Supreme ECM Motor ENG
The Supreme electric furnace with variable speed ECM motor.
The only furnace offering both 2 wires 208/240V models and 3 wires 120 240/208V models for a direct installation of accessories.
· Multi-position installation · Sequential operation of electrical elements · Approved for line voltage wiring in copper or aluminum · Approved for zero clearance and mobile-home
installations · Separately framed elements allowing quick and
easy replacement · 20” x 20” supply air outlet · Baked painted cabinet · Breakers in front panel
SUPREME
ECM Motor
ADVANTAGE SERIES
· Continuous ventilation selector switch in front panel
· Low/High power selector switch in front panel
· LED indicator for heating demand
MODULATING SERIES
· Semi-conductor modulation on the entire range (0-100%)
for increased comfort and quiet operation
· Control board enabling total command of the unit and
easy configuration · Compatible with the Smart Duct System®
· Allows for our Right-Sized System ®, in combination with
our
heat pump
SUPREME ECM Motor
ARRANT
W S
Y
927 mm 36 1/2″
Right Side View
B
KOE
Identical on the 2 sides
A
Identical on the 2 sides, the back and below.
RETURN 483 mm x 483 mm
19″ x 19″
451 mm 17 3/4″
451 mm 17 3/4″
Top View
559 mm 22″ 25 mm 1″
SUPPLY
25 mm 1″
559 mm 22″
O N PART
508 mm x 508 mm 20″ x 20″
KOE A = 35 mm @ 44 mm
1 3/8″ & 1 3/4″ B = 29 mm
7/8″
Side pannels pre-punched for ease of return-air
installation
Weight: 105 lb (48kg)
ADVANTAGE SERIES
Model #
SUP10-A240V12 SUP15-A240V12 SUP18-A240V12 SUP20-A240V12 SUP23-A240V12 SUP25-A240V12 SUP20-A240V20 SUP23-A240V20 SUP25-A240V20 SUP27-A240V20 SUP30-A240V20
Volts (1 ph*) 2 wires¹
240/208
Input kW (BTU/hr) 10 (34 100) 15 (51 200) 18 (61 400) 20 (68 200) 23 (78 500) 25 (85 400) 20 (68 200) 23 (78 500) 25 (85 400) 27 (92 100) 30 (102 400)
Motor HP 1/2 1/2 1/2 1/2 1/2 1/2 1 1 1 1 1
¹ Can be wired with 3 conductors for 120 208/240V supply, to allow direct installation of accessories such as humidifiers. ² Static Pressure at 0.5″ W.C. ³ CFM adjustable in heating and cooling
* 3 phases model available, see with your distributor for more information.
Air flow² Max cfm³
1200 1200 1200 1200 1200 1200 2000 2000 2000 2000 2000
Max cooling (tons) 3 3 3 3 3 3 5 5 5 5 5
MODULATING SERIES
Model #
SUP10-M240V12 SUP15-M240V12 SUP18-M240V12 SUP20-M240V12 SUP23-M240V12 SUP20-M240V20 SUP23-M240V20 SUP25-M240V20 SUP27-M240V20 SUP30-M240V20
Volts (1 ph) 2 wires¹
240/208
Input kW (BTU/hr)
10 (34 100) 15 (51 200) 18 (61 400) 20 (68 200) 23 (78 500) 20 (68 200) 23 (78 500) 25 (85 400) 27 (92 100) 30 (102 400)
Motor HP
1/2 1/2 1/2 1/2 1/2 1 1 1 1 1
Traditionnal Ducts²
Airflow Max (cfm)
Max cooling (tons)
1400
3.5
1400
3.5
1400
3.5
1400
3.5
1400
3.5
2200
5.5
2200
5.5
2200
5.5
2200
5.5
2200
5.5
¹ Can be wired with 3 conductors for 120 208/240V supply, to allow direct installation of accessories such as humidifiers. ² Static Pressure at 0.5″ W.C.
Smart Ducts®
Airflow Max (cfm)
Max cooling (tons)
1000
2.5
1000
2.5
1000
2.5
1000
2.5
1000
2.5
1600
4
1600
4
1600
4
1600
4
1600
4
3400, boulevard Industriel Sherbrooke, Québec J1L 1V8 Canada
T 1.819.346.8493 TF 1.800.567.2733 F 1.819.822.4227 [email protected] www.dettson.com
Specifications subject to change without notice.
