel tank with
unleaded gasoline with a minimum octane rating of 86 and a capacity
of 1.8 gallons. Then, fill the pump with 16 oz of Mi-T-M pump oil
#AW-4085-0016. Connect the high pressure nozzle to the spray wand
and connect the spray wand to the pressure hose. Connect the
pressure hose to the unit’s water inlet. Turn on the water supply
and squeeze the trigger on the spray wand to release any trapped
air in the system.
To start the engine, move the choke lever to the “Choke”
position and pull the recoil starter cord until the engine starts.
Once it starts, move the choke lever to the “Run” position. Adjust
the spray wand to the desired pressure and begin cleaning.
After use, shut off the unit and release trapped pressure before
leaving. Do not leave the pressurized unit unattended.
PARTS LIST FOR
CM-4200-0MMB
(AFTER SERIAL #11390468)
Displacement: Pump Oil Grade: Pump Oil Capacity: Nozzle Size:
420 cc Mi-T-M Pump Oil #AW-4085-0016 16 oz. # 3.5
©Copyright 2015, Mi-T-M
1
EX-1019-110722
This Parts Listing has been compiled for your benefit. You can be assured your cold water pressure washer was constructed and designed with quality and performance in mind. Each component has been rigorously tested to ensure the highest level of quality.
The contents of this Parts Listing are based on the latest product information available at the time of publication. Mi-T-M reserves the right to make changes in price, color, materials, equipment, specifications or models at any time without notice.
WARNING
THIS IS A PROFESSIONAL HIGH PRESSURE, COLD WATER PRESSURE WASHER. CAUTION SHOULD BE OBSERVED WHEN USING OR REPAIRING THIS UNIT! READ AND FOLLOW THE SAFETY WARNINGS LISTED BELOW BEFORE ATTEMPTING ANY REPAIRS ON THIS PRESSURE WASHER!
SAFETY WARNINGS
1.
NEVER alter or modify the equipment. Be sure any accessory items and system components being used will withstand the pressure developed. Use
only genuine manufacturer parts for repair of your pressure washer. Failure to do so can cause hazardous operating conditions and will VOID warranty.
2.
NEVER make adjustments on machinery while the unit is connected to the engine without first removing the ignition cable from the spark plug.
Turning over the machinery by hand during adjustment or cleaning might start the engine and machinery with it, causing serious injury to the operator.
3.
Know how to stop and bleed pressures quickly. Be thoroughly familiar with controls.
4.
Before servicing the unit, turn unit off, relieve the water pressure and allow the unit to cool down. Do not make repairs while the unit is running.
Service in a clean, dry, flat area. Block the wheels to prevent the unit from moving. Be especially careful to properly dispose of any flammable materials.
5.
After testing the machine, DO NOT leave the pressurized unit unattended. Shut off the unit and release trapped pressure before leaving.
Table of Contents
SPECIFICATIONS…………………………………………………………………………………………………………………………………………………………………………………..3 NOTES ………………………………………………………………………………………………………………………………………………………………………………………………….4 NOTES ………………………………………………………………………………………………………………………………………………………………………………………………….5 FRAME ASSEMBLY (AFTER SERIAL #11390468) …………………………………………………………………………………………………………………………………….6 PUMP ASSEMBLY (3-0475) …………………………………………………………………………………………………………………………………………………………………….8 UNLOADER ASSEMBLY (8-0635) ……………………………………………………………………………………………………………………………………………………………10
©Copyright 2015, Mi-T-M
2
EX-1019-110722
SPECIFICATIONS
MODEL NUMBER Operating Pressure (PSI/Bar): High Pressure Nozzle: Water Volume (GPM/lpm): Engine: Displacement (cc) Engine Type Oil Type Oil Capacity (oz./liters) Fuel Type Fuel Capacity (gallon/ liters) Starting Maximum No Load RPM Pump: Oil Type Oil Capacity (oz./liters) Plungers Manifold Valves Unloader Detergent Injector Unit Net Weight (lbs/Kg) Unit Shipping Weight (lbs/Kg) Unit Net Dimension (in/cm) Unit Shipping Dimension (in/cm)
CM-4200-0MMB 4200 / 289.6 3.5 3.4 / 12.9 Mi-T-M Engine 420 cc
4 Stroke, Overhead Valve, Single Cylinder SAE10W-30 37.1 / 1.1
Unleaded Gasoline 86 Octane Minimum 1.8 / 6.7 Recoil
3700 (+/- 100) RPM Direct Driven, Oil Bath, Triplex Piston
Mi-T-M Pump Oil #AW-4085-0016 16 / 0.47 Ceramic
Forged Brass Stainless Steel
Preset Low pressure downstream from pump
139 / 63 150 / 68 25.83Lx22.5Wx25.25H/ 65.61Lx57.15Wx64.13H 32Lx22.625Wx27.5H/ 81.28Lx57.47Wx69.85H
©Copyright 2015, Mi-T-M
3
EX-1019-110722
DATE 10/18/22
SERIAL NUMBER #11390468
NOTES
REASON FOR CHANGE CHANGED PUMP FROM 3-0391 TO 3-0475
©Copyright 2015, Mi-T-M
4
EX-1019-110722
NOTES
©Copyright 2015, Mi-T-M
5
EX-1019-110722
CM-4200-0MMB 101822JRC
1 2 3
©Copyright 2015, Mi-T-M
FRAME ASSEMBLY (AFTER SERIAL #11390468)
37 36 35 34 38
33
32
31
29 28 27 26 25
30
4 5 6 7 8
24 23 22 21 20
19 18 17 15 16
9 10 11 12 13 14
6
EX-1019-110722
©Copyright 2015, Mi-T-M
ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 –
FRAME ASSEMBLY TITLE DECAL DECAL – WARNING/CAUTION/OPERATION (SEE 71-1049) HANDLE FRAME DECAL – MADE IN USA NOZZLE NOZZLE NOZZLE GROMMET LOCKNUT ISOLATOR BOLT DECAL – SILVER STICKER DECAL- MOBILE PRO WHEEL LOCKNUT PUMP KEY BOLT WASHER LOCKNUT DECAL – REWIND 420CC (SEE 71-1049) DECAL – RISK OF FIRE (SEE 71-1049) DECAL – RISK OF BURNS (SEE 71-1049) ENGINE – 50 STATE DECAL (SEE 71-1049) WASHER LOCKWASHER BOLT DETERGENT HOSE HOSE ASSEMBLY QUICK CONNECT HOSE ASSEMBLY QUICK CONNECT SOCKET O-RING O-RING DECAL – RISK OF INJECTION (SEE 71-1049) LANCE ASSEMBLY GUN & WAND – 4000 PSI QUICK CONNECT DECAL SET
CM-4200-0MMB 101822JRC
PART #
QTY
34-3228
1
N/A
1
7-0276A18
1
5-0254A53
1
34-3553
1
18-0386
1
18-0393
1
18-0395
1
33-0001
5
30-0157
6
14-0008
2
27-0068
6
N/A
1
34-3570
1
14-0161
2
30-0117
2
3-0475
1
43-0078
1
27-0121
4
28-0023
8
30-0159
4
34-2865
1
N/A
1
N/A
1
1-0199
1
N/A
1
28-0022
4
29-0008
4
27-0118
4
19-0233
1
15-0270
1
17-0006
1
N/A
1
17-0004
1
25-0123
1
25-0122
1
N/A
1
16-0366
1
16-0441
1
17-0074
1
71-1049
1
7
EX-1019-110722
PUMP ASSEMBLY (3-0475)
TORQUE SPEC.
ITEM #
FT-LBS
NM
1
11.1
15
16
7.4
10
22
18.4
25
75
11.1
15
77
18.4
25
3-0475 091422
©Copyright 2015, Mi-T-M
8
EX-1019-110722
©Copyright 2015, Mi-T-M
ITEM 1 2 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 71 72 73 74 75 76 77 78 79 80 81 82
PUMP ASSEMBLY DESCRIPTION BOLT FLANGE W/SIGHT GLASS O-RING SNAP RING BALL BEARING CRANKSHAFT CRANKCASE O-RING CRANKCASE – BACK COVER O-RING OIL DRAIN PLUG BOLT OIL CAP NEEDLE BEARING O-RING MOUNTING FLANGE OIL SEAL BOLT OIL SEAL RETAINER RING O-RING (SEE KIT 70-0501) LOW PRESSURE SEAL (SEE KIT 70-0501) INTERMEDIATE SEAL RETAINER (SEE KIT 70-0501) COMPACTION FLAKE HIGH PRESSURE SEAL (SEE KIT 70-0501) SUPPORT RING (SEE KIT 70-0501) CONNECTING ROD PISTON – WRIST PIN PISTON – CERAMIC COATED O-RING – RETAINING RING MANIFOLD HEAD PLUG THERMAL RELIEF SERRATED WASHER BOLT LOCKWASHER BOLT O-RING (SEE KIT 70-0759) VALVE ASSEMBLY (SEE KIT 70-0759) O-RING VALVE PLUG UNLOADER
PART # 27-8431 46-1597 25-0634 46-1596 48-0102
N/A N/A 25-0604 46-1594 25-0606 39-0376 27-8401 46-1593 48-0096 25-0603 46-1892 26-0192 27-8432 46-1313 46-1312 SEE KIT SEE KIT 46-1311 N/A SEE KIT SEE KIT 46-1595 46-1505 46-1504 25-0747 46-1893 39-0102 22-0005 28-0203 27-8875 29-0154 27-8439 SEE KIT SEE KIT 25-0622 39-0422 8-0635
3-0475 091422
QTY 4 1 1 1 1 1 1 1 1 1 1 6 1 1 1 1 1 4 3 3 3 3 3 3 3 3 3 3 3 3 1 1 1 4 4 4 4 6 6 6 6 1
KIT # 70-0501 70-0759
DESCRIPTION KIT – HIGH PRESSURE SEAL KIT KIT – VALVES W/O-RINGS
ITEMS 25, 26, 27, 29, 30
78 & 79
9
# OF ASSEMBLIES 3 6
# OF CYLENDERS 3 3
EX-1019-110722
8-0635 080520
©Copyright 2015, Mi-T-M
UNLOADER ASSEMBLY (8-0635)
1
LOCTITE SPECIFICATIONS
POSITION
LOCTITE
21
BLUE LOCTITE 542
39
BLUE LOCTITE 542
44
BLUE LOCTITE 542
45 46 47 48 27 49 50
44
43
42
41
40
39
38 37 36
10
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
29 28 27 26 25 24 30 31 32 33 34 35
EX-1019-110722
ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26
DESCRIPTION
SECURING PIN
(SEE KIT 70-0659)
CAP
(SEE KIT 70-0659)
BOLT
(SEE KIT 70-0659)
WASHER
(SEE KIT 70-0659)
KNOB
(SEE KIT 70-0659)
KNOB
(SEE KIT 70-0659)
SPRING SEAT
(SEE KIT 70-0659)
SPRING
(SEE KIT 70-0659)
SPRING SEAT
(SEE KIT 70-0659)
VALVE ROD
(SEE KIT 70-0659)
O-RING
(SEE KIT 70-0659)
SUPPORT RING
(SEE KIT 70-0659)
JAM NUT
(SEE KIT 70-0659)
SET SCREW
(SEE KIT 70-0659)
UNLOADER VALVE BODY (SEE KIT 70-0659)
O-RING
(SEE KIT 70-0659)
O-RING
(SEE KIT 70-0659)
SUPPORT RING
(SEE KIT 70-0659)
O-RING
(SEE KIT 70-0659)
BY PASS JET UNLOADER (SEE KIT 70-0659)
BULLET
(SEE KIT 70-0659)
O-RING
(SEE KIT 70-0659)
VALVE SEAT
(SEE KIT 70-0659)
PLUG
(SEE KIT 70-0658)
O-RING
(SEE KIT 70-0658)
SPRING BASE
(SEE KIT 70-0658)
PART# 46-1602
7-0260 27-8431 28-0003
7-0259 SEE KIT SEE KIT SEE KIT SEE KIT SEE KIT 25-0651 SEE KIT SEE KIT 8-0479 SEE KIT 25-0652 25-0163 SEE KIT 25-0655 SEE KIT SEE KIT 25-0656 SEE KIT 39-0379 25-0691 46-1603
UNLOADER ASSEMBLY
QTY
ITEM
2
27
1
28
1
29
1
30
1
31
1
32
1
33
1
34
1
35
1
N/A
1
36
1
37
1
38
1
39
1
40
1
41
1
42
1
43
1
44
1
45
1
46
1
47
1
48
1
49
1
50
1
DESCRIPTION
O-RING (SEE KIT 70-0500 OR 70-0658)
SPRING
(SEE KIT 70-0658)
VALVE HOUSING
O-RING
O-RING
INLET BANJO BOLT
O-RING
BY PASS HOUSING
O-RING
GARDEN HOSE ASSY.
INLET CONNECTOR (SEE KIT 23-0095)
SWIVEL NUT
(SEE KIT 23-0095)
FILTER
(SEE KIT 23-0095)
HOSE BARB
(SEE KIT 70-0499)
O-RING (SEE KIT 70-0293 OR 70-0499)
BALL (SEE KIT 70-0293 OR 70-0499)
SPRING (SEE KIT 70-0293 OR 70-0499)
O-RING
QC ADAPTER
(SEE KIT 70-0499)
OUTLET CONNECTOR
O-RING
SPRING
(SEE KIT 70-0500)
CHECKING VALVE (SEE KIT 70-0500)
OUTLET BANJO BOLT
O-RING
8-0635 080520 CH
PART# 25-0690 46-1604 46-1619 25-0664 25-0684
8-0595 25-0602 46-1620 25-0654 23-0095 SEE KIT SEE KIT 19-0001 46-0869 SEE KIT SEE KIT SEE KIT 25-0123 SEE KIT 46-1389 25-0663 SEE KIT SEE KIT
8-0594 25-0169
QTY 2 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
KIT # 23-0095 70-0293 70-0499 70-0500 70-0658 70-0659
REPLACEMENT KITS DESCRIPTION KIT – GARDEN HOSE INLET ASSY KIT – INJECTOR REPAIR KIT – OUTLET QC W/CHEM INJ KIT – NON-RETURN VALVE KIT – EZ START KIT – UNLOADER REBUILD
ITEMS 36-38 40-42 39-42, 44 47-48, 27 24-28 1-23
# OF ASSEMBLIES 1 1
1, 1 1 1 1
©Copyright 2015, Mi-T-M
11
EX-1019-110722
©Copyright 2015, Mi-T-M
Manufactured by Mi-T-M 50 MI-T-M Drive, Peosta IA 52068 563-556-7484/ Fax 563-556-1235
