VERSA-300-PLN LED Light
Product Information:
Product Name: LED VERSA-300-PLN
Variant: VERSA-300-PLN-BLK (Black Finish), VERSA-300-PLN-WHT
(Satin White Finish)
Specifications:
- Lumen Output: 15W – Warm White 3000K – 2080lm, Neutral White
4000K – 1420lm, White 5700K – 1470lm - Lumen Output: 18W – Neutral White 4000K – 1650lm, White 5700K –
1710lm - Lumen Output: 25W – Neutral White 4000K – 2200lm, White 5700K –
2320lm - Voltage: 240V
- Power Factor: 0.9
- IP Rating: IP65
- Lifespan: 50,000hrs
- IK Rating: IK08
- CRI: 80
- Dimmable: No
Product Usage Instructions:
- Take out the light and accessory pack from the box.
- Unscrew the front frame anticlockwise to separate the frame,
diffuser, and back. - Disconnect the connection plug and fix the base plate.
- Connect the wires to the block through the reliefs.
- Set the connectors well and insert the diffuser cover on the
back housing. Insert screws. - Match the cover with the plate. If using Type B cover, make
sure the center line is on the connecting line of two
knockouts. - For installation of concealed wiring, use the front cover (type
A) and knockouts. - For installation of opening wiring, use the front cover (type
B) and knockouts. - Note: The lamp must be installed by a professional
electrician. - Note: Ensure the power supply is switched off before fitting
this product. - Note: Do not touch the lamp when in use. Keep away from hot
steam and corrosive gas.
29-31 Richland St. Kingsgrove. Sydney NSW 2208 Australia Phone: 02 9554 9600 | Fax: 02 9554 9433
[email protected] | www.domuslighting.com
Installation Manual
VERSA-300-PLN
Date: 05/2018
Variant
Item No.
Description
19800
VERSA-300-PLN-BLK
15/18/25W Bunker Light, TRIO. Black Finish
19802
VERSA-300-PLN-WHT 15/18/25W Bunker Light, TRIO. Satin White Finish
Thank you for purchasing your new LED VERSA-300-PLN, Please take the time to read and understand the instruction sheet below. Failure to do so may void warranty.
Specifications
Lumen 15W
18W
25W
(±5%): Warm White 3000K – 1380lm Warm White 3000K – 1560lm
Warm White 3000K – 2080lm
Neutral White 4000K – 1420lm Neutral White 4000K – 1650lm
Neutral White 4000K – 2200lm
White 5700K – 1470lm
White 5700K – 1710lm
White 5700K – 2320lm
Voltage: 240V
Beam Angle: 110°
Operating Temp: -20°C~45°C
Power: 15W – 18W – 25W (Switchable) CCT:
3000K – 4000K – 5700K Power Factor: 0.9
(Switchable)
IP Rating: IP65
Lifespan: 50,000hrs
IK Rating:
IK08
CRI:
80
Dimmable: No
1.Take out light and accessory pack from box
2. Unscrew the front frame anticlockwise, to separate the frame, diffuser and back.
3. Disconnect the connection plug, fix the base plate
4. Connect the wires to the block through the reliefs
Ø4.5
5. Set the connectors well and insert the diffuser cover on the
6. Match the cover with plate (If the Type B cover, make sure the
7.
back housing. Insert screws.
center line is on the connecting line
of two knock out)
350mA 500mA 600mA
(Standard)
L N
L N
WW NW CW 350mA 500mA 600mA
Front Cover (type A)
Installation of concealed wiring.
Knock out
Knock out
Front Cover (type B)
Installation of opening wiring.
Note: -The lamp must be installed by professional electrician
-Ensure the power supply is switched off before fitting this product
-Do not touch the lamp when in use -Keep away from hot steam and corrosive gas
