FX182 Optical Channel Checker
Product Information
The FX182 OCC is a test set that provides firmware/software
updates for various features and enhancements. The current software
version is ver. 01.04.0001, which was released on October 20, 2022.
The firmware versions include Boot Rom version 4.0.1, CPLD version
10, and Fiber Tool Version 01.01.06.
The OCC (Optical Channel Checker) offers several new features
and improvements, including general enhancements such as fixing
WiFi/BT enabled option bug and minor UI improvements. It also
includes file operation and related enhancements such as the
ability to customize the set of optical channel plans through
R-Server.
Prior releases include ver. 01.02.0008, released on July 7,
2022, and ver. 01.02.0004, the initial release on November 22,
2021. These releases introduced various general enhancements, file
operation improvements, and bug fixes.
Product Usage Instructions
Upgrading Procedure via USB Memory Stick
1. Ensure that the test set can detect the memory stick before
starting the procedure.
2. Turn the test set’s power OFF.
3. Connect the USB stick via an OTG cable to the FX182 micro-USB
port and connect the AC adapter.
4. Option A (Clean Install): Turn the test set ON by pressing
the SAVE+POWER buttons simultaneously and holding them until a tone
(beep) is heard. Wait for the boot-up process to finish.
5. Option B (Preserve Settings and Data): Turn the test set ON
by pressing the POWER+HOME buttons simultaneously and holding them
until a tone (beep) is heard. Wait for the boot-up process to
finish.
6. The test set will reboot itself at the end of the upgrading
process.
Upgrading Procedure via WiFi or LAN
1. Ensure that the test set is ON and connected to WiFi or LAN
using the micro-B USB-RJ45 adapter cable.
2. Use a PC, Mac, tablet, or smartphone with access to the file
system and the ability to select the install package file.
3. Open a web browser and enter the IP address of the test set
into the browser’s address/search field (e.g., 10.0.20.1). The test
set’s IP address is displayed at the bottom-left corner of the
screen.
4. Once the test set’s Web Remote Access page loads, select
“Upgrade” from the menu on the left side of the screen.
5. Tap or click on the “Select File” button and point it to the
Software Image file.
6. Tap or click on the “Upload” button to transfer the Software
Image file to the test set.
7. Once the file transfer is complete, tap or click on “Upgrade”
and let the test set go through the process without interruption.
This may take some time.
For further assistance or support, please contact VeEX Inc.
at:
2827 Lakeview Court, Fremont, CA 94538, USA
Tel: 1.510.651.0500
Fax: 1.510.651.0505
Website: www.veexinc.com
FX182 OCC
Software Release Notes
FX182 OCC Firmware/Software Updates
Refer to the last section of this document for software upgrade guide. The update process may take a few minutes to complete. Do not turn the test set off or disconnect its AC/DC adapter during the process.
Software version: ver. 01.04.0001
Release Scope: Formal Release. General Availability Firmware versions: – Boot Rom version: 4.0.1 – CPLD version: 10 – Fiber Tool Version: 01.01.06
OCC new features and improvements: 1. General enhancements
a. Fixed WiFi/BT enabled option bug b. Minor UI improvements 2. File operation and related enhancements a. Added ability to customize set of optical channel plans through R-Server
October 20, 2022
Software version: ver. 01.02.0008
Release Scope: Formal Release. General Availability Firmware versions: – Boot Rom version: 2.0.7 – CPLD version: 10
OCC new features and improvements: 1. General enhancements a. Added new toolbox widget for controlling wavelength/frequency b. Improved Table Edit c. Added scroll button functionality d. Fixed calibration firmware bug e. OTDR tool bug fixes and UI improvements 2. File operation and related enhancements a. Fixed Customizable Channel Plan labels in test reports and R-Server 3. Supports FiberScope option a. Included fiber tool version number
July 7, 2022
2827 Lakeview Court, Fremont, CA 94538, USA Tel: 1.510.651.0500 Fax: 1.510.651.0505 www.veexinc.com
1
FX182 OCC
Software Release Notes
Software version: ver. 01.02.0004
November 22, 2021
Release Scope: Initial Release. General Availability Firmware versions: – Boot Rom version: 2.0.7 – CPLD version: 10
OCC new features and improvements: 1. General enhancements
a. OCC measurement range includes O to L-band b. Added user-defined Test Profiles including CWDM, 100GHz DWDM C-L Band, and LR4/LR8 Transceivers c. Added 4-color coded View Modes: Summary, Tiles, Bar Graph, and Table Graph d. Added Quick CWDM/Quick DWDM for single channel measurement or locating peak channel in test profile e. Added EZ Remote registration f. Added R- Server support 2. File operation and related enhancements a. Save/View results in HTML report format 3. Supports FiberScope option
2827 Lakeview Court, Fremont, CA 94538, USA Tel: 1.510.651.0500 Fax: 1.510.651.0505 www.veexinc.com
2
FX182 OCC
Software Release Notes
Upgrading procedure
To download the latest software version available, go to https://www.veexinc.com/support/software, enter the first four characters of the test set’s serial number (e.g. TEBC) and use the links to download the software package and Release Notes to the PC. FX182 OCC image file can be recognized by its fx182-veex-arm.tar.gz file name. Extract this file from the ZIP folder and copy to the root of a FAT32 USB memory stick. This upgrade integrates the micro OSA software, Boot Rom, and CPLD into a single file. The test set must be connected to AC/DC charger at all times during the whole upgrade process. DO NOT turn it off at any time; the update process would take a few minutes. To verify the software version number installed, turn the test set back on, open the Utilities section, select Settings, and open About. You may also use the Web Remote Access to get the information
Updating via a micro-B USB memory stick or USB-A Memory Stick with an OTG adapter Make sure the test set can detect the memory stick, before starting this procedure. 1. Turn the test set’s power OFF 2. Connect the USB stick via OTG cable to FX182 micro-USB port and connect the AC adapter. 3. Option A: For a clean install (reset all settings and clear internal storage), turn the test set ON, by pressing the SAVE+POWER
buttons simultaneously and holding them until a tone (beep) is heard, then wait for the boot up process to finish. 4. Option B: To preserve some existing settings and data, turn the test set ON, by pressing the POWER+HOME buttons
simultaneously and holding them until a tone (beep) is heard, then wait for the boot up process to finish. 5. The test set will reboot itself at the end of upgrading
Updating via WiFi or LAN Make sure the test set is ON and connected to WiFi, or to a LAN using the micro-B USB-RJ45 adapter cable. PCs, Mac, tablets, and smartphones can be used to perform this task, as long as they provide access to the file system and allow to select the install package file. 1. Open the Web Browser and enter the IP address of the test set into the browser’s address/search field (e.g., 10.0.20.1). The
test set’s IP address is displayed at the bottom-left corner of the screen, 2. Once the test set’s Web Remote Access page loads, select Upgrade from the menu on the left side of the screen. 3. Tap or click on the Select File button and point it to the Software Image file. 4. Tap or click on the Upload button to transfer the Software Image file to the test set. 5. Once the file transfer is done, tap or click on Upgrade and let the test set go through the process, uninterrupted. This will take
a few minutes. The test set will reboot itself at the end.
© 2021 – 2022 VeEX Inc. All rights reserved.
VeEX, VePAL, ReVeal, VeExpress, V-SAM, V-SCAN, Multi-BERT, Fiberizer and the V logos are trademarks or registered trademarks of VeEX Incorporated, or one of its affiliates. All other trademarks or registered trademarks are the property of their respective owners.
Some features listed in this document require software options that may require paid activation or license and may or may not be available in all products. VeEX Inc., reserves the right to change product offerings or specifications without notice.
2827 Lakeview Court, Fremont, CA 94538, USA Tel: 1.510.651.0500 Fax: 1.510.651.0505 www.veexinc.com
3
