Home Decorators Collection Pt-06005-del Mauvo Canyon Led Outdoor Post Lantern User Guide (+ PDF)

The Mauvo Canyon LED Outdoor Post Lantern is a product of Home
Decorators Collection. The product model number is PT-06005-DEL,
and the item number is 1007260749. This outdoor post lantern is
designed to enhance the look of your home while providing
illumination for outdoor spaces. The product comes with a warranty
that covers repair or replacement in case of defects.

Product Usage Instructions

Pre-Installation

Before installing the Mauvo Canyon LED Outdoor Post Lantern,
inspect the wire insulation for any cuts, abrasions, or exposed
copper that may have resulted during shipping. If there is a defect
in the wire, do not attempt installation. Please call customer
service at 1-800-986-3460.

Planning Installation

Plan the installation of the outdoor post lantern carefully,
taking into account the location and height of the post. Ensure
that there is enough space for the lantern to be mounted securely
and that it is not obstructed by any objects.

Tools Required

The following tools are required for installation:

Phillips screwdriver
Flathead screwdriver
Adjustable wrench
Wire stripper/cutter
Electrical tape

Hardware Included

The product comes with the following hardware:

Mounting bracket
Mounting screws
Wire nuts
Gasket
Post cap

Package Contents

The package includes the following:

Mauvo Canyon LED Outdoor Post Lantern
Installation instructions

Installation

Turn off the circuit breaker or remove the fuse at the fuse box
before beginning the installation.
Attach the mounting bracket to the post using the mounting
screws.
Connect the wires from the post to the wires from the lantern
using wire nuts and electrical tape.
Attach the lantern to the mounting bracket using the provided
screws.
Attach the post cap to the post.
Turn on the circuit breaker or replace the fuse at the fuse
box.

Operation

To operate the Mauvo Canyon LED Outdoor Post Lantern, turn on
the circuit breaker or replace the fuse at the fuse box. The
lantern will turn on automatically at dusk and turn off at dawn.
The lantern is designed to provide years of reliable service with
minimal maintenance.

Care and Cleaning

The Mauvo Canyon LED Outdoor Post Lantern is designed to require
minimal maintenance. To clean the lantern, use a soft cloth and
mild soap solution. Do not use abrasive cleaners or solvents as
they may damage the finish of the lantern.

Troubleshooting

If you experience any problems with your Mauvo Canyon LED
Outdoor Post Lantern, please call customer service at
1-800-986-3460 or visit www.homedepot.com/homedecorators for
assistance.

Safety Information

Before installing or using the Mauvo Canyon LED Outdoor Post
Lantern, read the safety information provided in the user manual
carefully. Ensure that the post lantern is installed correctly and
securely to prevent accidents and injuries. If you have any
questions or concerns, contact customer service at
1-800-986-3460.

CAUTION: Inspect the wire insulation for any
cuts, abrasions, or exposed copper that may have resulted during
shipping. If there is a defect in the wire, do not attempt
installation. Please call our Customer Service Team at
1-800-986-3460.

WARNING: To reduce the risk of electric shock,
turn off the circuit breaker or remove the fuse at the fuse box
before beginning the installation. Do not attempt to modify or
alter the Mauvo Canyon LED Outdoor Post Lantern in any way as this
may result in damage to the product or cause accidents and
injuries.

View Fullscreen

Item #1007260749 Model #PT-06005-DEL
USE AND CARE GUIDE
MAUVO CANYON LED OUTDOOR POST LANTERN
Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service
8 a.m. – 7 p.m., EST, Monday Friday, 9 a.m. 6 p.m., EST, Saturday 1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Home Decorators Collection!

Table of Contents
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Pre-Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Planning Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Hardware Included. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Care and Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Safety Information
questions.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for
help.
FCC Responsible Party Name: Bel Air Lighting Address: 28104 Witherspoon Pkwy. Valencia, CA 91355 Telephone Number: 1-800-446-9092

CAUTION: Inspect the wire insulation for any cuts, abrasions, or exposed copper that may have resulted during shipping. If there is a defect in the wire, do not attempt installation. Please call our Customer Service Team at 1-800-986-3460.
WARNING:
turning off the circuit breaker or by removing the fuse at the fuse box.

Warranty
date of purchase. This warranty applies only to the original consumer purchaser and only to products used in normal use and service. If this product is found to be defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the
alterations, neglect, or mishandling. This warranty shall not apply to any product that is found to have been improperly installed, set-up, or used in any way not in accordance with the instructions supplied with the product. This warranty shall not apply to a failure of the product as a result of an accident, misuse, abuse, negligence, alteration, faulty installation, or any other failure not relating to faulty material
considered normal wear and tear. The manufacturer does not warrant and specially disclaims any warranty, whether express or implied,
shall not be liable for any consequential or incidental loss or damage, including but not limited to any labor / expense costs involved in the replacement or repair of said product. Contact the Customer Service Team at 1-800-986-3460 or visit www.homedepot.com/homedecorators.
2

Pre-Installation
PLANNING INSTALLATION
Read all instructions before installation. To avoid damaging this product, assemble it on a soft, non-abrasive surface, such as carpet or cardboard. Keep your receipt and these instructions for proof of purchase.
TOOLS REQUIRED

Ladder

Safety goggles

Electrical tape

Phillips screwdriver

Flat blade screwdriver

Pliers

HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.

Wire strippers

Silicone sealant

Part Description AA Wire nut BB Screw (preinstalled)

Quantity 3 3

HOMEDEPOT.COM/HOMEDECORATORS

Please contact 1-800-986-3460 for further assistance.

Pre-Installation (continued)
PACKAGE CONTENTS
A

Part

Description

Light fixture

Quantity 1

Installation

1 Making the electrical connections

Remove the preinstalled screws to remove the top of the light fixture (A). Remove the potective foam and resecure the top of the light fixture (A) using the previously removed screws.

Connect the black to black (power), the white to white

(neutral) and copper wire to ground wire with the wire nuts (AA) and secure with electrical tape (not included).

NOTE: If the wires from the fixture are the same color, attach the side with markings or letters to the black (positive) wire and the other to the white (neutral) wire.

2 Securing the light fixture
Secure the base (A) to the pole or base (not included) with the pre-assembled screws (BB).
CAUTION: To avoid any waterproofing problems, please make sure the light fixture fits the mounting surface perfectly during installation and use silicone sealant around the canopy for better sealing after installation.

AA A
A BB

HOMEDEPOT.COM/HOMEDECORATORS

Please contact 1-800-986-3460 for further assistance.

Operation
1 Turning the light on
Turn the light switch on to activate the fixture.
If it is daylight, the fixture will not illuminate. To test the fixture, cover the photocell with electrical tape. Once you confirm the fixture illuminates, remove the electrical tape.
If it is daylight, the fixture may not illuminate with the electrical tape over the photocell, as the photocell can be sensitive. Wait until nighttime to confirm the fixture illuminates.
NOTE: Position the photocell fixture so that the light from the any other fixture or any other light does not shine directly onto the “eye,” as this will interfere with the normal operation of the photocell fixture.

Care and Cleaning
Clean the lamp with a soft, dry cloth. Do not use any cleaners with chemicals, solvents, or harsh abrasives.

Troubleshooting

Problem The bulb will not light.
The fuse blows or circuit breaker trips when the light is turned on.

Possible Cause The power is off. There is a faulty wire connection. The circuit breaker is off. There are crossed wires or the power wire is grounding out.

Solution Ensure the power supply is On. Check the wiring. Ensure the circuit breaker is in the On position. Check the wire connections. Contact a qualified electrician or call the Customer Service Team at 1-800-986-3460.

HOMEDEPOT.COM/HOMEDECORATORS

Please contact 1-800-986-3460 for further assistance.

Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service
8 a.m. 7 p.m., EST, Monday Friday, 9 a.m. 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
Retain this manual for future use.
