ERSSM1-01B Sones Speaker Stand
Product Information
The product is a speaker stand with the model number ERSSM1-01B.
It has a maximum weight capacity of 22 lbs or 10 kg. The package
includes two bases, four pillars, two speaker bracket A, two
speaker bracket B, two fixed plates, two connectors, two decorative
covers, eight spikes, eight spike covers, two M6 x 25mm bolts, two
1/4 in-20 x 1/2 in bolts, two M6 x 16mm bolts, and an Allen key.
The product weighs 14.7 lbs or 6.68 kg.
Product Usage
- Check the weight of your speaker. If it weighs more than 22 lbs
or 10 kg, the stand is not compatible. - Attach the spikes and covers to the base. Use the covers if the
spikes will damage your floors. - Secure the pillars and other parts to the base using the Allen
key. - Assemble the pillars by feeding the cables through the lower
pillar and connector, inserting the connector into the pillar, and
then feeding the cables through the upper pillar and securing it
over the connector. - Attach the speaker bracket to the pillar using the appropriate
bolts and Allen key. - Adjust the level of the base by rotating the spikes and
removing the covers if necessary.
If you have any concerns or questions about the product, contact
ErgoAV customer care via phone at (877)419-7832 or email at
[email protected]. You can also visit their website at
www.ergoav.com or mail them at 9501 Louisiana Ave N, #200, Brooklyn
Park, MN 55445.
Sones® Speaker Stand Instruction Manual
(A)
English pages 02-07
French pages 08-1 3
Spanish pages 14-19
Model: ERSSM1-01 B
Thank You for Choosing this ErgoAV Product! At ErgoAV, we want to add value to your AV experience by providing the highest quality products and services in the industry. If you have any concerns or comments, please contact us.
ErgoAV Customer Care phone(877)419-7832 email: [email protected] website: www.ergoav.com address: 9501 Louisiana Ave N, #200, Brooklyn Park, MN 55445
Important Safety Instructions
· Check package contents against Supplied Parts and Hardware List to assure that all components were received undamaged. Do not use damaged or defective parts. If you require replacement parts, contact customer service at [email protected].
· Not all parts and hardware included will be used. · Carefully read all instructions before attempting installation. If you do not understand
the instructions or have any concerns or questions, please contact customer service at [email protected]. · This product may contain moving parts. Use with caution. · Do not use this product for any purpose that is not explicitly specified in this manual. Do not exceed weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect assembly or inappropriate use.
– Weight Restrictions MAX 22 lbs 10 kg
If your Speaker weighs more,
this stand is NOT compatible.
WARNING
DO NOT exceed the maximum weight indicated. This speaker stand is intended for use only within the maximum weights indicated. Use with products heavier than the maximum weights indicated may result in failure of the stand and its accessories, causing possible damage and or injury.
Tools Needed (Not Included)
Phillips Screwdriver
Supplied Parts and Hardware
AwARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. Do not use damaged or defective parts. If you need replacement parts, please contact Technical Support at (877) 419-7832 or Customer Service at [email protected]. · NOTE: Not all hardware included in this package will be used.
02
Supplied Parts and Hardware
0
Base [01] X 2
Pillar [02] X 4
~
Speaker Bracket A [03] X 2
Speaker Bracket B [04] X 2
~
Fixed Plate [05] X 2
1ji.,1
Connector [06] X 2
Decorative Cover
[07] X 2
$ Spikes [A] X 8
®Plastic Washer [E] X 2
a Cover [B] X 8
® Washer [F] X 2
Inner Hexagon
Bolt
‘
M6 x 25mm [C] X 2
·
Bolt
1/4 in-20 x 1/2 in
[G] X 2i
Bolt M6 x 16mm
[D] X 2
r M4 Allen Key [H] X 1
Step 1 Assemble Spikes to Base
Mounting the Spikes [A] and Covers [B] on the Base [01 ].
: NOTE: Covers [BJ can be used as an alternative if Spikes [A] will damage floors.
‘
I
r—–,
L!r -[-0–1—]*–1.-J-!- – – , L! [-A-]-*-4–[-8-]-*4.J!
03
Step 2 Assemble Pillar to Base
Lock [C], [E], [07], [02] on the Base [01] with the Allen Key [H].
Step 3 Pillar Assembly
!Lr-[0–1—]-*-1-r—-[—0—2–]-*—1——-[-0—7—]-*—1–~,,! I C*1 E*1 H*1 I LI ———–~I
Feed cable(s) through lower Pillar [02] and Connector [06]. Insert Connector [06] into Pillar [02]. Feed cable(s) through upper Pillar [02]. Insert upper Pillar [02] over Connector [06] to secure assembly.
r———–,
L! [-02-]-*-2—[-0-6]-*-1~!
04
Step 4 Secure the Speaker Bracket to the Pillar
r—–,
! ! L _[0_3_]*_1_ .J
r——-,
! D*1 H*1 !
L——-.J
r—–,
![03]*1 !
r—– L—–.J ———-,
! D*1 F*1 G*1 H*1 !
L—————.J
05
Fron
r———–,
!
r=
!L _8*_1___E_*1_ Ji
06
Step 5 (Optional) Adjust Level of Base
To level and stabilize the base, you can remove the Cover [B] (if needed) and rotate the Spike [A]. Repeat on each corner as necessary.
—— …. ………… ‘ ‘ ‘ ‘
,,—,
I
I
,, I ,g;l’ I
07
At ErgoAV, we strive to provide the highest value products. We want to support your purchase. If you have questions, concerns, or feedback please let us know!
ErgoAV Customer Care Phone(877)419-7832 [email protected]
A/V Furniture
0
0
I.0
0 0
I
0
0
0
0 0
0
ff
~
oOo
i ~
0 0 0
. f
0
0
d
~ I
~
~
0
0
TV mounts
Tabletop TV Stands
860-00444-00 Rev00
9501 Louisiana Ave N, #200, Brooklyn Park, MN 55445 www.ergoav.com
ERSSM1-01B
Speaker Accessories
The ERSSM1-01B is designed to be compable with the Sonos® Play: 1® and Play: 5® speakers. The adjustable feet or spikes can level the stand on uneven floors and improve acouscs. Built in cable management allows cables to run through the pillar to create a clean and finished look. Steel pillar and glass base provide a strong and stylish foundaon for your speaker. 34″ height places the speaker at opmum listening level.
Features
· Designed to be compable with the Sonos® Play: 1® and Play: 5® speakers.
· Adjustable feet or spikes level stand on uneven floors and improve acouscs.
· Cable management – cables run through pillar to create a clean look.
· Solid Foundaon – steel pillar and glass base provide a strong and stylish foundaon for your speaker.
· 34″ Tall to place the speaker at opmum listening level.
Compatible with Sonos® Play: 1®, One® and One SLTM
Compatible with Sonos® Play: 5®
Max
22 lbs. / 10 kg
1-877-419-7832 [email protected] ergoav.com
Model Number ERSSM1-01B
Product Specifications
DIMENSIONS (W x H x D) 12.5″ × 34.2″ × 12.6″
318.3mm × 869mm × 320mm
PRODUCT WEIGHT 14.7 lbs. 6.68 KG
LOAD CAPACITY 22 lbs. 10 KG
WARRANTY: 5-Year
FINISH
AVAILABLE COLORS
Powder Coang
Black
Package Specifications
PACKAGE SIZE (W x H x D) 20.4″ × 6.4″ × 14.6″
517mm × 163mm × 372mm
PACKAGE WEIGHT PACKAGE UPC CODE PACKAGE CONTENTS UNITS IN PACKAGE
17.4 lbs. 7.9 KG
810082200249
Product, Manual, Parts
1 Unit
Master Carton Specifications
PACKAGE SIZE (W x H x D) 20.9″ × 13.4″ × 15.4″
530mm × 340mm × 390mm
PACKAGE WEIGHT 36.5 lbs. 16.55 KG
UNITS IN CARTON 2 Unit
Product Dimensions
415mm[16.33”] 834mm [32.83”] 320mm [12.6”]
35mm [1.38”]
FRONT VIEW
Wire Hole: 40 x 20mm [1.57” x 0.78”]
Adjustable Height: 3mm[0.11”]
BACK VIEW
318.35mm [12.5”]
TOP VIEW
40mm [1.57”]
255mm [10.04”]
SIDE VIEW
834mm [32.83”] 320mm [12.6”]
FRONT VIEW
415mm [16.33”]
35mm [1.38”]
ERSSM1-01B
Speaker Stand The informaon and designs contained in this document are confidenal and the proprietary property of BESTERGO, Inc neither the design nor any informaon contained in this drawing may be reproduced, used, or disclosed to others without the express wrien permission of BESTERGO, Inc.
SIDE VIEW
40mm [1.57”]
Adjustable Height: 3mm[0.11”]
Wire Hole: 40 x 20mm [1.57” x 0.78”] 255mm [10.04”]
3-D View TOP VIEW
318.35mm [12.53”]
