MPND-06005-DEL MAUVO Canyon LED Outdoor Medium Pendant
Product Information
The Mauvo Canyon LED Outdoor Medium Pendant is a product from
Home Decorators Collection. The pendant light is designed for
outdoor use and provides efficient lighting with its LED
technology. It comes with a warranty and customer support from the
manufacturer.
Product Usage Instructions
Pre-Installation
Before installing the pendant light, inspect the wire insulation
for any cuts, abrasions, or exposed copper that may have resulted
during shipping. If there is a defect in the wire, do not attempt
installation and call Home Decorators Collection Customer Service
at 1-800-986-3460.
Installation
Refer to the Planning Installation section of the manual to plan
the installation of the pendant light. Ensure that you have all the
necessary tools required for installation. The hardware needed for
installation is included in the package contents.
Operation
After installation, turn on the circuit breaker or replace the
fuse at the fuse box. The pendant light comes with LED technology
that provides efficient lighting. Refer to the Care and Cleaning
section of the manual for maintenance tips.
Troubleshooting
If you have any problems or questions regarding the pendant
light, call Home Decorators Collection Customer Service at
1-800-986-3460.
Safety Information
Refer to the Safety Information section of the manual for safety
precautions when using the pendant light.
Warranty
The pendant light comes with a warranty that applies only to the
original consumer purchaser and only to products used in normal use
and service. The manufacturer’s obligation is to repair or replace
the product if found to be defective. Refer to the Warranty section
of the manual for more information.
Item #1007198178 Model #MPND-06005-DEL
USE AND CARE GUIDE
MAUVO CANYON LED OUTDOOR MEDIUM PENDANT
Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service
8 a.m. – 7 p.m., EST, Monday Friday, 9 a.m. 6 p.m., EST, Saturday 1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Home Decorators Collection!
Table of Contents
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Pre-Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Planning Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Hardware Included. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Care and Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Safety Information
questions.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for
help.
FCC Responsible Party Name: Bel Air Lighting Address: 28104 Witherspoon Pkwy. Valencia, CA 91355 Telephone Number: 1-800-446-9092
Warranty
CAUTION: Inspect the wire insulation for any cuts, abrasions, or exposed copper that may have resulted during shipping. If there is a defect in the wire, do not attempt installation. Please call our Customer Service Team at 1-800-986-3460.
WARNING:
turning off the circuit breaker or by removing the fuse at the fuse box.
date of purchase. This warranty applies only to the original consumer purchaser and only to products used in normal use and service. If this product is found to be defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the
alterations, neglect, or mishandling. This warranty shall not apply to any product that is found to have been improperly installed, set-up, or used in any way not in accordance with the instructions supplied with the product. This warranty shall not apply to a failure of the product as a result of an accident, misuse, abuse, negligence, alteration, faulty installation, or any other failure not relating to faulty material
considered normal wear and tear. The manufacturer does not warrant and specially disclaims any warranty, whether express or implied,
shall not be liable for any consequential or incidental loss or damage, including but not limited to any labor / expense costs involved in the replacement or repair of said product. Contact the Customer Service Team at 1-800-986-3460 or visit www.homedepot.com/homedecorators.
2
Pre-Installation
PLANNING INSTALLATION
Read all instructions before installation. To avoid damaging this product, assemble it on a soft, non-abrasive surface, such as carpet or cardboard. Keep your receipt and these instructions for proof of purchase.
TOOLS REQUIRED
Ladder
Safety goggles
Electrical tape
Phillips screwdriver
Flat blade screwdriver
Pliers
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Wire strippers
Silicone sealant
AA
BB
Part Description AA Mounting bracket BB Mounting screw CC Wire nut
CC
Quantity 1 2 3
3
HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Pre-Installation (continued)
PACKAGE CONTENTS
A
B
C
Part Description A B Chain (w/ quick connector) C Canopy
Quantity 1 1 1
4
Installation
1
Attach the mounting unit (AA) to the junction box (not included) with the mounting screws (BB) and remove the pre-installed screw collar ring.
Place the canopy (C) over the pre-installed screw collar loop on the mounting unit (AA). Turn the screw collar ring until 1/2 of the screw collar loop threads are exposed.
Secure the chain (B) to the screw collar loop on the
Lower the screw collar ring and canopy (C) over the chain (B). Weave the electrical wires, ground wires through the chain (B), canopy (C) and the center of the mounting unit (AA).
NOTE: Ensure the quick connector is fully closed when installing the chain.
2 Making the electrical connections
mounting unit (AA) by securing it with the preinstalled ground screw.
Connect the black to black (power), the white to white (neutral) and copper wire to ground wire with the wire
NOTE: color,attach the smooth wire with H markings or letters to the black (positive) wire and the ribbed wire with N markings to the white (neutral) wire.
3 Securing the light fixture
Place the canopy (C) over the pre-installed screw collar loop on the mounting unit (AA). Screw on the screw collar ring
CAUTION: To avoid any waterproofing problems, please make sure the light fixture fits the mounting surface perfectly during installation and use silicone sealant around the canopy for better sealing after installation.
AA BB
B C
C
AA B CC
C
5
HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Operation
1
Turn the light switch on to activate the fixture.
If it is daylight, the fixture will not illuminate. To test the fixture, cover the photocell with electrical tape. Once you confirm the fixture illuminates, remove the electrical tape.
If it is daylight, the fixture may not illuminate with the electrical tape over the photocell, as the photocell can be sensitive. Wait until nighttime to confirm the fixture illuminates.
NOTE: Position the photocell fixture so that the light from the any other fixture or any other light does not shine directly onto the “eye,” as this will interfere with the normal operation of the photocell fixture.
Care and Cleaning
Clean the lamp with a soft, dry cloth. Do not use any cleaners with chemicals, solvents, or harsh abrasives.
Troubleshooting
Problem The bulb will not light
The fuse blows or circuit breaker trips when the light is turned on.
Possible Cause The power is off. There is a faulty wire connection. The circuit breaker is off. There are crossed wires or the power wire is grounding out.
Possible Cause Ensure the power supply is On. Check the wiring. Ensure the circuit breaker is in the ON position. Check the wire connections.
1-800-986-3460.
6
Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service
8 a.m. 7 p.m., EST, Monday Friday, 9 a.m. 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
Retain this manual for future use.
