V4-WPS 12-36V RF IP67 Waterproof LED Controller
Product Information
Model No.: V4-WPS
Product Name: 4 Channel Constant Voltage LED
Waterproof RF Controller
Features:
- Waterproof 4 channel constant voltage LED RF controller with
IP67 rating, suitable for outdoor and damp environment. - Match with RF 2.4G single zone or multiple zone single color,
dual color and RGB/RGBW remote control. - One RF controller accepts up to 10 remote controls.
- 4096 levels 0-100% dimming smoothly without any flash.
- Built-in 10 dynamic modes when using with RGB/RGBW light,
including jump or gradual change style. - Auto-transmitting function: Controller automatically transmits
signals to another controller with a 30m control distance. - Synchronize on multiple number of controllers.
- Fade in and out effect selectable.
Technical Parameters:
- Input and Output: Input voltage: 12-36VDC,
Input current: 20.5A, Output voltage: 4 x (12-36)VDC, Output
current: 4CH,5A/CH, Output power: 4x(60-180W), Output type:
Constant voltage - Warranty: 5 years
- Dimming data: Input signal: RF 2.4GHz, Control
distance: 30m (Barrier-free space), Dimming gray scale: 4096 (2^12)
levels, Dimming range: 0 -100%, Dimming curve: Logarithmic, PWM
frequency: 1000Hz (default) - Package Size: L165 x W98 x H72mm
- Gross weight: 0.492kg
Safety and EMC:
- EMC standard (EMC): ETSI EN 301 489-1
V2.2.3 - Safety standard(LVD): ETSI EN 301 489-17
V3.2.4, EN 62368-1:2020+A11:2020 - Radio Equipment(RED) Certification: ETSI EN
300 328 V2.2.2, CE, EMC, LVD, RED
Environment:
- Operation temperature: -30°C ~ +55°C
- Case temperature (Max.): +85°C
- IP rating: IP67
Mechanical Structures and Installations:
Please refer to the wiring diagram and instructions provided in
the user manual.
Product Usage Instructions
V4-WPS for RGB/RGBW:
1. Connect the power input wires (Brown V+, Blue V-) to a power
supply with a voltage range of 12-36VDC.
2. Connect the LED output wires according to the wiring diagram
provided.
3. If connecting with an RGB LED strip, long press the match key
for 15 seconds to switch the controller to RGB mode. The light will
blink 5 times.
4. Use an RGB/RGBW remote control to control the LED strip.
5. The power supply should be AC100-240V.
V4-WPS for dual color:
1. Connect the power input wires (Brown V+, Blue V-) to a power
supply with a voltage range of 12-36VDC.
2. Connect the LED output wires according to the wiring diagram
provided.
3. Use a CCT remote control to control the dual color LED
strip.
4. The power supply should be AC100-240V.
V4-WPS for single color:
1. Connect the power input wires (Brown V+, Blue V-) to a power
supply with a voltage range of 12-36VDC.
2. Connect the LED output wires according to the wiring diagram
provided.
3. Use a dimming remote control to control the single color LED
strip.
4. The power supply should be AC100-240V.
5. The controller’s match key can be used to match or delete
remote controls.
6. To match a remote control, short press the match key and
immediately press the on/off key (for single zone remote) or zone
key (for multiple zone remote) of the remote.
7. To delete all matched remotes, press and hold the match key
for 5 seconds. The light will blink 3 times to indicate that all
matched remotes have been deleted.
Note: Please refer to the user manual for further
instructions and safety precautions.
4 Channel Constant Voltage LED Waterproof RF Controller Model No.: V4-WPS
IP67 waterproof/4 Channels/Step-less dimming/Wireless remote control/Auto-transmitting/Synchronize
Features
Waterproof 4 channel constant voltage LED RF controller with IP67 rating, suitable for outdoor and damp environment.
Match with RF 2.4G single zone or multiple zone single color, dual color and RGB/RGBW remote control.
One RF controller accept up to 10 remote control. 4096 levels 0-100% dimming smoothly without any flash. When using with RGB/RGBW light, built in 10 dynamic mode, include jump or gradual change style. Auto-transmitting function: Controller automatically transmit signal to another controller with 30m control distance. Synchronize on multiple number of controllers. Fade in and out effect selectable.
Technical Parameters
Input and Output Input voltage Input current Output voltage Output current Output power Output type Warranty Warranty
12-36VDC 20.5A 4 x (12-36)VDC 4CH,5A/CH 4x(60-180W) Constant voltage
5 years
Dimming data Input signal Control distance Dimming gray scale Dimming range Dimming curve PWM frequency Package Size Gross weight
RF 2.4GHz 30m(Barrier-free space) 4096 (2^12) levels 0 -100% Logarithmic 1000Hz (default)
L165 x W98 x H72mm 0.492kg
LVD RED
Safety and EMC
EMC standard (EMC)
Safety standard(LVD) Radio Equipment(RED) Certi cation
Environment Operation temperature Case temperature (Max.) IP rating
ETSI EN 301 489-1 V2.2.3 ETSI EN 301 489-17 V3.2.4 EN 62368-1:2020+A11:2020 ETSI EN 300 328 V2.2.2 CE,EMC,LVD,RED
Ta: -30 OC ~ +55OC T c:+85OC IP67
Mechanical Structures and Installations
153.00 mm
57.00 mm
V4-WPS
RGBW/RGB/CCT/Dimming 4CH LED RF Controller
Uin=12-36VDC Iin=20.5A Uout=4x(12-36)VDC Iout=4x5A Pout=4x(60-180)W
Temp Range: -30~+55
·tc=75
IP67
Power Input Brown V+ Blue V-
LED Output
Black
V+
Brown 1 R WW
Y/G
2 G CW
Blue
3 B WW
Gray
4 W CW
143.50 mm 34.00 mm
Wiring Diagram
V4-WPS for RGB/RGBW
RGB /RGBW remote
Power Input Brown V+ Blue V-
LED Output
Black
V+
Brown 1 R WW
Y/G
2 G CW
Blue
3 B WW
Gray
4 W CW
RGBW LED strip
W
Power Supply 12-36VDC Constant Voltage
Note: If connect with RGB LED strip, please long press match key for 15s, the controller will become RGB type, the light blinks 5 times.
AC100-240V
V4-WPS for dual color
CCT remote
++
Power Input Brown V+ Blue V-
LED Output
Black
V+
Brown 1 R WW
Y/G
2 G CW
Blue
3 B WW
Gray
4 W CW
CW
WW Dual color LED strip
CW
WW Dual color LED strip
Power Supply 12-36VDC Constant Voltage
AC100-240V
User Manual Ver 1.0.0
1
V4-WPS for single color
Power Input Brown V+ Blue V-
Dimming remote
Match Remote Control (two match ways)
LED Output
Black
V+
Brown 1 R WW
Y/G
2 G CW
Blue
3 B WW
Gray
4 W CW
Single color LED strip +
Single color LED strip +
Single color LED strip +
Single color LED strip +
End user can choose the suitable match/delete ways. Two options are offered for selection:
Power Supply 12-36VDC Constant Voltage
AC100-240V
Use the controller’s Match key
Match: Short press match key, immediately press on/off key (single zone remote) or zone key (multiple zone remote) of the remote.
Delete: Press and hold match key for 5s to delete all match, The light blinks 3 times means all matched remotes were deleted.
Use Power Restart
Match: Switch off the power, then switch on power, repeat again. Immediately short press on/off key (single zone remote) or zone key (multiple zone remote) 3 times on the remote. The light blinks 3 times means match is successful.
Delete: Switch off the power, then switch on power, repeat again. Immediately short press on/off key (single zone remote) or zone key (multiple zone remote) 5 times on the remote. The light blinks 5 times means all matched remotes were deleted.
RGB/RGBW dynamic mode list
No.
Name
1
RGB jump
2
RGB smooth
3
6 color jump
4
6 color smooth
5
Yellow cyan purple smooth
No.
Name
6
RGB fade in and out
7
Red fade in and out
8
Green fade in and out
9
Blue fade in and out
10 White fade in and out
Fade in and Fade out Setting
Long press match key 5s, then short press match key 3 times, the lighting effect will be set to the fade in and fade out in 3s. Long press match key 10s, restore factory default parameter, the light blinks 10 times, the light on/off time restores to 0.5s.
Dual color control
CH1,CH3=Warm white LED CH2,CH4=Cool white LED Each channel can supply up to 120W(@24V) and white balance can be controlled as such:
Color temperature Power distribution
Cool white
CH1=0W,CH2=120W CH3=0W,CH4=120W
Neutral white
CH1=60W,CH2=60W CH3=60W,CH4=60W
Warm white
CH1=120W,CH2=0W CH3=120W,CH4=0W
Linear dual color tuning
Warm white(Min. 2700K) Neutral white(4000K)
Cool white(Max. 6500K)
Recommended CCT range
PPW WMM dduuttyy((%%)) PWM duty(%)
Dimming curve for CCT
Dimming curve for RGBW/RGB/DIM
110000 9900 8800 7700 6600 5500 4400 3300 2200 1100
Gamma=1.0
10 20 30 40 50 60 70 80 90 100
Brightness(%)
100
Gamma=1.6
90 80 70 60 50 40 30 20 10
10 20 30 40 50 60 70 80 90 100
Brightness(%)
Malfunctions analysis & troubleshooting
Malfunctions
No light
Wrong color
Uneven intensity between front and rear,with voltage drop
Causes 1. No power. 2. Wrong connection or insecure.
1. Wrong connection of R/G/B/W wires.
1. Output cable is too long. 2. Wire diameter is too small. 3. Overload beyond power supply capability. 4. Overload beyond controller capability.
No response from the remote
1. The battery has no power. 2. Beyond controllable distance. 3. The controller did not match the remote.
Troubleshooting
1. Check the power. 2. Check the connection. 1. Reconnect R/G/B/W wires. 1. Reduce cable or loop supply. 2. Change wider wire. 3. Replace higher power supply. 4. Add power repeater.
1. Replace battery. 2. Reduce remote distance. 3. Re-match the remote.
