Asus Vivobook Pro 16x Oled N7600pc-l2029t Portable Laptop Owner's Manual

VivoBook Pro 16X OLED N7600PC-L2029T Portable Laptop
Owner’s Manual

VivoBook Pro 16X OLED N7600PC-L2029T Portable Laptop

ASUS VivoBook Pro 16X OLED N7600PC-L2029T notebook i7-11370H 40.6 cm (16″) WQUXGA Intel® Core™ i7 16 GB DDR4SDRAM 1000 GB SSD NVIDIA GeForce RTX 3050 Wi-Fi 6 (802.11ax)
Windows 10 Home Grey
Brand : ASUS
Product family: VivoBook
Product code: N7600PCL2029T
Product name : N7600PCL2029T
– Windows 10 Home 64-bit
– Intel Core i7-11370H (12MB Cache)
– 40.6 cm (16″) WQUXGA 3840 x 2400 OLED, NVIDIA GeForce RTX 3050 (4GB GDDR6)
– 16GB LPDDR5-SDRAM (1 x 16) & 1000GB SSD Intel Core i7-11370H (12MB Cache), 16GB LPDDR5-SDRAM, 1000GB SSD, 40.6 cm (16″) WQUXGA 3840 x 2400 OLED, Intel Iris Xe Graphics, NVIDIA GeForce RTX 3050 (4GB GDDR6), WLAN, Webcam, Windows 10 Home 64-bit
ASUS VivoBook Pro 16X OLED N7600PC-L2029T. Product type: Notebook, Form factor: Clamshell. Processor family: Intel® CoreTM i7, Processor model: i7-11370H. Display diagonal: 40.6 cm (16″), HD type: WQUXGA, Display resolution: 3840 x 2400 pixels. Internal memory: 16 GB, Internal memory type: DDR4-SDRAM. Total storage capacity: 1000 GB, Storage media: SSD. On-board graphics card model: Intel Iris Xe Graphics, Discrete graphics card model: NVIDIA GeForce RTX 3050. Operating system installed: Windows 10 Home. Product colour: Grey

Design
Colour name	Comet Grey
Product type *	Notebook
Product colour *	Grey
Form factor *	Clamshell
Housing material	Aluminium
Market positioning	Home
Introduction year	2021
Display
Display diagonal *	40.6 cm (16″)
Display resolution *	3840 x 2400 pixels
Touchscreen *
HD type	WQUXGA
Panel type	OLED
Native aspect ratio	16:10
Display surface	Gloss
RGB colour space	DCI-P3
Colour gamut	100%
High Dynamic Range (HDR)
Processor
Processor manufacturer *	Intel
Processor generation	11th gen Intel® Core™ i7
Processor model *	i7-11370H
Processor family *	Intel® Core™ i7
Processor boost frequency	4.8 GHz
Processor cores	4
Processor cache	12 MB
Configurable TDP-up frequency	3.3 GHz
Camera
Privacy type	Privacy shutter
Network
Top Wi-Fi standard *	Wi-Fi 6 (802.11ax)
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Mobile network connection *
Antenna type	2×2
Ethernet LAN
Bluetooth
Bluetooth version	5.2
Ports & interfaces
USB 2.0 ports quantity *	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity *	1
HDMI ports quantity *	1
HDMI version	1.4
Thunderbolt 4 ports quantity	1
Intel® Thunderbolt 4
Combo headphone/mic port
Charging port type	DC-in jack
Power adapter barrel connector	4.5 mm
USB Type-C DisplayPort Alternate Mode
USB Power Delivery
Keyboard
Pointing device	Touchpad
Numeric keypad *
Keyboard backlit
Processor
Configurable TDP-up	35 W
Configurable TDP-down	28 W
Configurable TDP-down frequency Memory	3 GHz
Memory
Internal memory *	16 GB
Internal memory type	DDR4-SDRAM
Memory form factor	On-board
Memory layout (slots x size)	1 x 16 GB
Maximum internal memory *	16 GB
Storage
Total storage capacity *	1000 GB
Storage media *	SSD
Total SSDs capacity	1000 GB
Number of SSDs installed
SSD capacity	1000 GB
SSD interface	NVMe, PCI Express 4.0
NVMe
SSD form factor	M.2
Optical drive type *
Card reader integrated
Compatible memory cards	MicroSD (TransFlash)
Graphics
Discrete GPU manufacturer	NVIDIA
Discrete graphics card model *	NVIDIA GeForce RTX 3050
On-board graphics card *
Discrete graphics card *
On-board graphics card model *	Intel Iris Xe Graphics
Discrete graphics card memory	4 GB
Discrete graphics memory type	GDDR6
Audio
Speakers manufacturer	Harman Kardon
Built-in microphone
Camera
Front camera
Front camera HD type	HD
Privacy camera
Software
Operating system architecture	64-bit
Operating system installed *	Windows 10 Home
Processor special features
Intel Trusted Execution Technology
Intel VT-x with Extended Page Tables (EPT)
Intel Stable Image Platform Program (SIPP)
Intel Software Guard Extensions (Intel SGX)
Idle States
CPU configuration (max)	1
Intel Virtualization Technology for Directed I/O (VT-d)
Intel Virtualization Technology (VTx)
Battery
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	6
Battery capacity *	96 Wh
Power
AC adapter power	120 W
AC adapter frequency	50 – 60 Hz
AC adapter input voltage	100 – 240 V
AC adapter output current	6:00 AM
AC adapter output voltage	20 V
Security
Fingerprint reader
Trusted Platform Module (TPM)
Weight & dimensions
Width	360.5 mm
Depth	259 mm
Height	18.9 mm
Weight *	1.95 kg
Logistics data
Harmonized System (HS) code	84713000
