WTH-28EF12A2 Electric Fireplace
Product Information
Product Name: Electric Fireplace
Model No.: WTH-28EF12A2
Implementation Standards: Fixed And Location-Dedicated
Electric Room Heaters [UL 2021] [CSA C22.2#46]
Country of Origin: Made in China
Consumer Safety Information
Please read this manual carefully before installing and
operating the electric fireplace. Failure to follow these
instructions may result in electric shock, fire, property damage,
or personal injury. Do not store or use gasoline or other flammable
liquids in the vicinity of this appliance.
Important Safety Information
WARNING: Read all instructions before using this heater!
This heater gets hot when in use. To avoid burns, DO NOT let bare
skin touch hot surfaces.
WARNING: Connect to properly grounded outlets ONLY. DO
NOT insert or allow foreign objects to enter any ventilation or
exhaust openings, as this may cause electric shock or fire, or
damage the heater. To prevent a possible fire, DO NOT block air
intakes or exhaust in any manner. DO NOT use on soft surfaces, like
a bed, where openings may become blocked.
A heater has hot and arcing or sparking parts inside. DO NOT use
it in areas where gasoline, paint, or flammable liquids are used or
stored. Use this heater only as described in this manual. Any other
use not recommended by the manufacturer may cause fire, electric
shock, or injury to persons.
ALWAYS plug heaters directly into a wall
outlet/receptacle. Never use with an extension cord or
relocatable power tap (outlet/power strip).
DO NOT place the heater near a bed because objects such
as pillows or blankets can fall off the bed and be ignited by the
heater.
NEVER use this heater in bathrooms, laundry rooms, or any
other location where the heater could fall into a bathtub or pool,
become damp or come in contact with water.
AVOID FIRE! Regularly inspect all air vents to make sure
they are free from dust, lint, or other blockage. Unplug the unit
and clean with a vacuum ONLY. DO NOT rinse or get wet.
ALWAYS mount to wall bracket before use. DO NOT set on
the floor or other surface to use.
NEVER use a wall mount bracket from another
manufacturer.
This product is not intended to be a primary heat source. It is
for supplemental heat only. INDOOR use only! NEVER use this
heater outdoors, as doing so may result in electric shock.
Risk of electric shock! DO NOT OPEN! No user-serviceable
parts inside!
ALWAYS turn this heater off before unplugging it from the
outlet.
ALWAYS disconnect this unit from the power supply before
performing any assembly or cleaning, or before relocating the
electric fireplace.
NEVER leave this heater unattended. ALWAYS unplug this
heater when not in use.
ALWAYS store this heater in a dry location. NEVER use the
fireplace if it has become wet.
NEVER plug this heater into an outlet that is old, cracked,
or has any loose wires or connections. Plugging this heater
into a faulty outlet could result in electric arcing within the
outlet that could cause the outlet to overheat or catch fire.
ALWAYS check your heater cord and plug connections with each
use!
Product Usage Instructions
1. Carefully read and understand the entire user manual before
installing and operating the electric fireplace.
2. Ensure that the electric fireplace is plugged into a properly
grounded outlet. DO NOT use an extension cord or power strip.
3. Place the electric fireplace on a stable surface or mount it
to a wall bracket according to the manufacturer’s instructions.
4. Keep the electric fireplace away from flammable materials and
ensure that there is no blockage of air intakes or exhaust
vents.
5. Never touch the hot surfaces of the electric fireplace with
bare skin to avoid burns.
6. Avoid using the electric fireplace on soft surfaces like
beds, where openings may become blocked.
7. Do not use the electric fireplace in areas where gasoline,
paint, or flammable liquids are used or stored.
8. Regularly inspect and clean the air vents of the electric
fireplace using a vacuum. DO NOT rinse or get the unit wet.
9. Always turn off and unplug the electric fireplace before
performing any assembly, cleaning, or relocating.
10. Store the electric fireplace in a dry location when not in
use and ensure it is not plugged into a faulty outlet.
11. NEVER leave the electric fireplace unattended while it is in
operation.
12. Only use the electric fireplace indoors and NEVER use it
outdoors.
13. If any issues or concerns arise with the electric fireplace,
refer to the user manual or contact the manufacturer for
assistance.
ELECTRIC FIREPLACE
Model No.: WTH-28EF12A2
Implementation Standards:
Fixed And Location-Dedicated Electric Room Heaters [UL 2021] [CSA C22.2#46]
Made in China
CONTENTS
1.Make people pay attention ———————————— 01 2. Parts and hardware ———————————————- 03 3. Product size —————————————————— 03 4. Installation and Assembly ————————————– 04 5. Control Description ———————————————- 06 6. Remote Control Description ———————————– 09 7. WIFI link control ————————————————– 13 8. Care and maintenance ——————————————- 16 9. Electrical schematics ——————————————- 18 10. Customer Support ————————————————- 19
CONSUMER SAFETY INFORMATION
Read this manualbefore installing and operating this appliance. Failure to follow these instructions may result in electric shock,fire property, or personal injury. Do not store or use gasoline or other flammable liquids in the vicinity of this appliance.
1
IMPORTANT SAFETY INFORMATION!
WARNING
Read all instructions before using this heater! This heater is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces. If provided,
use handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the front of the heater, and keep them away from the sides and rear. Extreme caution is necessary when any heater is used by or near children or invalids and whenever the heater is left operating and unattended. DO NOT operate any heater with a damaged cord or plug or after the heater malfunctions, has been dropped or damaged in any manner, Discard heater, or return to authorized service facility for examination and /or repair. DO NOT run power cord under carpeting. DO NOT cover power cord with throw rugs, runners, or similar coverings. DO NOT route power cord under furniture or appliances. Arrange power cord away from traffic area, and where it will not be tripped over.
WARNING
Connect to properly grounded outlets ONLY. DO NOT insert or allow foreign objects to enter any ventilation or exhaust openings, as this may
cause electric shock or fire, or damage the heater. To prevent a possible fire, DO NOT block air intakes or exhaust in any manner. Doing so could
cause a fire. DO NOT use on soft surfaces, like a bed, where openings may become blocked. A heater has hot and arcing or sparking parts inside. DO NOT use it in areas where gasoline,
paint, or flammable liquids are used or stored. Use this heater only as described in this manual. Any other use not recommended by the
manufacturer may cause fire, electric shock, or injury to persons. ALWAYS plug heaters directly into a wall outlet/receptacle. Never use with an extension
cord or relocatable power tap (outlet/power strip). DO NOT place the heater near a bed because objects such as pillows or blankets can fall off the bed
and be ignited by the heater. NEVER use this heater in bathrooms, laundry rooms, or any other location where the heater
could fall into a bathtub or pool, become damp or come in contact with water. AVOID FIRE! Regularly inspect all air vents to make sure they are free from dust, lint, or other
Blockage.Unplug the unit and clean with a vacuum ONLY. DO NOT rinse or get wet. ALWAYS mount to wall bracket before use. DO NOT set on the floor, or other surface, to use.
1
NEVER use a wall mount bracket from another manufacturer. This product is not intended to be a primary heat source. It is for supplemental heat only. INDOOR use only! NEVER use this heater outdoors! Doing so may result in electric shock! Risk of electric shock! DO NOT OPEN! No user-serviceable parts inside! ALWAYS turn this heater off before unplugging it from the outlet. ALWAYS disconnect this unit from the power supply before performing any assembly or cleaning,
or before relocating the electric fireplace. NEVER leave this heater unattended. ALWAYS unplug this heater when not in use. ALWAYS store this heater in a dry location.NEVER use the fireplace if it has become wet. NEVER plug this heater into an outlet that is old, cracked, or has any loose wires or
connections. Plugging this heater into a faulty outlet could result in electric arcing within the outlet that could cause the outlet to overheat or catch fire. ALWAYS check your heater cord and plug connections with each use!
i) MAKE SURE the plug fits tight in the outlet! Faulty wall outlet connections or loose plugs can cause the outlet to overheat.
ii) Heaters draw more current than small appliances. Overheating may occur even if it has not occurred with the use of other appliances.
iii) During use check frequently to see if the plug outlet or face plate is HOT! iv) If the outlet or face plate is HOT, discontinue use immediately and have a qualified electrician
inspect and/or replace the faulty outlets.
The power cord supplied with the heater has a plug with two flat blades (live and neutral) and one round pin (ground). If a 3slot receptacle is not available, an adapter MUST be used. The adapter MUST be properly grounded to the outlet box (see figure at right).(Note:Adapter NOT INCLUDED.)
SAVE THESE INSTRUCTIONS!
PREPARATION
This product includes a GLASS panel! Always use extreme caution when handing glass. Failure to do so could result in personal injury or property damage.
Remove all parts and hardware from the carton and place them on a clean, soft, dry surface. Parts and assembly steps are grounded for wall-hanging or recessing use. Check the parts list to make sure nothing is missing. Dispose of packaging materials properly. Please recycle whenever possible. You will need the following tools (not included): Phillips screwdriver; stud finder; level; tape measure; electric drill; battery;1/4″ wood drill bit, hammer.
2
PARTS & HARDWARE
B. 4x2mm Screws (2pcs)l
A. Fireplace
Specification and Dimension
C.Remote Control
D. Instructions
WARNING
WHEN USING PAINT OR LACQUER TO FINISH THE MANTEL, THE PAINT OR LACQUER MUST BE HEAT
RESISTANT TO PREVENT DISCOLOURATION
Your appliance is a wall-mounted, recessed and /or mantel installed appliance. Select a suitable location that is not susceptible to moisture and is away from drapes, furniture and high traffic areas. NOTE: Follow all national and local electrical codes.
MINIMUM CLEARANCE TO COMBUSTIBLES
Bottom Sides Back
Measurements are taken from the glass front.
0″
Top
0″
Top
0″
11.8″ (300mm) to mantel 11.8″ (300mm) to ceiling
3
Installation and Assembly
RECESSED TO WALL INSTALLATION ( Tips:Wall bracket removing is NOT required. )
STEP 1 Select a dry wall to open a hole for fireplace box. Figure (A)
Figure (A) Hole cut size
Model Number WTH-28EF12A2
Framing Hole Size
W
H
27 3/8″ 695mm
22 7/16″ 570mm
D
7 1/2″ 190.5mm
STEP 2 Lift out the decorative kit upwards, Move the fireplace box to the wall hole or fireplace mantel. Figure(B)
Figure (B)
4
STEP 3 Use the 4 screws(provided) to lock the appliance into wall or fireplace mantel Figure(C)
STEP 4 Fix the trim kit Figure(D)
Figure(C)
Figure(D)
5
Control Description
WARNING
Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure do to so could result in electric shock, fire, serious injury, or death.
POWER
Make sure the ON/OFF switch, located on the control panel, is in the OFF position.Plug the power cord into a 120-230V Volt 7 Amp grounded outlet (see IMPORTANT SAFETY INFORMATION on Pages 2 and 3).Make sure the outlet is in good condition and that the plug is not loose.NEVER exceed the maximum amperage for the circuit. DO NOT plug other appliances into the same circuit.
METHODS OF OPERATION
This electric fireplace can be operated by the button, located on the TOP right side glass panel of the fireplace, or by the battery-powered REMOTE CONTROL.
The operation and functions of the two methods are the same.
Before operating, please review the IMPORTANT SAFETY INFORMATION on Pages 2 and 3, and heed all warnings.
Power standby switch
WIFI Display area FLAME EMBER color / brightness
TIMER HEATER
switch button
6
Turn on switch button first
BUTTON POWER HEATER TIMER EMBER
FLAME
FUNCTION
ON: Enables control panel functions and remote control.Turn on flame effect. OFF: Disables control panel functions and remote control. Turn off flame effect. HEATER button:Turn heater on and off. NOTE: To prevent overheating, the heater fan will blow out cool air for 30 seconds after the heater turn off. TEMPERATURE button: Control temperature settings to choose temperature as desired. Setting range from 62F to 82F. TIMER button: Control timer settings to turn off fireplace at selected time. Settings range from 0 hours,1hours, to 24 hours.
EMBER button: Makes the ember bed color effect changing. Makes the ember bed effect dimmer and brighter.
FLAME button: Makes the flame color effect changing. Makes the flame effect dimmer and brighter.
ACTION&INDICATION
1. Press once. Indicator light turns on. Power turns on. All functions enabled. 2. Press again. Indicator light turns off. Power turns on. All functions will off. 1. Press once. Indicator lights up(LOF). 750W heater turns on and blows warm air. 2. Press again. Indicator lights up(HIF). 1500W heaters turns on and blows hot air. 3. Press again. Smart 72F 4. Press again.Heaters turn off . The display show ” OFF ” 5. Keep pressing 3 seconds to setting temperature 62F to 82F. 1. Press once. Indicator light turn on. Temperature is set to hours. 2. Press again until desired setting is reached(0-8H). LED display show setting. 3. Keep pressing 3 seconds to setting 0-24 hours.
1. Press once. Ember bed color effect gets changing.(12 color) 2. Press again until desired setting is reached. When set the color to C0, the ember bed color will automatic changing Keep pressing 3 seconds to make the ember bed effect dimmer and brighter(L5-L1).
3. Press once. flame color effect gets changing. (12 color) 4. Press again until desired setting is reached. When set the color to F0, the flame color will automatic changing Keep pressing 3 seconds to make the flame effect dimmer and brighter(L5-L1).
UP DOWN
UP button: Flame&ember bed color/dimmer and brighter/Timer/Flame speed/ Temperature DOWN button: Flame&ember bed color/dimmer and brighter/Timer/Flame speed/ Temperature
Flame&ember bed color/dimmer and brighter/ Timer/Flame speed/ Temperature Flame&ember bed color/dimmer and brighter/ Timer/Flame speed/ Temperature
SPEED
FLAME SPPED button: Setting the flame speed (S5-S1)
Setting the flame speed (S5-S1)
7
Turn on switch button first
Power standby switch
Flame color e. ect 3S Long press for 3 s. Click the button, the
flame brightness e ect
ember bed color e. ect 3S Long press for 3 s. Click the button
,ember bed brightness e ect
Timer to turn o the fireplace
Heater 750W /1500W/ 72f/OFF
Long press for 3S to enter automatic forward time mode. Long press to stop scrolling. Setting completed. 3S
Long press for 3S to enter automatic forward temperature mode. Long press to stop scrolling. Setting completed. 3S
8
Remote Control Description
indicator light Power standby switch
TIMER FLAME
Remote
UP EMBER DOWN
TIMER
HEATER Battery
MODE 1 Remote control 1. Illustration of button mode
1. Open the battery compartment cover and install the 2 x AAA batterys. 2. Test whether the battery is installed properly and press any key to observe whether the indicator light is on.
MODE 2 Remote control 2.Remote control function selection mode, up and down selection
9
NOTICE
To improve operation, aim the remote control at the front of the fireplace. DO NOT press the buttons too quickly.Give the unit time to respond to each command.
Excluding batteries, Prepare yourselfWith 2x AAA batteries.
AAA AAA
2xAAA
+
AAA
AAA
–
+ –
1. Open the battery compartment cover and install the 2 x AAA batterys.
Remote control to adjust brightness
3S Long press for 3 s. Click the button, the flame brightness e ect
3S
Long press for 3 s. Click the button ,ember bed brightness e ect
2. Test whether the battery is installed properly and press any key to observe whether the indicator light is on
10
Remote control 1. Illustration of button mode
Flame color e ect
Press any key to remotely activate the control board. Once the control board lights up, control operations can be carried out.
ember bed color e ect Setting the flame speed Timer to turn o the fireplace
UP DOWN Select a temperature
Heater 750W /1500W/ 72 F/OFF
11
