S120 Solar Wall Light Cam
Product Information: S120 Solar Wall Light Cam
The S120 Solar Wall Light Cam is an outdoor security camera that
is powered by solar energy. It features a 1080p HD camera with a
140-degree viewing angle, motion detection, two-way audio, and a
built-in LED light for night vision. The camera is designed to be
mounted on a wall or similar surface and can be synced with the
eufy Security app to provide remote access and control.
What’s Included
- S120 Solar Wall Light Cam
- Mounting Bracket Model: T81A0
- Mounting Screws
- Camera Fixing Screw
- USB-C Extension Cable
- Quick Start Guide
Product Usage Instructions
Ensure Tight Seal
Prior to usage, ensure that the camera has a tight seal to
prevent damage from water or other elements.
Charging the Camera
Note that the charging cable and AC adapter are not included. To
charge the camera, use a USB-C cable and adapter to connect to a
power source. The camera should be charged fully before usage.
Setting Up
- Download and install the eufy Security app and create an
account. - Follow the on-screen instructions to add the Solar Wall Light
Cam to the app.
Mounting
Select a location on a wall or similar surface where the solar
panel will receive sufficient sunlight and the camera will have an
unobstructed view. We recommend mounting the camera 2 m – 2.5 m
(6.6 ft – 8.2 ft) above ground level for optimal performance.
- Use the mounting bracket provided as a template to mark the
mounting points on the wall or surface where drilling will be
required. - Drill holes in the wall or surface and insert the expansion
anchors into the holes if mounting onto hard surfaces such as brick
or concrete. - Screw the mounting bracket onto the wall.
- Slot the camera onto the mounting bracket and ensure that it is
attached securely. - Insert and tighten the camera fixing screw at the bottom of the
camera to secure it in place.
Safety
Dispose of used batteries according to their instructions to
prevent risk of explosion. Shielded cables must be used for all
connections to other computing devices to maintain compliance with
FCC regulations.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is
subject to certain conditions, and changes or modifications not
approved by the responsible party could void the user’s authority
to operate the equipment.
Declaration of Conformity
This product complies with the radio interference requirements
of the European Community.
QUICK START GUIDE
S120 Solar Wall Light Cam
AT A GLANCE
Ensure Tight Seal
SYNC
Solar Panel Camera LED Indicator Microphone
USB-C Charging Port SYNC Button Speaker
01
WHAT’S INCLUDED
UP
S120 Solar Wall Light Cam Mounting Bracket Model: T81A0
Mounting Screws
Camera Fixing Screw
USB-C Extension Cable
Quick Start Guide
02
Ensure Tight Seal
CHARGING THE CAMERA
SYNC
Charging cable and AC adapter are not included. 03
SETTING UP
1. Download and install the eufy Security app, and sign up for an account.
2. Follow the on-screen instructions to add your Solar Wall Light Cam.
04
MOUNTING
Select a Location
The camera can be mounted on a wall or similar surface. Select a location where the solar panel will not be blocked by obstacles such as a roof or leaves.
05
· If it isn’t possible to completely avoid the solar panel being blocked by obstacles, try to allow as much exposure to sunlight as possible.
· Pay attention to battery management via the app to make sure your device receives enough power to continue operating. If your Solar Wall Light Cam does not receive enough power to continue operating, it can be charged manually, or an additional solar panel (with USB-C extension cable) can be connected and placed in a location with sufficient sunlight to stay powered.
06
Location Height
We recommend mounting 2 m – 2.5 m (6.6 ft – 8.2 ft) above ground level.
To maximize solar panel efficiency and the camera field of view, select a location where the camera receives plenty of sunlight.
6.6-8.2 ft (2 – 2.5 m)
Camera Field of View
Motion Detection Zone
07
Mount the Camera
1. Mark the mounting points on the wall or surface where drilling will be required, using the mounting bracket as a template.
UP
2. Drill holes in the wall or surface, then insert the expansion anchors into the holes.
This step applies if mounting onto hard surfaces such as brick or concrete. For soft surfaces such as wood, skip this step.
08
Anker Innovations Limited. All rights reserved. eufy Security and eufy Security Logo are trademarks of Anker Innovations Limited, registered in the United States and other countries. All other trademarks are the property of their respective owners.
51005003795 V01
3. Screw the mounting bracket onto the wall.
UP
4. Slot the camera onto the mounting bracket and make sure it is attached securely.
UP UP
5. Insert and tighten the camera fixing screw at the bottom of the camera.
UP
09
SAFETY
· Do not use the product in an environment where the temperature is too high or too low. Never expose the product to wet environments.
· The suitable temperature for devices and accessories is -20°C to 50°C (Charging temperature is 0°C to 40°C).
· It is recommended to supply the device in an environment with a temperature that ranges from 5°C to 25°C.
· Unless specifically indicated that it is safe to do so in the user guide or instruction manual, do not use this device in an environment that exceeds the recommended low or high temperature.
· Unless specifically indicated that it is safe to do so in the user guide or instruction manual, avoid exposing your device to direct sunshine or excessively wet environments.
· When supplying power, place the device in an environment that has a normal room temperature and good ventilation.
· The light source contained in this luminaire should only be replaced by the manufacturer, its service agent or a similarly qualified person.
SÉCURITÉ · N’utilisez pas le produit dans un environnement où la température
est trop élevée ou trop basse. N’exposez jamais l’appareil à un ou à un environnement humide. · La température appropriée pour le produit et les accessoires est comprise entre -20 °C et 50°C(la température de charge est de 0 °C à 40 °C). · Il est recommandé d’alimenter l’appareil dans un environnement dont la température est comprise entre 5 °C et 25 °C. · À moins qu’il ne soit spécifiquement indiqué dans le guide de l’utilisateur ou le manuel d’instructions que cela est sans danger, n’utilisez pas cet appareil dans un environnement qui dépasse les températures basses ou élevées recommandées. · Sauf indication contraire dans le guide de l’utilisateur ou le manuel d’instructions, évitez d’exposer votre appareil aux rayons directs du soleil
ou à des environnements excessivement humides.
10
· Lors de l’alimentation électrique, placez l’appareil dans un environnement ayant une température ambiante normale et une bonne ventilation.
· La source lumineuse contenue dans ce luminaire ne doit être remplacée que par le fabricant, son agent de service ou une personne également
qualifiée.
CAUTION!
THERE IS A RISK OF EXPLOSION IF AN INCORRECT BATTERY TYPE IS USED. DISPOSE OF USED BATTERIES ACCORDING TO THEIR INSTRUCTIONS.
ATTENTION!
IL EXISTE UN RISQUE D’EXPLOSION EN CAS D’UTILISATION D’UN TYPE DE PILE INCORRECT. ÉLIMINEZ LES PILES USAGÉES CONFORMÉMENT AUX INSTRUCTIONS.
Warning: Replacing a battery with an incorrect type may bypass safeguards and create danger; Disposal of a battery in a fire or other source of significant heat, or by crushing, or cutting, may result in an explosion as well as leakage of flammable liquids and gases; Leaving a battery in an extremely hot environment may result in an explosion as well as leakage of flammable liquids and gases; A battery subjected to extremely low air pressure may result in an explosion as well as leakage of flammable liquids and gases. Attention: -Le remplacement d’une batterie par un type incorrect peut contourner les protections et créer un danger ; -L’élimination d’une pile dans un feu ou une autre source de chaleur importante, ou par écrasement ou découpage, peut entraîner une explosion ainsi qu’une fuite de liquides et de gaz inflammables ; -Le fait de laisser une batterie dans un environnement extrêmement chaud peut entraîner une explosion ainsi qu’une fuite de liquides et de gaz inflammables ; -Une batterie soumise à une pression d’air extrêmement faible peut provoquer une explosion ainsi qu’une fuite de liquides et de gaz inflammables.
11
NOTICE
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible or compliance could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: (1) Reorient or relocate the receiving antenna. (2) Increase the separation between the equipment and receiver. (3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. (4) Consult the dealer or an experienced radio/TV technician for help. FCC Radio Frequency Exposure Statement The device has been evaluated to meet general RF exposure requirements. The device can be used in fixed/mobile exposure condition. The min separation distance is 20cm.
12
Notice: Shielded cables All connections to other computing devices must be made using shielded cables to maintain compliance with FCC regulations. The following importer is the responsible party: Company Name: POWER MOBILE LIFE, LLC Address: 10900 NE 8th St, Ste 501, Bellevue WA 98004 Telephone:1-800-988-7973
IC Statement This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.” Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: (1) l’appareil nedoit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.” This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. IC RF Statement When using the product, maintain a distance of 20cm from the body to ensure compliance with RF exposure requirements. Lors de l’utilisation du produit, maintenez une distance de 20 cm du corps afin de vous conformer aux exigences en matière d’exposition RF.
13
Declaration of Conformity
This product complies with the radio interference requirements of the European Community.
Hereby, Anker Innovations Limited declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. For the declaration of conformity, visit the Web site: https://uk.eufylife.com/.
This product complies with the radio interference requirements of the United Kingdom.
Hereby, Anker Innovations Limited declares that this product is in compliance with Radio Equipment Regulations 2017(SI2017/1206). The full text of the UK declaration of conformity is available at the following internet address: https://uk.eufylife.com
RF exposure information: The Maximum Permissible Exposure (MPE) level has been calculated based on a distance of d=20 cm between the device and the human body. To maintain compliance with RF exposure requirements, use product that maintains a 20cm distance between the device and the human body. Frequency bands and power as below:
Function Bands Operation Frequency Max. Power
Wi-Fi 2.4GHz
2412-2472MHz
EIRP 19.94 dBm
The following importer is the responsible party (contract for EU matters): Anker Innovations Deutschland GmbH I Georg-Muche-Strasse 3, 80807 Munich, Germany The following importer is the responsible party (contract for UK matters): Anker Technology (UK) Limited I GNR8, 49 Clarendon Road, Watford,Hertfordshire, WD17 1HP, United Kingdom
14
This product is designed and manufactured with high quality materials and components, which can be recycled and reused. This symbol means the product must not be discarded as household waste, and should be delivered to an appropriate collection facility for recycling. Proper disposal and recycling helps protect natural resources, human health and the environment. For more information on disposal and recycling of this product, contact your local municipality, disposal service, or the shop where you bought this product.
15
CUSTOMER SERVICE
12-month limited warranty
(US) +1 (800) 988-7973 (UK) +44 (0) 1604 936200 (DE) +49 (0) 69 9579 7960 ( ) +86 400 0550 036 ( ) +81 03 4455 7823 (AU) +61 3 8331 4800 (Egypt) +20 8000000826 (UAE) +971 8000320817 (Kuwait) +965 22069086 (Saudi Arabia) +966 8008500030 (Middle East & Africa) +971 520750842
