WHISPER-6 LED Exterior Wall Light
Product Information
The LED WHISPER-6 is a wall light designed and manufactured by
Domus Lighting. It is available in different variants, each with a
unique item number and description:
- Variant: WHISPER-6-WHT-WW
- Item No: 19678
- Description: LED Wall light with a Satin White finish. It emits
a warm white light with a color temperature of 3000K.
- Variant: WHISPER-6-WHT-W
- Item No: 19679
- Description: LED Wall light with a Satin White finish. It emits
a white light with a color temperature of 5000K.
- Variant: WHISPER-6-BLK-WW
- Item No: 19680
- Description: LED Wall light with a Black finish. It emits a
warm white light with a color temperature of 3000K.
- Variant: WHISPER-6-BLK-W
- Item No: 19681
- Description: LED Wall light with a Black finish. It emits a
white light with a color temperature of 5000K.
Usage Instructions
Before installing or using the LED WHISPER-6, please carefully
read and understand the following instructions:
- The lamp must be installed by a professional electrician.
- Ensure that the power supply is switched off before fitting the
product. - Do not touch the lamp when it is in use.
- Keep the product away from hot steam and corrosive gas.
Note: Failure to comply with these instructions may void the
warranty of the product.
29-31 Richland St. Kingsgrove. Sydney NSW 2208 Australia Phone: 02 9554 9600 | Fax: 02 9554 9433
[email protected] | www.domuslighting.com
Installation Manual
WHISPER-6
Date:10/2018
Variant
Item No.
Description
19678
WHISPER-6-WHT-WW LED Wall light, Satin White finish. 3000K, warm white.
19679
WHISPER-6-WHT-W
LED Wall light, Satin White finish. 5000K, white.
19680
WHISPER-6-BLK-WW LED Wall light, Black finish. 3000K, warm white.
19681
WHISPER-6-BLK-W
LED Wall light, Black finish. 5000K, white.
Thank you for purchasing your new LED WHISPER-6, Please take the time to read and understand the instruction sheet below. Failure to do so may void warranty.
Specifications
Voltage: 240V AC
Power: IP Rating: CRI:
10.5W IP65 80
Lumen (±5%):
Beam Angle: CCT: Lifespan:
Warm White 3000K – 290lm White 5000K – 340lm 120° 3000K – 5000K 50,000hrs
Dimmable:
No
Operating Temp: -20°~45° Power Factor:
8mm
Note: -The lamp must be installed by professional electrician
-Ensure the power supply is switched off before fitting this product
-Do not touch the lamp when in use -Keep away from hot steam and corrosive gas
