VC900-M8M ARM-Based In-Vehicle System

VC900-M8M: NXP i.MX8M ARM-Based In-vehicle System

Key Features:

• ARM-Based System
• Support Yocto Linux 2.5 and Android 9.0
• 6-axis IMU Sensor: 3 Accelerometer + 3 Gyroscope
• Rich I/O Connectivity:
  • 1 GbE
  • 4 COM
  • 1 CAN Bus
  • 2 USB 3.0
  • 1 Micro USB (OTG)
• Wide-Voltage: 9~36V vehicle power input with ACC/IGN
  function
• Wide-Temperature

Specification:

System:

• Processor: NXP i.MX8M Quad, Cortex-A53 1.3GHz (by model)
  NXP i.MX8M Dual, Cortex-A53 1.3GHz (by model)
• Memory: On board memory 2GB/4GB (by model)
  Single channel LPDDR4 up to 3200 MHz
• Graphics:
  • 1 x HDMI resolution up to 1920×1080 @ 60 Hz
  • Micro SD card slot
  • eMMC 5.1 16GB on board, support up to 64GB (optional)
• Storage: eMMC 5.1 16GB on board, support up to 64GB
  (optional)
• LED: 1 x Status LED
• Expansion:
  • 1 x M.2 2242/3042 B Key (USB 3.1 Gen1), Nano SIM Slot
    support
  • 1 x M.2 2230 E Key (PCIex1/USB2.0)

Sensor:

• 6 axis IMU (3 Accelerometer + 3 Gyroscope)

I/O:

Front I/O:

• Sensor: Ethernet Serial USB Display Audio
• Display:
  • 1 x HDMI with Amplifier to support 2W speaker (optional)
  • 1 x Line-out & 1 x MIC-in (internal header)

Rear I/O:

• Buttons: Power reset button
• CANbus: 1 x CANbus, DB-9
• Antenna: 4 x Antenna holes for LTE 4G, WiFi and GPS
• Serial:
  • 1 x RS-232/422/485 (COM1)
  • 2 x RS-232(TX,RX) (COM3/COM4)
  • 1 x RS-232(TX,RX,RTS,CTS) (COM2)

Power:

• Wide range 9~36V with ACC/IGN function
• Type Connector: 3-pole terminal block

OS Support Mechanism:

• Yocto Linux 2.5
• Android 9.0 (option)

Environment:

• Standards and Certifications:
  • CE
  • FCC
  • E-Mark R10
  • RoHS
  • UKCA
• Dimensions (W x H x D): 200 x 120 x 45mm
• Weight: 1.9kg
• Operating Temperature: 10 to 90% RH (non-condensing)
• Storage Temperature: Operating/non-operating: MIL-STD-810G
  Method 516.6, Procedure 1
• Relative Humidity: Operating/non-operating: MIL-STD-810G Method
  514.6, Category 4
• Certification: CE, FCC, E-Mark R10, RoHS, UKCA

Ordering Information:

Optional Items:

Packing List:

• 1 x VC900-M8M system unit
• 1 x 3-pole terminal block cable for power input
• 1 x Wall mount bracket/screw pack
• 1 x Quick installation guide

Product Usage Instructions:

1. Connect the VC900-M8M system unit to a power source using the
   included 3-pole terminal block cable for power input.
2. Connect the necessary peripherals to the rich I/O connectivity
   ports, including:
   • 1 GbE
   • 4 COM
   • 1 CAN Bus
   • 2 USB 3.0
   • 1 Micro USB (OTG)
3. If using a display, connect to the HDMI port with a compatible
   cable.
4. If using LTE 4G, WiFi, or GPS, connect the necessary antennas
   to the corresponding antenna holes.
5. If using an external speaker, connect to the Line-out or MIC-in
   port.
6. Power on the VC900-M8M system unit using the power reset button
   on the rear I/O panel.
7. The VC900-M8M system unit is compatible with Yocto Linux 2.5
   and Android 9.0 operating systems. Choose your desired OS and boot
   up the system.

VC900-M8M

NXP i.MX8M ARM-Based In-vehicle System
KEY FEATURES
ARM-Based System
Support Yocto Linux 2.5 and Android 9.0
6-axis IMU Sensor
3 Accelerometer + 3 Gyroscope
Rich I/O Connectivity
1 GbE, 4 COM, 1 CAN Bus, 2 USB 3.0, 1 Micro USB (OTG)
Wide-Voltage
9~36V vehicle power input with ACC/IGN function
Wide-Temperature
-20°C~65°C operation without active fan

PANEL

USB 3.0 LAN

Power input COM1 Power Button

COM4

COM2

HDMI OTG CAN
Front View

Rear View

COM3

SPECIFICATION

SYSTEM

Processor

Memory

GRAPHICS STORAGE
LED EXPANSION

Display External Internal Indicators M.2

SENSOR FRONT I/O

Sensor Ethernet Serial USB

Display Audio

REAR I/O

Buttons CANbus Antenna Serial

POWER OS SUPPORT MECHANISM

Type Connector Linux Android Construction Color Mounting

ENVIRONMENT
STANDARDS AND CERTIFICATIONS

Dimensions (W x H x D) Weight Operating Temperature Storage Temperature Relative Humidity Shock Vibration Certifciation

NXP i.MX8M Quad, Cortex-A53 1.3GHz (by model)

NXP i.MX8M Dual, Cortex-A53 1.3GHz (by model)

On board memory 2GB/4GB (by model)

Single channel LPDDR4 up to 3200 MHz

1 x HDMI

resolution up to 1920×1080 @ 60 Hz

Micro SD card slot

eMMC 5.1 16GB on board, support up to 64GB (optional)

1 x Status LED

1 x M.2 2242/3042 B Key (USB 3.1 Gen1), Nano SIM Slot support 1 x M.2 2230 E Key (PCIex1/USB2.0)

6 axis IMU (3 Accelerometer + 3 Gyroscope)

1 x Giga LAN, RJ-45

1 x RS-232/422/485 (COM1)

2 x USB 3.0, type A

1 x OTG, micro USB

1 x HDMI

with Amplifier to support 2W speaker (optional)

1 x Line-out & 1 x MIC-in (internal header)

1 x Power reset button

1 x CANbus, DB-9

4 x Antenna holes for LTE 4G, WiFi and GPS

1 x RS-232(TX,RX,RTS,CTS) (COM2) 2 x RS-232(TX,RX) (COM3/COM4)

Wide range 9~36V with ACC/IGN function

3-pole terminal block

Yocto Linux 2.5

Android 9.0 (option)

Sheet Metal

Black

DIN-Rail mount

Wall mount

200 x 120 x 45mm

1.9kg

-20 to 65°C

-40 to 85°C

10 to 90% RH (non-condensing)

Operating/non-operating: MIL-STD-810G Method 516.6, Procedure 1

Operating/non-operating: MIL-STD-810G Method 514.6, Category 4

CE, FCC, E-Mark R10, RoHS, UKCA

ORDERING INFORMATION

Model Name VC900-M8M VC900-M8M

Part Number 750-VC9000-000G 750-VC9000-100G

Description
VC900-M8M: Fanless, i.MX8M Quad, 4GB memory, 16GB eMMC, 1 LAN, 1 HDMI, 1 CAN, 4 COM, 2 USB 3.0, F/G RoHS
VC900-M8M: Fanless, i.MX8M Dual, 2GB memory, 16GB eMMC, 1 LAN, 1 HDMI, 1 CAN, 4 COM, 2 USB 3.0, F/G RoHS

OPTIONAL ITEMS

Optional Items LTE 4G WiFi + BT

Part Number 761-0EM06E-000G 612-RTL882-000G

Description 4G Module Kit, Quectel LTE-A Cat 6 M.2 Module, EM06-E Wi-Fi+BT, ENLI M.2 2230 Combo Module Card, RTL8822CE

PACKING LIST
1 x VC900-M8M system unit 1 x 3-pole terminal block cable for power input 1 x Wall mount bracket/screw pack 1 x Quick installation guide
