PESMX2211003CE
Service Manual Version:2201 Ventilating Fan
(North AmericaMarket)

RG-T810A

WARNING
This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product. Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.

IMPORTANT SAFETY NOTICE
There are special components used in this equipment which are important for safety. These parts are marked by in the Schematic Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards. Do not modify the original design without permission of manufacture. We suggest to handle such parts after the static electricity prevention. It is forbidden to touch the PCB parts by bare hands during the repairing process.

CONTENTS

PAGE

1.Specifications————————————————————————————— 1

2.Parts Identification———————————————————————————- 2~4

3.Wiring Diagram————————————————————————————— 5

4.Parts List———————————————————————————————– 6, 7

1. Specifications
1

2. Parts Identification
Main Body Section

6
A

A
(2pcs)

10 12

RG-T810A

(2pcs)

A C
(3pcs) 8
D (4 pcs)
9
D (2 pcs)
11

E (3 pcs)
14
2

2. Parts Identification
Main PCB Section
15
17

RG-T810A

F
(2 pcs)

Main Labels

ATTENTION
Circuit board assembly inside, do not drill the can/housing.For details, please refer to installation instructions.
ATTENTION
Carte de circuit imprimé à l’intérieur, ne percez pas le boîtier. Pour plus de détails, consultez les instructions d’installation.

E78414
US LISTED
FAN

2. Parts Identification
Packing Section
22
23 26

RG-T810A
24 25
27

3. Wiring Diagram

RG-T810A

4. Parts List

Main Body Section No. Part No.
1 FFV5710025S 2 FFV1600159S 3 FFV0000166S 4 FFV0900052S 5 FFV3450010S 6 FFV0900072S 7 FFV2800020S 8 FFV10VS1M2 9 FFV510VS19 10 FFV510VS18 11 FFV0810RS2 12 FFV7020021S 13 FFV510VS10 14 FFV1315A810 A FFV7000108S B FFV7000227S C FFVXTT48GFJ D FFVXTT412GFJ E FFV7000202S

Part Name Suspension Bracket Frame Assy Adapter Assy Connector Plate Ground Wire ConnectorAssy(V) Junction Cover Motor Assy Motor Support Blade Main PCB Assy Nut Casing Grill Assembly Truss Tap Screw Earth Screw Assy Bind Tap Screw Bind Tap Screw Bind Tap Screw

Main PCB Section No. Part No. 15 FFVT810L199 16 FFV510VS1992 17 FFV510VS112
F FFVXTN268GFJ

Part Name Main PCB Box Main PCB Cover Motor Lead Wire Screw

RG-T810A

Q´ty 1 1 1 1 1 1 1 1 1 1 1 1 1 1 5 1 3 6 3

Remark

Q´ty 1 1 1 1

Remark

4. Parts List

RG-T810A

Main Labels No. Part No. 18 FFVT810A105 19 FFV6730110S 20 FFV0810011S 21 FFV2260003S

Part Name Name Plate Warning Label Caution Label 1 UL Mark

Q´ty 1 1 1 1
