Hammond M795 M Series Cord Wraps Instructions (+ PDF)

M795 M Series Cord Wraps
Instructions

Contents hide

1 Cord Wraps

2 Printed Circuit Board Standoffs

3 Replacement Screw List

4 Battery Holders

5 Documents / Resources

6 Related Posts

Cord Wraps

Part Number M795
• 4.8” (122mm) overall length
• grey plastic cord wrap
• two mounting posts on 1.5625” centers
• simple installation: secured by two clips each (included)
• sold in pairs

1421

Printed Circuit Board Standoffs

	Part Number 1421PCB1-8 • 0.65” (17mm) overall height • 0.71” (18mm) square mounting pad with self adhesive • P.C. board bottom would rest 0.25” (6mm) above the enclosure floor • Suggested material thickness 0.0625” (1.6mm) max. • Suggested hole diameter 0.156” (4mm) • Tough white nylon • Sold in packs of 8
	Part Number 1421PCB2-8 • 0.9” (23mm) overall height • 0.71” (18mm) square mounting pad with self adhesive • P.C. board bottom would rest 0.5” (12.7mm) above the enclosure floor • Suggested material thickness 0.0625” (1.6mm) max. • Suggested hole diameter 0.156” (4mm) • Tough white nylon • Sold in packs of 8

Hardware

Replacement Screw List

Photo	Part Number	Qty	Description	System	Technical Description
	1421F4	Set of 24 items	4 sets of: pan head machine screws, locknuts, #10 Tenormin nuts, Tektite screws, flat washers & hex nuts for mounting fans or fan grills.	U.S. (UTS)	8-32 x 2″ Phillips 10-32 x 5/8 Taptite Phillips
	1421J6	6	Self tapping for most metal case series	U.S. (UTS)	6-32 Phillips
	1455MS100	100	Self tapping type for the 1455 series panels	U.S. (UTS)	#6 x 3/8″ Phillips
	1455MS100BK	100	Black Self tapping type for the 1455 series panels	U.S. (UTS)	#6 x 3/8″ Phillips
	1457MS100	100	Black Self tapping type for the 1457 series panels with “O” ring installed	U.S. (UTS)	6-32 x 1/2″ TT, Phillips
	1551ATS100	100	Self tapping type for 1551 series	U.S. (UTS)	#2 x 3/16″ Phillips
	1590MS100	100	Machine type for assembly – 1590 (except L-R) series	U.S. (UTS)	6-32 x ½” Phillips
	1590MS50BK	50	Black machine type for assembly – 1590 series	U.S. (UTS)	6-32 x ½” Phillips
	1590MS50BU	50	Blue machine type for assembly – 1590 series	U.S. (UTS)	6-32 x ½” Phillips
	1590MS50GY	50	Grey machine type for assembly – 1590 series	U.S. (UTS)	6-32 x ½” Phillips
	1590WMS100BK	100	Black machine type for assembly – 1590W series with “O” ring installed	U.S. (UTS)	6-32 x ½” Phillips
	1591MS100	100	Machine type for assembly – 1591 & 1598 series	Metric	M3 – 0.5 x 10mm Phillips
	1591MS100BK	100	Machine type for assembly – 1591 & 1598 series (Black)	Metric	M3 – 0.5 x 10mm Phillips
	1591TS100	100	Self tapping type for assembly – 1591 “S” series and 1551 series	U.S. (UTS)	#4 x 0.5″ Phillips
	1591TS100BK	100	Black self tapping type for assembly – 1591 “S” series and 1551 series	U.S. (UTS)	#4 x 0.5″ Phillips
	1593ATS50 1593ATS100	50 100	Pan head, self tapping type for 1553T, 1591XX, 1593 and 1599 series enclosure internal standoffs	U.S. (UTS)	#4 x 1/4″ Phillips
	1593MS100	100	Self tapping, oval head for assembly – 1593 series	U.S. (UTS)	#4 x 0.625″ Phillips
	1594MS100	100	Machine type for assembly – 1594, 1599B, and 1592 series	Metric	M3 – 0.5 x 18mm Phillips
	1594TS100	100	Self tapping for assembly – 1594 & 1599ES “S” series	U.S. (UTS)	#4 x 1″ Phillips
	1594WMS100	100 Sets	Machine type for assembly – 1594 watertight series & 1599E. With 100 “O” rings	Metric	M3 – 0.5 x 25mm Phillips
	1595MS100	100	Machine type for assembly – 1595 series	Metric	M3 – 0.5 x 8mm Phillips
	1598ATS100	100	Pan head, self tapping type for 1555, and 1598 series enclosure internal standoffs	U.S. (UTS)	#6 x 1/4″ Phillips
	1598TS100	100	Self tapping for assembly – 1598 “S” series	U.S. (UTS)	#4 x 5/8″ Phillips
	1599BTS100	100	Self tapping for assembly – 1599BS “S” series	U.S. (UTS)	#4 x ¾” Phillips
	1599HMS100	100	Machine type for assembly – 1599H series	Metric	M3 – 0.5 x 12mm Phillips
	1599HTS100	100	Self tapping for assembly – 1599HS “S” series	U.S. (UTS)	#4 x 1″ Phillips
	SC503-100	100	Replacement 1553T cover screws	Metric	(M3-0.5 x 18mm Flat Head)
	SC503BK-100	100	Replacement 1553T cover screws	Metric	(M3-0.5 x 18mm Flat Head)

Battery Holders

Photo (not to scale)	Part Number	Qty Per Package	Compatible Bateries (not incl.)
	BH1AAW	1	(1) AA
	BH1AAAW	1	(1) AAA
	BH2AAW	1	(2) AA
	BH2AAAW	1	(2) AAA
	BH3AAW	1	(3) AA
	BH3AAAW	1	(3) AAA
	BH4AAW	1	(4) AA
	BH4AAAW	1	(4) AAA
	BS61	1	(1) 9V
