CBS-series Converters Bus Converter Power Module Type

Product Information

The DC-DC Converters Bus Converter is a low-profile isolated
power module type. It is a compact HALF BRICK converter that is
commonly used in the telecommunication market. The converter offers
high efficiency, high density, and high reliability. It does not
have built-in aluminum and tantalum electrolytic capacitors, and it
features built-in overcurrent, overvoltage, and thermal protection
circuits. The converter also has a remote ON/OFF function and a
mounting hole (M3 tapped). It is compliant with CE marking, Low
Voltage Directive, RoHS Directive, UKCA marking, Electrical
Equipment Safety Regulations, and RoHS Regulations. The safety
agency approvals include UL60950-1, C-UL recognized, and TuV
approved. The converter comes with a 5-year warranty and optional
parts such as a heat sink.

Product Usage Instructions

Ensure that the input voltage of the DC-DC converter is within
the specified range. The available input voltage options are DC18 –
36V or DC36 – 76V.
Select the desired output voltage from the available options:
1.8V, 2.5V, 3.3V, 5V, or 12V.
Refer to the model specifications to determine the maximum
output wattage for the selected output voltage.
If required, choose optional features such as remote ON/OFF or
mounting hole.
If additional cooling is needed, consider adding a heat sink as
an optional part.
Based on the chosen specifications, refer to the model number
table to find the appropriate model code.
Ensure that the DC-DC converter is properly installed and
connected according to the provided guidelines.
Verify that the output voltage of the converter is adjusted
within the specified range, if necessary.
Take note of the overcurrent protection, overvoltage
protection, and other safety features provided by the
converter.
If remote sensing or remote ON/OFF functionality is required,
follow the instructions provided to enable and control these
features.

For more detailed information and technical specifications,
please refer to the product manual available at http://www.cosel.co.jp/en/.

View Fullscreen

DC-DC Converters Bus Converter . Power Module Type

Low Profile Isolated

Safety

OCP

Approvals

OVP

Remote ON/OFF

CBS-series

Feature
Compact DC-DC Converter, “HALF BRICK” which has been standard size for Telecommunication Market High efficiency High density High reliability : not built-in aluminum and tantalum electrolytic capacitor Built-in overcurrent, overvoltage and thermal protection circuits Built-in remote ON/OFF Mounting hole (M3 tapped)
CE marking
Low Voltage Directive RoHS Directive
UKCA marking
Electrical Equipment Safety Regulations RoHS Regulations
Safety agency approvals
UL60950-1, C-UL recognized, TuV approved
5-year warranty

Optional parts

Optional parts Heat sink

Model
CBS50, CBS100, CBS200

www.cosel.co.jp/en/

December 27, 2022

CBS-1

DC-DC Converters Bus Converter . Power Module Type Ordering information

CBS50

CB S 50 48 12 -O

1Series name

2Single output

3Output wattage

4Input voltage

24 :DC18 – 36V

48 :DC36 – 76V

5Output voltage 6 Optional

R :with Remote ON/OFF

Positive logic control

T :with Mounting hole

f3.4 thru

FO:w i t h A d d i t i o n o f a

Heat sink

MODEL MAX OUTPUT WATTAGE[W] DC OUTPUT

CBS50241R8 CBS50242R5

21.06

29.25

1.8V 11.7A 2.5V 11.7A

CBS502403 CBS502405

38.6

50.0

3.3V 11.7A 5V 10A

CBS502412 50.4 12V 4.2A

SPECIFICATIONS

MODEL

CBS50241R8 CBS50242R5 CBS502403 CBS502405 CBS502412

VOLTAGE[V]

DC18 – 36

INPUT

CURRENT[A]

*1 1.24typ

1.58typ

2.04typ

2.48typ

2.39typ

EFFICIENCY[%]

*1 71typ

77typ

79typ

84typ

88typ

VOLTAGE[V]

1.8

2.5

3.3

CURRENT[A]

11.7

4.2

LINE REGULATION[mV] 10max

10max

24max

LOAD REGULATION[mV] 10max

10max

24max

RIPPLE[mVp-p]

-20 to +100C*2 80max -40 to -20C*2 120max

80max 120max

120max 150max

OUTPUT

RIPPLE NOISE[mVp-p] -20 to +100C*2 120max -40 to -20C*2 200max

120max 200max

150max 200max

TEMPERATURE REGULATION[mV] 0 to +65C 35max -40 to +100C 66max

35max 66max

50max 100max

120max 240max

DRIFT[mV]

*3 16max

16max

20max

40max

START-UP TIME[ms]

200max (DCIN 24V, Io=100%)

Fixed (TRM pin open), adjustable by external resistor

OUTPUT VOLTAGE ADJUSTMENT RANGE[V] *4

1.70 – 1.98 1.98 – 2.75 1.98 – 3.63 3.0 – 5.5

7.2 – 13.2

OUTPUT VOLTAGE SETTING[V] 1.77 – 1.88 2.46 – 2.61 3.25 – 3.45 4.90 – 5.20 11.74 – 12.46

OVERCURRENT PROTECTION PROTECTION OVERVOLTAGE PROTECTION[V] CIRCUIT AND OTHERS REMOTE SENSING
REMOTE ON/OFF

Works over 105% of rating and recovers automatically 2.16 – 2.88 3.00 – 4.00 4.00 – 5.50 5.75 – 7.00 13.80 – 16.80 Provided Provided (Negative logic L : ON, H : OFF)

CBS502415 51.0 15V 3.4A
CBS502415
2.44typ 87typ 15 3.4 30max 30max 120max 150max 150max 200max 150max 300max 60max
9.0 – 16.5 14.55 – 15.45
17.25 – 21.00

CBS502424 50.4 24V 2.1A
CBS502424
2.41typ 87typ 24 2.1 48max 48max 120max 150max 150max 250max 240max 480max 90max
14.4 – 26.4 23.28 – 24.72
27.60 – 33.60

CBS502428 50.4 28V 1.8A
CBS502428
2.41typ 87typ 28 1.8 56max 56max 120max 150max 150max 250max 280max 560max 90max
16.8 – 30.8 27.16 – 28.84
32.20 – 39.20

MODEL MAX OUTPUT WATTAGE[W] DC OUTPUT

CBS50481R8 CBS50482R5

21.06

29.25

1.8V 11.7A 2.5V 11.7A

CBS504803 CBS504805

38.6

50.0

3.3V 11.7A 5V 10A

CBS504812 50.4 12V 4.2A

SPECIFICATIONS

MODEL

CBS50481R8 CBS50482R5 CBS504803 CBS504805 CBS504812

VOLTAGE[V]

DC36 – 76

INPUT

CURRENT[A]

*1 0.62typ

0.79typ

1.01typ

1.23typ

1.18typ

EFFICIENCY[%]

*1 71typ

77typ

80typ

85typ

89typ

VOLTAGE[V]

1.8

2.5

3.3

CURRENT[A]

11.7

4.2

LINE REGULATION[mV] 10max

10max

24max

LOAD REGULATION[mV] 10max

10max

24max

RIPPLE[mVp-p]

-20 to +100C*2 80max -40 to -20C*2 120max

80max 120max

120max 150max

OUTPUT

RIPPLE NOISE[mVp-p] -20 to +100C*2 120max -40 to -20C*2 200max

120max 200max

150max 200max

TEMPERATURE REGULATION[mV] 0 to +65C 35max -40 to +100C 66max

35max 66max

50max 100max

120max 240max

DRIFT[mV]

*3 16max

16max

20max

40max

START-UP TIME[ms]

200max (DCIN 48V, Io=100%)

Fixed (TRM pin open), adjustable by external resistor

OUTPUT VOLTAGE ADJUSTMENT RANGE[V] *4

1.70 – 1.98 1.98 -2.75 1.98 – 3.63 3.0 – 5.5

7.2 – 13.2

OUTPUT VOLTAGE SETTING[V] 1.77 – 1.88 2.46 -2.61 3.25 – 3.45 4.90 – 5.20 11.74 – 12.46

OVERCURRENT PROTECTION PROTECTION OVERVOLTAGE PROTECTION[V] CIRCUIT AND OTHERS REMOTE SENSING
REMOTE ON/OFF

Works over 105% of rating and recovers automatically 2.16 – 2.88 3.00 – 4.00 4.00 – 5.50 5.75 – 7.00 13.80 – 16.80 Provided Provided (Negative logic L : ON, H : OFF)

CBS504815 51.0 15V 3.4A
CBS504815
1.21typ 88typ 15 3.4 30max 30max 120max 150max 150max 200max 150max 300max 60max
9.0 – 16.5 14.55 – 15.45
17.25 – 21.00

CBS504824 50.4 24V 2.1A
CBS504824
1.19typ 88typ 24 2.1 48max 48max 120max 150max 150max 250max 240max 480max 90max
14.4 – 26.4 23.28 – 24.72
27.60 – 33.60

CBS504828 50.4 28V 1.8A
CBS504828
1.19typ 88typ 28 1.8 56max 56max 120max 150max 150max 250max 280max 560max 90max
16.8 – 30.8 27.16 – 28.84
32.20 – 39.20

CBS-2

December 27, 2022

www.cosel.co.jp/en/

CBS50

GENERAL SPECIFICATIONS

INPUT-OUTPUT

ISOLATION INPUT-CASE PIN, BASE PLATE

OUTPUT-CASE PIN, BASE PLATE

OPERATING TEMP.,HUMID.AND ALTITUDE

STORAGE TEMP.,HUMID.AND ALTITUDE ENVIRONMENT
VIBRATION

IMPACT

SAFETY AGENCY APPROVALS

OTHERS

CASE SIZE/WEIGHT COOLING METHOD

DC1,500V or AC1,000V 1minute, Cutoff current = 10mA, DC500V 50MW min(20t15C) DC1,500V or AC1,000V 1minute, Cutoff current = 10mA, DC500V 50MW min(20t15C) AC500V 1minute, Cutoff current = 100mA, DC500V 50MW min (20t15C) -40 to +100C (On aluminum base plate), 20 – 95%RH (Non condensing) (Refer to “Derating”), 3,000m (10,000feet) max -40 to +100C, 20 – 95%RH (Non condensing), 9,000m (30,000feet) max 10 – 55Hz, 49.0m/s2 (5G), 3minutes period, 60minutes each along X, Y and Z axis 196.1m/s2 (20G), 11ms, once each along X, Y and Z axis UL60950-1, C-UL, EN62368-1 57.9X12.7X61.0mm [2.28X0.5X2.4 inches](WXHXD) / 83g max Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink)

*1 At rated input(DC24V,DC48V) and rated load. *2 Ripple and ripple noise is measured by using measuring board with recommended capacitor Co & the film capacitor 0.1mF.
Measured by 20MHz oscilloscope or Ripple-Noise meter (Equivalent to KEISOKU-GIKEN:RM101). *3 Drift is the change in DC output for an eight hour period after a half-hour warm-up at 25C, with the input voltage held constant at the rated input/output. *4 When the input voltage is in the range of DC18 – 20V, DC36 – 40V, output voltage adjustment range is 60 – 105% (except for 1R8/2R5).

External view
Base Plate(Aluminum) Case(PBT)

Lot No.

12.7 ±0.5
[0.5]

¶Recomending size for processing PCB (TOP VIEW)

7-º1.5 [0.06]

2-º2.5 [0.1]

7.62 [0.3] 7.62 10.16 15.24 10.16 [0.3] [0.4] [0.6] [0.4] 50.8 [2.0]

5.08 ±0.5
[0.2]

10.16 15.24 10.16
[0.4] [0.6] [0.4]

(4.8)
[0.19] 7-º1±0.1
[0.04] -VIN CASE
RC +VIN

57.9max
[2.28] 48.3 ±0.5
[1.9]

Name Plate

(5.1)

50.8 ±0.5

4-M3 Mounting Hole 2-º2 ±0.2
[0.08] -VOUT
-S
TRM +S
+VOUT

[0.2] [2] 61max [2.4]

10.16 7.62 7.62 10.16
[0.4] [0.3] [0.3] [0.4]

4-º3.5

48.3

[0.14] [1.9]

¶Dimensions in mm, [ ]= inches

¶Div. : 0.5inch

¶Weight : 83g max ¶Tolerance : ±0.3 [±0.012] ¶Case : PBT ¶Base Plate: Aluminum ¶Dimensions in mm, [ ]= inches ¶Mounting hole screwing torque
: 0.49N·m(5.0kgf·cm)max

Performance data
¡INPUT CURRENT CHARACTERISTICS (CBS502428)
5

INPUT CURRENT A

3
Io=100%
2
Io=50%
1

INPUT VOLTAGE V

¡INPUT CURRENT CHARACTERISTICS (CBS504828)
5

INPUT CURRENT A

Io=100%
1

Io=50%

INPUT VOLTAGE V

www.cosel.co.jp/en/

December 27, 2022

CBS-3

DC-DC Converters Bus Converter . Power Module Type Ordering information

CBS100

CB S 100 48 12 -O

1Series name

2Single output

3Output wattage

4Input voltage

24:DC18 – 36V

48:DC36 – 76V

5Output voltage 6 Optional

R :with Remote ON/OFF

Positive logic control

T :with Mounting hole

f3.4 thru

FO:w i t h A d d i t i o n o f a

Heat sink

MODEL MAX OUTPUT WATTAGE[W] DC OUTPUT

CBS100241R8 42.12 1.8V 23.4A

CBS100242R5 58.50 2.5V 23.4A

CBS1002403 77.2 3.3V 23.4A

CBS1002405 100.0 5V 20A

CBS1002412 100.8 12V 8.4A

SPECIFICATIONS

MODEL

CBS100241R8 CBS100242R5 CBS1002403 CBS1002405 CBS1002412

VOLTAGE[V]

DC18 – 36

INPUT

CURRENT[A]

*1 2.47typ

3.17typ

4.07typ

5.02typ

4.77typ

EFFICIENCY[%]

*1 71typ

77typ

79typ

83typ

88typ

VOLTAGE[V]

1.8

2.5

3.3

CURRENT[A]

23.4

8.4

LINE REGULATION[mV] 10max

10max

24max

LOAD REGULATION[mV] 10max

10max

24max

RIPPLE[mVp-p]

-20 to +100C*2 80max -40 to -20C*2 120max

80max 120max

120max 150max

OUTPUT

RIPPLE NOISE[mVp-p] -20 to +100C*2 120max -40 to -20C*2 200max

120max 200max

150max 200max

TEMPERATURE REGULATION[mV] 0 to +65C 35max -40 to +100C 66max

35max 66max

50max 100max

120max 240max

DRIFT[mV]

*3 16max

16max

20max

40max

START-UP TIME[ms]

200max (DCIN 24V, Io=100%)

Fixed (TRM pin open), adjustable by external resistor

OUTPUT VOLTAGE ADJUSTMENT RANGE[V] *4

1.70 – 1.98 1.98 – 2.75 1.98 – 3.63 3.0 – 5.5

7.2 – 13.2

OUTPUT VOLTAGE SETTING[V] 1.77 – 1.88 2.46 – 2.61 3.25 – 3.45 4.90 – 5.20 11.74 – 12.46

OVERCURRENT PROTECTION PROTECTION OVERVOLTAGE PROTECTION[V] CIRCUIT AND OTHERS REMOTE SENSING
REMOTE ON/OFF

Works over 105% of rating and recovers automatically 2.16 – 2.88 3.00 – 4.00 4.00 – 5.50 5.75 – 7.00 13.80 – 16.80 Provided Provided (Negative logic L : ON, H : OFF)

CBS1002415 100.5 15V 6.7A
CBS1002415
4.81typ 87typ 15 6.7 30max 30max 120max 150max 150max 200max 150max 300max 60max
9.0 – 16.5 14.55 – 15.45
17.25 – 21.00

CBS1002424 100.8 24V 4.2A
CBS1002424
4.83typ 87typ 24 4.2 48max 48max 120max 150max 150max 250max 240max 480max 90max
14.4 – 26.4 23.28 – 24.72
27.60 – 33.60

CBS1002428 100.8 28V 3.6A
CBS1002428
4.83typ 87typ 28 3.6 56max 56max 120max 150max 150max 250max 280max 560max 90max
16.8 – 30.8 27.16 – 28.84
32.20 – 39.20

MODEL MAX OUTPUT WATTAGE[W] DC OUTPUT

CBS100481R8 42.12 1.8V 23.4A

CBS100482R5 58.50 2.5V 23.4A

CBS1004803 77.2 3.3V 23.4A

CBS1004805 100.0 5V 20A

CBS1004812 100.8 12V 8.4A

SPECIFICATIONS

MODEL

CBS100481R8 CBS100482R5 CBS1004803 CBS1004805 CBS1004812

VOLTAGE[V]

DC36 – 76

INPUT

CURRENT[A]

*1 1.24typ

1.58typ

2.01typ

2.48typ

2.36typ

EFFICIENCY[%]

*1 71typ

77typ

80typ

84typ

89typ

VOLTAGE[V]

1.8

2.5

3.3

CURRENT[A]

23.4

8.4

LINE REGULATION[mV] 10max

10max

24max

LOAD REGULATION[mV] 10max

10max

24max

RIPPLE[mVp-p]

-20 to +100C*2 80max -40 to -20C*2 120max

80max 120max

120max 150max

OUTPUT

RIPPLE NOISE[mVp-p] -20 to +100C*2 120max -40 to -20C*2 200max

120max 200max

150max 200max

TEMPERATURE REGULATION[mV] 0 to +65C 35max -40 to +100C 66max

35max 66max

50max 100max

120max 240max

DRIFT[mV]

*3 16max

16max

20max

40max

START-UP TIME[ms]

200max (DCIN 48V, Io=100%)

Fixed (TRM pin open), adjustable by external resistor

OUTPUT VOLTAGE ADJUSTMENT RANGE[V] *4

1.70 – 1.98 1.98 -2.75 1.98 – 3.63 3.0 – 5.5

7.2 – 13.2

OUTPUT VOLTAGE SETTING[V] 1.77 – 1.88 2.46 -2.61 3.25 – 3.45 4.90 – 5.20 11.74 – 12.46

OVERCURRENT PROTECTION PROTECTION OVERVOLTAGE PROTECTION[V] CIRCUIT AND OTHERS REMOTE SENSING
REMOTE ON/OFF

Works over 105% of rating and recovers automatically 2.16 – 2.88 3.00 – 4.00 4.00 – 5.50 5.75 – 7.00 13.80 – 16.80 Provided Provided (Negative logic L : ON, H : OFF)

CBS1004815 100.5 15V 6.7A
CBS1004815
2.38typ 88typ 15 6.7 30max 30max 120max 150max 150max 200max 150max 300max 60max
9.0 – 16.5 14.55 – 15.45
17.25 – 21.00

CBS1004824 100.8 24V 4.2A
CBS1004824
2.39typ 88typ 24 4.2 48max 48max 120max 150max 150max 250max 240max 480max 90max
14.4 – 26.4 23.28 – 24.72
27.60 – 33.60

CBS1004828 100.8 28V 3.6A
CBS1004828
2.39typ 88typ 28 3.6 56max 56max 120max 150max 150max 250max 280max 560max 90max
16.8 – 30.8 27.16 – 28.84
32.20 – 39.20

CBS-4

December 27, 2022

www.cosel.co.jp/en/

CBS100

GENERAL SPECIFICATIONS

INPUT-OUTPUT

ISOLATION INPUT-CASE PIN, BASE PLATE

OUTPUT-CASE PIN, BASE PLATE

OPERATING TEMP.,HUMID.AND ALTITUDE

STORAGE TEMP.,HUMID.AND ALTITUDE ENVIRONMENT
VIBRATION

IMPACT

SAFETY AGENCY APPROVALS

OTHERS

CASE SIZE/WEIGHT COOLING METHOD

DC1,500V or AC1,000V 1minute, Cutoff current = 10mA, DC500V 50MW min(20t15C) DC1,500V or AC1,000V 1minute, Cutoff current = 10mA, DC500V 50MW min(20t15C) AC500V 1minute, Cutoff current = 100mA, DC500V 50MW min (20t15C) -40 to +100C (On aluminum base plate), 20 – 95%RH (Non condensing) (Refer to “Derating”), 3,000m (10,000feet) max -40 to +100C, 20 – 95%RH (Non condensing), 9,000m (30,000feet) max 10 – 55Hz, 49.0m/s2 (5G), 3minutes period, 60minutes each along X, Y and Z axis 196.1m/s2 (20G), 11ms, once each along X, Y and Z axis UL60950-1, C-UL, EN62368-1 57.9X12.7X61.0mm [2.28X0.5X2.4 inches] (WXHXD) / 83g max Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink)

*1 At rated input(DC24V,DC48V) and rated load. *2 Ripple and ripple noise is measured by using measuring board with recommended capacitor Co & the film capacitor 0.1mF.
Measured by 20MHz oscilloscope or Ripple-Noise meter (Equivalent to KEISOKU-GIKEN:RM101). *3 Drift is the change in DC output for an eight hour period after a half-hour warm-up at 25C, with the input voltage held constant at the rated input/output. *4 When the input voltage is in the range of DC18 – 20V, DC36 – 40V output voltage adjustment range is 60 – 105% (except for 1R8/2R5).

External view
Base Plate(Aluminum) Case(PBT)

Lot No.

12.7 ±0.5
[0.5]

¶Recomending size for processing PCB (TOP VIEW)

7-º1.5 [0.06]

2-º2.5 [0.1]

7.62 [0.3] 7.62 10.16 15.24 10.16 [0.3] [0.4] [0.6] [0.4] 50.8 [2.0]

5.08 ±0.5
[0.2]

10.16 15.24 10.16
[0.4] [0.6] [0.4]

(4.8)
[0.19] 7-º1±0.1
[0.04] -VIN CASE
RC +VIN

57.9max
[2.28] 48.3 ±0.5
[1.9]

Name Plate

(5.1)

50.8 ±0.5

4-M3 Mounting Hole 2-º2 ±0.2
[0.08] -VOUT
-S
TRM +S
+VOUT

[0.2] [2] 61max [2.4]

10.16 7.62 7.62 10.16
[0.4] [0.3] [0.3] [0.4]

4-º3.5

48.3

[0.14] [1.9]

¶Dimensions in mm, [ ]= inches ¶Div. : 0.5inch

¶Weight : 83g max ¶Tolerance : ±0.3 [±0.012] ¶Case : PBT ¶Base Plate: Aluminum ¶Dimensions in mm, [ ]= inches ¶Mounting hole screwing torque
: 0.49N·m(5.0kgf·cm)max

Performance data
¡INPUT CURRENT CHARACTERISTICS (CBS1002428)
10

INPUT CURRENT A

6
Io=100%
4
Io=50%
2

INPUT VOLTAGE V

¡INPUT CURRENT CHARACTERISTICS (CBS1004828)
10

INPUT CURRENT A

Io=100%
2

Io=50%

INPUT VOLTAGE V

www.cosel.co.jp/en/

December 27, 2022

CBS-5

DC-DC Converters Bus Converter . Power Module Type Ordering information

CBS200

CB S 200 48 12 -O

1Series name

2Single output

3Output wattage

4Input voltage

24:DC18 – 36V

48:DC36 – 76V

5Output voltage 6 Optional

R :with Remote ON/OFF

Positive logic control

T :with Mounting hole

f3.4 thru

FO:w i t h A d d i t i o n o f a

Heat sink

MODEL MAX OUTPUT WATTAGE[W] DC OUTPUT

CBS200241R8 CBS200242R5 CBS2002403 CBS2002405 CBS2002412 CBS2002415 CBS2002424 CBS2002428

63.00

87.50

115.5

150.0

200.4

201.0

201.6

1.8V 35A 2.5V 35A 3.3V 35A 5V 30A 12V 16.7A 15V 13.4A 24V 8.4A 28V 7.2A

SPECIFICATIONS

MODEL

CBS200241R8 CBS200242R5 CBS2002403 CBS2002405 CBS2002412

VOLTAGE[V]

DC18 – 36

INPUT

CURRENT[A]

*1 3.75typ 4.80typ 6.09typ 7.62typ 9.60typ

EFFICIENCY[%]

*1 70typ

76typ

79typ

82typ

87typ

VOLTAGE[V]

1.8

2.5

3.3

CURRENT[A]

16.7

LINE REGULATION[mV] 10max

10max

24max

LOAD REGULATION[mV] 10max

10max

24max

RIPPLE[mVp-p]

-20 to +100C*2 80max -40 to -20C*2 120max

80max 120max

120max 150max

OUTPUT

RIPPLE NOISE[mVp-p] -20 to +100C*2 120max -40 to -20C*2 200max

120max 200max

150max 200max

TEMPERATURE REGULATION[mV] 0 to +65C 35max -40 to +100C 66max

35max 66max

50max 100max

120max 240max

DRIFT[mV]

*3 16max

16max

20max

40max

START-UP TIME[ms]

200max (DCIN 24V, Io=100%)

Fixed (TRM pin open), adjustable by external resistor OUTPUT VOLTAGE ADJUSTMENT RANGE[V] *4
1.70 – 1.98 1.98 – 2.75 1.98 – 3.63 3.0 – 5.5 7.2 – 13.2

OUTPUT VOLTAGE SETTING[V] 1.77 – 1.88 2.46 – 2.61 3.25 – 3.45 4.90 – 5.20 11.74 – 12.46

OVERCURRENT PROTECTION PROTECTION OVERVOLTAGE PROTECTION[V] CIRCUIT AND OTHERS REMOTE SENSING
REMOTE ON/OFF

Works over 105% of rating and recovers automatically 2.16 – 2.88 3.00 – 4.00 4.00 – 5.50 5.75 – 7.00 13.80 – 16.80 Provided Provided (Negative logic L : ON, H : OFF)

CBS2002415
9.63typ 87typ 15 13.4 30max 30max 120max 150max 150max 200max 150max 300max 60max
9.0 – 16.5 14.55 – 15.45
17.25 – 21.00

CBS2002424
9.66typ 87typ 24 8.4 48max 48max 120max 150max 150max 250max 240max 480max 90max
14.4 – 26.4 23.28 – 24.72
27.60 – 33.60

CBS2002428
9.66typ 87typ 28 7.2 56max 56max 120max 150max 150max 250max 280max 560max 90max
16.8 – 30.8 27.16 – 28.84
32.20 – 39.20

MODEL MAX OUTPUT WATTAGE[W] DC OUTPUT

CBS200481R8 CBS200482R5 CBS2004803 CBS2004805 CBS2004812 CBS2004815 CBS2004824 CBS2004828 CBS2004848

63.00

87.50

115.5

150.0

200.4

201.0

201.6

1.8V 35A 2.5V 35A 3.3V 35A 5V 30A 12V 16.7A 15V 13.4A 24V 8.4A 28V 7.2A 48V 4.2A

SPECIFICATIONS

MODEL

CBS200481R8 CBS200482R5 CBS2004803 CBS2004805 CBS2004812

VOLTAGE[V]

DC36 – 76

INPUT

CURRENT[A]

*1 1.88typ 2.40typ 3.01typ 3.77typ 4.74typ

EFFICIENCY[%]

*1 70typ

76typ

80typ

83typ

88typ

VOLTAGE[V]

1.8

2.5

3.3

CURRENT[A]

16.7

LINE REGULATION[mV] 10max

10max

24max

LOAD REGULATION[mV] 10max

10max

24max

RIPPLE[mVp-p]

-20 to +100C*2 80max -40 to -20C*2 120max

80max 120max

120max 150max

OUTPUT

RIPPLE NOISE[mVp-p] -20 to +100C*2 120max -40 to -20C*2 200max

120max 200max

150max 200max

TEMPERATURE REGULATION[mV] 0 to +65C 35max -40 to +100C 66max

35max 66max

50max 100max

120max 240max

DRIFT[mV]

*3 16max

16max

20max

40max

START-UP TIME[ms]

200max (DCIN 48V, Io=100%)

Fixed (TRM pin open), adjustable by external resistor OUTPUT VOLTAGE ADJUSTMENT RANGE[V] *4
1.70 – 1.98 1.98 -2.75 1.98 – 3.63 3.0 – 5.5 7.2 – 13.2

OUTPUT VOLTAGE SETTING[V] 1.77 – 1.88 2.46 -2.61 3.25 – 3.45 4.90 – 5.20 11.74 – 12.46

OVERCURRENT PROTECTION PROTECTION OVERVOLTAGE PROTECTION[V] CIRCUIT AND OTHERS REMOTE SENSING
REMOTE ON/OFF

Works over 105% of rating and recovers automatically 2.16 – 2.88 3.00 – 4.00 4.00 – 5.50 5.75 – 7.00 13.80 – 16.80 Provided Provided (Negative logic L : ON, H : OFF)

CBS2004815
4.76typ 88typ 15 13.4 30max 30max 120max 150max 150max 200max 150max 300max 60max
9.0 – 16.5 14.55 – 15.45
17.25 – 21.00

CBS2004824
4.77typ 88typ 24 8.4 48max 48max 120max 150max 150max 250max 240max 480max 90max
14.4 – 26.4 23.28 – 24.72
27.60 – 33.60

CBS2004828
4.77typ 88typ 28 7.2 56max 56max 120max 150max 150max 250max 280max 560max 90max
16.8 – 30.8 27.16 – 28.84
32.20 – 39.20

CBS2004848
4.77typ 88typ 48 4.2 96max 96max 200max 250max 250max 400max 480max 960max 180max
43.2 – 52.8 46.56 – 49.44
55.20 – 67.20

CBS-6

December 27, 2022

www.cosel.co.jp/en/

CBS200

GENERAL SPECIFICATIONS

INPUT-OUTPUT

ISOLATION INPUT-CASE PIN, BASE PLATE

OUTPUT-CASE PIN, BASE PLATE

OPERATING TEMP.,HUMID.AND ALTITUDE

STORAGE TEMP.,HUMID.AND ALTITUDE ENVIRONMENT
VIBRATION

IMPACT

SAFETY AGENCY APPROVALS

OTHERS

CASE SIZE/WEIGHT COOLING METHOD

DC1,500V or AC1,000V 1minute, Cutoff current = 10mA, DC500V 50MW min(20t15C) DC1,500V or AC1,000V 1minute, Cutoff current = 10mA, DC500V 50MW min(20t15C) AC500V 1minute, Cutoff current = 100mA, DC500V 50MW min (20t15C) -40 to +100C (On aluminum base plate), 20 – 95%RH (Non condensing) (Refer to “Derating”), 3,000m (10,000feet) max -40 to +100C, 20 – 95%RH (Non condensing), 9,000m (30,000feet) max 10 – 55Hz, 49.0m/s2 (5G), 3minutes period, 60minutes each along X, Y and Z axis 196.1m/s2 (20G), 11ms, once each along X, Y and Z axis UL60950-1, C-UL, EN62368-1 57.9X12.7X61.0mm [2.28X0.5X2.4 inches] (WXHXD) / 83g max Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink)

External view
Base Plate(Aluminum) Case(PBT)

Lot No.

12.7 ±0.5
[0.5]

¶Recomending size for processing PCB (TOP VIEW)

7-º1.5 [0.06]

2-º2.5 [0.1]

7.62 [0.3] 7.62 10.16 15.24 10.16 [0.3] [0.4] [0.6] [0.4] 50.8 [2.0]

5.08 ±0.5
[0.2]

10.16 15.24 10.16
[0.4] [0.6] [0.4]

(4.8)
[0.19] 7-º1±0.1
[0.04] -VIN CASE
RC
+VIN

57.9max
[2.28] 48.3 ±0.5
[1.9]

Name Plate

(5.1)

50.8 ±0.5

4-M3 Mounting Hole 2-º2 ±0.2
[0.08] -VOUT
-S
TRM +S
+VOUT

[0.2] [2] 61max [2.4]

10.16 7.62 7.62 10.16
[0.4] [0.3] [0.3] [0.4]

4-º3.5

48.3

[0.14] [1.9]

¶Dimensions in mm, [ ]= inches ¶Div. : 0.5inch

¶Weight : 83g max ¶Tolerance : ±0.3 [±0.012] ¶Case : PBT ¶Base Plate: Aluminum ¶Dimensions in mm, [ ]= inches ¶Mounting hole screwing torque
: 0.49N·m(5.0kgf·cm)max

Performance data
¡INPUT CURRENT CHARACTERISTICS (CBS2002428)
20

¡INPUT CURRENT CHARACTERISTICS (CBS2004828)
20

INPUT CURRENT A

Io=100%

Io=50%

INPUT VOLTAGE V

www.cosel.co.jp/en/

December 27, 2022

Io=100%

Io=50%

INPUT VOLTAGE V

CBS-7

DC-DC Converters Bus Converter . Power Module Type Ordering information

CBS350

CB S 350 48 12 -O

1Series name

2Single output

3Output wattage

4Input voltage 5Output voltage

6 Optional

R :with Remote ON/OFF

Positive logic control

T :with Mounting hole

f3.4 thru

MODEL MAX OUTPUT WATTAGE[W] DC OUTPUT

CBS3502412 CBS3502424 CBS3502428 CBS3502432 CBS3502448 CBS3504812 CBS3504824 CBS3504828 CBS3504832 CBS3504848

300

348

350

352

302

348

350

352

350

12V 25A 24V 14.5A 28V 12.5A 32V 11A 48V 6.3A 12V 29A 24V 14.5A 28V 12.5A 32V 11A 48V 7.3A

SPECIFICATIONS

MODEL

CBS3502412 CBS3502424 CBS3502428 CBS3502432 CBS3502448 CBS3504812 CBS3504824 CBS3504828 CBS3504832 CBS3504848

VOLTAGE[V]

DC20 – 36

DC36 – 76

DC36 – 60

INPUT

CURRENT[A]

*1 14.5typ 16.7typ 16.4typ 16.5typ 14.0typ 8.33typ 8.15typ 8.10typ 8.15typ 8.15typ

EFFICIENCY[%]

*1 86typ 87typ 89typ 89typ 90typ 87typ 89typ 90typ 90typ 91typ

VOLTAGE[V]

CURRENT[A]

14.5

12.5

6.3

14.5

12.5

7.3

LINE REGULATION[mV] 24max 48max 56max 64max 96max 24max 48max 56max 64max 96max

LOAD REGULATION[mV] 24max 48max 56max 64max 96max 24max 48max 56max 64max 96max

-20 to +100C*2 120max 150max 180max 180max 300max 120max 150max 180max 180max 300max

RIPPLE[mVp-p] -40 to -20C*2 150max 180max 220max 220max 360max 150max 180max 220max 220max 360max

0 to 15%Load*2 240max 300max 360max 360max 600max 240max 300max 360max 360max 600max

-20 to +100C*2 150max 180max 220max 220max 360max 150max 180max 220max 220max 360max

OUTPUT RIPPLE NOISE[mVp-p] -40 to -20C*2 200max 250max 280max 280max 500max 200max 250max 280max 280max 500max

0 to 15%Load*2 300max 360max 440max 440max 720max 300max 360max 440max 440max 720max

TEMPERATURE REGULATION[mV] 0 to +65C 120max 240max 280max 320max 480max 120max 240max 280max 320max 480max -40 to +100C 240max 480max 560max 640max 960max 240max 480max 560max 640max 960max

DRIFT[mV]

*3 40max 90max 90max 120max 180max 40max 90max 90max 120max 180max

START-UP TIME[ms]

200max (DCIN 24V, Io=100%)

200max (DCIN 48V, Io=100%)

Fixed (TRM pin open), adjustable by external resistor OUTPUT VOLTAGE ADJUSTMENT RANGE[V] *4
7.2 – 13.2 14.4 – 26.4 16.8 – 30.8 25.6 – 35.2 38.4 – 52.8 7.2 – 13.2 14.4 – 26.4 16.8 – 30.8 25.6 – 35.2 38.4 – 55.2

OUTPUT VOLTAGE SETTING[V] *1 11.88 – 12.12 23.76 – 24.24 27.72 – 28.28 31.68 – 32.32 47.52 – 48.48 11.88 – 12.12 23.76 – 24.24 27.72 – 28.28 31.68 – 32.32 47.52 – 48.48

OVERCURRENT PROTECTION Works over 105% of rating and recovers automatically

PROTECTION OVERVOLTAGE PROTECTION[V] 13.80 – 16.80 27.60 – 33.60 32.20 – 39.20 36.80 – 44.80 57.50 – 63.00 13.80 – 16.80 27.60 – 33.60 32.20 – 39.20 36.80 – 44.80 57.50 – 63.00

CIRCUIT AND

OTHERS REMOTE SENSING

Provided

REMOTE ON/OFF

Provided (Negative logic L : ON, H : OFF)

INPUT-OUTPUT

DC1,500V or AC1,000V 1minute, Cutoff current = 10mA, DC500V 50MW min(20t15C)

ISOLATION INPUT-BASE PLATE

DC1,500V or AC1,000V 1minute, Cutoff current = 10mA, DC500V 50MW min(20t15C)

OUTPUT-BASE PLATE AC500V 1minute, Cutoff current = 100mA, DC500V 50MW min (20t15C)

OPERATING TEMP.,HUMID.AND ALTITUDE -40 to +100C (On aluminum base plate), 20 – 95%RH (Non condensing) (Refer to DERATING CURVE), 3,000m (10,000feet) max

STORAGE TEMP.,HUMID.AND ALTITUDE ENVIRONMENT
VIBRATION

-40 to +100C, 20 – 95%RH (Non condensing), 9,000m (30,000feet) max 10 – 55Hz, 49.0m/s2 (5G), 3minutes period, 60minutes each along X, Y and Z axis

IMPACT

196.1m/s2 (20G), 11ms, once each along X, Y and Z axis

SAFETY AGENCY APPROVALS UL60950-1, C-UL, EN62368-1

CASE SIZE/WEIGHT OTHERS
COOLING METHOD

57.9X12.7X61.0mm [2.28X0.5X2.4 inches] (WXHXD) / 83g max Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink)

*1 At rated input(DC24V,DC48V), rated load, and aluminum base plate temperature 25C. *2 Ripple and ripple noise is measured by using measuring board with recommended capacitor Co & the film capacitor 0.1mF. Refer to the manual. *3 Drift is the change in DC output for an eight hour period after a half-hour warm-up at 25C, with the input voltage held constant at the rated input/output. *4 When the input voltage is in the range of DC20 – 22V, DC36 – 40V, output voltage is limited. Refer to the manual.

CBS-8

December 27, 2022

www.cosel.co.jp/en/

External view
Base Plate(Aluminum) Case(PBT)

Lot No.

12.7t0.5
[0.5]

5.08 t0.5
[0.2]

10.16 15.24 10.16
[0.4] [0.6] [0.4]

(4.8)
[0.19] 7-º1t0.1
[0.04] -VIN NC
RC
+VIN

57.9max
[2.28] 48.3 t0.5
[1.9]

Name Plate

(5.1)

50.8 t0.5

4-M3 Mounting Hole 2-º2 t0.2
[0.08] -VOUT
-S
TRM +S
+VOUT

[0.2] [2] 61max [2.4]

10.16 7.62 7.62 10.16
[0.4] [0.3] [0.3] [0.4]

CBS350

¶Recomending size for processing PCB (TOP VIEW)

7-º1.5 [0.06]

2-º2.5 [0.1]

7.62 [0.3] 7.62 10.16 15.24 10.16 [0.3] [0.4] [0.6] [0.4] 50.8 [2.0]

4-º3.5

48.3

[0.14] [1.9]

¶Dimensions in mm, [ ]= inches

¶Div. : 0.5inch

¶Weight : 83g max ¶Tolerance : t0.3 [t0.012] ¶Case : PBT ¶Base Plate: Aluminum ¶Dimensions in mm, [ ]= inches ¶Mounting hole screwing torque
: 0.49N·m(5.0kgf·cm)max

www.cosel.co.jp/en/

December 27, 2022

CBS-9

DC-DC Converters Bus Converter . Power Module Type Ordering information

CBS450

CB S 450 48 28 -O

1Series name

2Single output

3Output wattage

4Input voltage 5Output voltage

6 Optional

R :with Remote ON/OFF

Positive logic control

T :with Mounting hole

f3.4 thru

MODEL MAX OUTPUT WATTAGE[W] DC OUTPUT

CBS4504824 456 24V 19A

CBS4504828 448 28V 16A

CBS4504832 400 32V 12.5A

SPECIFICATIONS

MODEL

CBS4504824

CBS4504828

CBS4504832

VOLTAGE[V]

DC38 – 60

DC36 – 76

INPUT

CURRENT[A]

*1 10.6typ

10.5typ

9.3typ

EFFICIENCY[%]

*1 90typ

91typ

VOLTAGE[V]

CURRENT[A]

12.5

LINE REGULATION[mV] 48max

56max

64max

LOAD REGULATION[mV] 48max

56max

64max

-20 to +100C*2 180max

210max

RIPPLE[mVp-p] -40 to -20C*2 220max

260max

0 to 15%Load*2 360max

430max

-20 to +100C*2 220max

260max

OUTPUT RIPPLE NOISE[mVp-p] -40 to -20C*2 280max

330max

0 to 15%Load*2 440max

520max

TEMPERATURE REGULATION[mV] 0 to +65C 240max -40 to +100C 480max

280max 560max

DRIFT[mV]

*3 90max

90max

120max

START-UP TIME[ms]

200max (DCIN 48V, Io=100%)

Fixed (TRM pin open), adjustable by external resistor

OUTPUT VOLTAGE ADJUSTMENT RANGE[V] *4

19.2 – 26.0

16.8 – 32.2

25.6 – 35.2

OUTPUT VOLTAGE SETTING[V] *1 23.52 – 24.48

27.44 – 28.56

31.36 – 32.64

OVERCURRENT PROTECTION Works over 105% of rating and recovers automatically

PROTECTION OVERVOLTAGE PROTECTION[V] 27.60 – 33.60

CIRCUIT AND

OTHERS REMOTE SENSING

Provided

32.20 – 39.20

REMOTE ON/OFF

Provided (Negative logic L : ON, H : OFF)

36.80 – 44.80

INPUT-OUTPUT

DC1,500V or AC1,000V 1minute, Cutoff current = 10mA, DC500V 50MW min(20t15C)

ISOLATION INPUT-BASE PLATE

DC1,500V or AC1,000V 1minute, Cutoff current = 10mA, DC500V 50MW min(20t15C)

OUTPUT-BASE PLATE AC500V 1minute, Cutoff current = 100mA, DC500V 50MW min (20t15C)

OPERATING TEMP.,HUMID.AND ALTITUDE -40 to +100C (On aluminum base plate), 20 – 95%RH (Non condensing) (Refer to “Derating”), 3,000m (10,000feet) max

STORAGE TEMP.,HUMID.AND ALTITUDE ENVIRONMENT
VIBRATION

-40 to +100C, 20 – 95%RH (Non condensing), 9,000m (30,000feet) max 10 – 55Hz, 49.0m/s2 (5G), 3minutes period, 60minutes each along X, Y and Z axis

IMPACT

196.1m/s2 (20G), 11ms, once each along X, Y and Z axis

SAFETY AGENCY APPROVALS UL60950-1, C-UL, EN62368-1

CASE SIZE/WEIGHT OTHERS
COOLING METHOD

57.9X12.7X61.0mm [2.28X0.5X2.4 inches] (WXHXD) / 83g max Conduction cooling (e.g. heat radiation from the aluminum base plate to the attached heat sink)

*1 At rated input(DC48V), rated load, and aluminum base plate temperature 25C. *2 Ripple and ripple noise is measured by using measuring board with recommended capacitor Co & the film capacitor 0.1mF. Refer to the manual. *3 Drift is the change in DC output for an eight hour period after a half-hour warm-up at 25C, with the input voltage held constant at the rated input/output. *4 Refer to the manual for the input range.

CBS-10

December 27, 2022

www.cosel.co.jp/en/

External view
Base Plate(Aluminum) Case(PBT)

Lot No.

12.7t0.5
[0.5]

5.08 t0.5
[0.2]

10.16 15.24 10.16
[0.4] [0.6] [0.4]

(4.8)
[0.19] 7-º1t0.1
[0.04] -VIN NC
RC
+VIN

57.9max
[2.28] 48.3 t0.5
[1.9]

Name Plate

(5.1)

50.8 t0.5

4-M3 Mounting Hole 2-º2 t0.2
[0.08] -VOUT
-S
TRM +S
+VOUT

[0.2] [2] 61max [2.4]

10.16 7.62 7.62 10.16
[0.4] [0.3] [0.3] [0.4]

CBS450

¶Recomending size for processing PCB (TOP VIEW)

7-º1.5 [0.06]

2-º2.5 [0.1]

7.62 [0.3] 7.62 10.16 15.24 10.16 [0.3] [0.4] [0.6] [0.4] 50.8 [2.0]

4-º3.5

48.3

[0.14] [1.9]

¶Dimensions in mm, [ ]= inches

¶Div. : 0.5inch

¶Weight : 83g max ¶Tolerance : t0.3 [t0.012] ¶Case : PBT ¶Base Plate: Aluminum ¶Dimensions in mm, [ ]= inches ¶Mounting hole screwing torque
: 0.49N·m(5.0kgf·cm)max

www.cosel.co.jp/en/

December 27, 2022

CBS-11

CBS-series

Pin Configuration

-VIN 4

(CBS50/100/200) CASE (CBS350/450)NC

RC 2

+VIN 1

4-Mounting hole
9 -VOUT 8 -S 7 TRM 6 +S 5 +VOUT
bottom view

No. Pin Name 1 +VIN 2 RC

Function +DC input Remote ON/OFF

3 NC CASE
4 -VIN

No connection (CBS350/450) Wiring base plate (CBS50/100/200) -DC input

5 +VOUT 6 +S 7 TRM

+DC output +Remote sensing Adjustment of output voltage

8 -S 9 -VOUT

-Remote sensing -DC output

Mounting hole Mounting hole

ImplementationMounting Method
Mounting method
¡When multiple power modules are used side by side, position them with sufficient spaces to allow adequate air ventilation so that the aluminum base plate temperature of each power module will remain within the temperature range shown in the derating”.
¡Do not pass the DC input pattern underneath the power module as this will increase conducted noise. Place the DC input pattern away from the power module. Do not pass the DC output pattern underneath the power module as this will increase output noise. Place the DC output pattern away from the power module.
¡High frequency noise is radiated from the power module. When mounting the power module on a PCB, leave a copper pattern on the PCB to let it act as a shield and connect this pattern to the CASE pin (CBS50/100/200) or the mounting hole.

¡When a heat sink cannot be fixed on the base plate side, order the power module with “-T”option. A heat sink can be mounted by affixing a M3 tap on the heat sink. In case of CBS350/450, make sure a mounting hole will be connected to a grounding capacitor CY.

Standard Optional : -T

Mounting hole
M3 tapped f3.4 thru

Stress onto the pins
¡Applying excessive stress to the input or output pins of the power module may damage internal connections. Avoid applying stress in excess of that shown in right figure.
¡Input and output pins are soldered onto the internal PCB. Do not bend or pull the leads with excessive force.
¡As unexpected stress may be applied to the pins, set the diameter of the PCB mounting hole at 3.5mm.
¡As unexpected stress may be applied to the pins from vibration or shock, fix the power module by using the mounting holes with screws to reduce stress.
¡Fix the power module to the PCB with the screws before soldering the input and output pins to prevent the PCB pattern being damaged.

Soldering temperature

¡Flow soldering

: 260ª for up to 15 seconds.

¡Soldering iron (26W) : 450ª for up to 5 seconds.

-VIN CASE
NC RC
+VIN

-VOUT -S TRM +S +VOUT

+VOUT, -VOUT

Less than 39.2N(4kgf)

Others

Less than 19.6N(2kgf)

CBS-12

December 27, 2022

www.cosel.co.jp/en/

CBS-series

Derating
¡Use the power modules with conduction cooling (e.g. heat dissipation from the aluminum base plate to the attached heat sink).Below shows the derating curves with respect to the aluminum base plate temperature. Note that operation within the hatched areas will cause a significant level of ripple and ripple noise. Contact us for more information on cooling methods.
¡It is necessary to note thermal fatigue life by power cycle. Please reduce the temperature fluctuation range as much as possible when the up and down of temperature are frequently generated.Contact for more information on cooling methods.

¿CBS50, CBS100, CBS200

100

2 1

1CBS200O12,15,24,28,48 2Others (Excluding CBS350/450) 50

Load factor[%]

0 (85)

-40 -20

100 110

Aluminum base plate temperature Tc [C]

Tc:Measuring point
Aluminum base plate

¿CBS350

100 (85.7) (83.3)
50

1CBS3502412,CBS3502448,CBS3504848 2Others (CBS350)

2 1

Load factor[%]

(15) 0 -40

(85)

-20

Aluminum base plate temperature Tc [C]

100 110

¿CBS400
100 (75)
50

CBS450

Load factor[%]

(15) 0
-40

(85)

-20

Aluminum base plate temperature Tc [C]

100 110

Instruction Manual
It is neccessary to read the “Instruction Manual” and “Before using our product” before you use our product.

Instruction Manual

https://www.cosel.co.jp/redirect/catalog/en/CBS/

Before using our product https://en.cosel.co.jp/technical/caution/index.html

CBS

NOTICE

www.cosel.co.jp/en/

December 27, 2022

CBS-13

CBS-series

Basic Characteristics Data

Model

Circuit method

CBS50 CBS100 CBS200 CBS350 CBS450

Forward converter Forward converter Forward converter Forward converter Forward converter

*1 Refer to Instruction Manual.

Switching frequency
[kHz]

Input current
[A]

Rated input fuse

310

–

370

–

Refer to

370

table No.1

–

370

–

370

–

Inrush current protection
–

PCB/Pattern

Material

Single sided

Series/Redundancy operation availability Double Series Redundancy sided operation operation

Aluminum Yes

Yes *1

Aluminum Yes

Yes *1

Aluminum Yes

Yes *1

Aluminum Yes

Yes *1

Aluminum Yes

Yes *1

Table1. The value of input current (at rated input voltage and rated load)

[A]

Output Voltage

Model

1.8V

2.5V

3.3V

12V

15V

24V

28V

32V

48V

CBS5024 1.2

1.6

2.0

2.5

2.4

–

CBS5048 0.6

0.8

1.0

1.3

1.2

–

CBS10024 2.5

3.2

4.1

5.0

4.8

–

CBS10048 1.2

1.6

2.0

2.5

2.4

–

CBS20024 3.8

4.8

6.1

7.6

9.6

9.7

–

CBS20048 1.9

2.4

3.0

3.8

4.8

–

4.8

CBS35024

–

CBS35048

–

8.4

–

8.2

8.1

8.2

CBS45048

–

10.6

10.5

9.3

–

CBS-14

December 27, 2022

www.cosel.co.jp/en/

Cosel Cbs-series Converters Bus Converter Power Module Type Owner's Manual

CBS-series Converters Bus Converter Power Module Type

Product Information

Product Usage Instructions

References

Documents / Resouces

Related Manuals
