P1348 Analog Clock

ANALOG CLOCK INSTALLATION & MAINTENANCE MANUAL

P1348

ED-16102 Rev 03

29 April 2022

201 Daktronics Drive Brookings, SD 57006-5128 www.daktronics.com/support
800.325.8766

Introduction
- Important Safety Instructions
- Resources
Mechanical Installation
- Mounting
- Removal & Replacement
- Small Clocks
- Large Clocks
Electrical Installation
- Warnings and Disclaimers
- Clock Control Installation
Replacement Parts
- Replacement Fuses
- Routine/Preventative Maintenance
A Reference Drawings

1 Introduction

This manual explains the installation and maintenance of
Daktronics Analog Clocks. This manual is not specific to a
particular installation. Project-specific information takes
precedence over general information found in this manual.

Important Safety Instructions

Resources

Figure 1 illustrates a Daktronics drawing label. This manual
refers to drawings by listing the last set of digits. In the
example, the drawing would be referred to as DWG-1007804. All
references to drawing numbers, appendices, figures, or other
manuals are presented in bold typeface. Any drawings referenced in
a section are listed at the beginning of it as shown below:

Drawing Number

Drawing Label

Reference Drawing: System Riser Diagram
DWG-1007804

Daktronics identifies manuals by the DD or ED number located on
the cover page.

Ensure all applicable materials have been gathered before
beginning the installation. Contact a Daktronics sales coordinator
or project manager.

2 Mechanical Installation

Mounting

Reference Drawings: Attachment- DA-1100-4 to
DA-1004-XX DWG-272683

Each analog clock will be mounted differently depending on the
diameter of the clock face and the surface to which it will be
attached. DWG-272683 in Appendix A shows the typical location and
hardware required when mounting an analog clock to a standard
Daktronics arch truss. For all other types of mountings, refer to
contract-specific shop drawings or system riser diagrams.

Removal & Replacement

Instructions for removal and replacement of the analog clock
will depend on the specific installation and should be outlined in
the project-specific information.

Small Clocks

Instructions for installation of small clocks will depend on the
specific installation and should be outlined in the
project-specific information.

Large Clocks

Instructions for installation of large clocks will depend on the
specific installation and should be outlined in the
project-specific information.

3 Electrical Installation

Warnings and Disclaimers

Before beginning electrical installation, ensure all power to
the area is turned off and the area is safe to work in. Failure to
follow proper safety procedures can result in injury or death.
Daktronics is not responsible for any damages or injuries resulting
from improper installation or use of their products.

Clock Control Installation

Instructions for clock control installation will depend on the
specific installation and should be outlined in the
project-specific information.

4 Replacement Parts

Replacement Fuses

If a fuse needs to be replaced, refer to the project-specific
information for the correct replacement fuse and instructions for
replacement.

Routine/Preventative Maintenance

Perform routine maintenance as outlined in the project-specific
information to ensure proper functioning of the analog clock.

A Reference Drawings

Refer to the reference drawings listed throughout this manual
for detailed installation and maintenance information.

View Fullscreen

ANALOG CLOCK INSTALLATION & MAINTENANCE MANUAL
P1348
ED-16102 Rev 03
29 April 2022
201 Daktronics Drive Brookings, SD 57006-5128 www.daktronics.com/support 800.325.8766

Copyright © 2006-2022
All rights reserved. While every precaution has been taken in the preparation of this manual, the publisher assumes no responsibility for errors or omissions. No part of this book covered by the copyrights hereon may be reproduced or copied in any form or by any means–graphic, electronic, or mechanical, including photocopying, taping, or information storage and retrieval systems–without written permission of the publisher. Daktronics trademarks are property of Daktronics, Inc. All other trademarks are property of their respective companies.

Table of Contents
1 Introduction 1 Important Safety Instructions…………………………………………………………………………………………………1 Resources …………………………………………………………………………………………………………………………….1
2 Mechanical Installation 2 Mounting ……………………………………………………………………………………………………………………………..2 Removal & Replacement……………………………………………………………………………………………………..2 Small Clocks 2 Large Clocks 3
3 Electrical Installation 4 Warnings and Disclaimers……………………………………………………………………………………………………..4 Clock Control Installation ……………………………………………………………………………………………………..4
4 Replacement Parts 5 Replacement Fuses ………………………………………………………………………………………………………………5 Routine/Preventative Maintenance ……………………………………………………………………………………..5
A Reference Drawings 7
i

This page intentionally left blank.

1 Introduction

This manual explains the installation and maintenance of Daktronics Analog Clocks. This manual is not specific to a particular installation. Project-specific information takes precedence over general information found in this manual.

Important Safety Instructions

· Read and understand all instructions before beginning the installation process.
· Disconnect power when not in use or when servicing.
· Do not modify the structure or attach any panels or coverings to the clock without the express written consent of Daktronics.
· Do not disassemble control equipment or electronic controls of the clock; failure to follow this safeguard will make the warranty null and void.

Resources

Figure 1 illustrates a Daktronics drawing label. This manual refers to drawings by listing the last set of digits. In the example, the drawing would be referred to as DWG-1007804. All references to drawing numbers, appendices, figures, or other manuals are presented in bold typeface. Any drawings referenced in a section are listed at the beginning of it as shown below:

Drawing Number
Figure 1: Drawing Label

Reference Drawing: System Riser Diagram …………………………………………………………………………… DWG-1007804

Daktronics identifies manuals by the DD or ED number located on the cover page.

Ensure all applicable materials have been gathered before beginning the installation. Contact a Daktronics sales coordinator or project manager.

Introduction 1

2 Mechanical Installation
Mounting
Reference Drawings: Attachment- DA-1100-4 to DA-1004-XX ………………………………………………….. DWG-272683
Each analog clock will be mounted differently depending on the diameter of the clock face and the surface to which it will be attached. DWG-272683 in Appendix A shows the typical location and hardware required when mounting an analog clock to a standard Daktronics arch truss. For all other types of mountings, refer to contract-specific shop drawings or system riser diagrams.
Note: For installation procedures of the truss itself, refer to the Outdoor Decorative Accent Installation Manual (ED-16076), available online at www.daktronics.com/ manuals.
Removal & Replacement
Small Clocks
Refer to Figure 2 and the instructions below for removal of clocks that are 4′ (1.2 m) and smaller in diameter:

Clock Face
Clock Mechanism

Clock Mechanism
Bracket
Screw @4

Clock Mechanism
Cover

Figure 2: Rear View, Small Analog Clock 1 Disconnect power to the clock. 2 Remove both clock hands from the front of the clock. 3 Remove rear cover from the back of the clock. 4 Remove the four screws from within the clock mechanism to free the clock from the
bracket.
Mechanical Installation 2

Large Clocks
Refer to Figure 3 and the instructions below for removal of clocks that are 5′ (1.5 m) and larger in diameter:
Clock Face (with Splice Plates @2)

Clock Mechanism
Bracket

Screw @4

Clock Mechanism (with Attached Mounting Plate)

Figure 3: Rear View, Large Analog Clock
1 Disconnect power to the clock. 2 Remove both clock hands from the front of the clock. 3 Remove the four screws securing the Clock Mechanism (with Attached Mounting
Plate) to the Clock Mechanism Bracket. 4 Unbolt the Mounting Plate from the Clock Mechanism, and keep it for the
replacement clock.
Note: Do not use straps provided by Electric Time; reuse the Daktronics mounting plate when replacing the clock mechanism.

Mechanical Installation 3

3 Electrical Installation
CAUTION: Only qualified individuals should perform power routing and termination.
Warnings and Disclaimers
· Ensure that all electrical work meets or exceeds all local or national electrical codes. · Provide the required power to the display as listed on the product labels,
specifications, or site-specific riser drawings. The conductor size may vary based on the length of the power run. · Consider implementing a separate circuit for the display using an isolation transformer or dedicated transformer. · Daktronics assumes no liability for any issues caused by line voltage fluctuations or other improper power conditions.
Clock Control Installation
Reference Drawings: System Riser: Clock Assy…………………………………………………………………………. DWG-263976
The clock control system consists of two parts: a controller and a motor mechanism. The controller is used to set the current time and send power to the motor mechanism, which in turn rotates the clock hands. DWG-263976 in Appendix A illustrates a typical wiring diagram for 115 and 230 VAC installations. For additional clock installation and setup information, refer to the 99B-MI User’s Manual, located online at www.electrictime.com/ services/support. 1 After the motor mechanism is mounted to the rear of the clock face, install the clock
hands to the front of the clock face with both hands pointing up at the 12:00 position. 2 Determine the controller location and mount per manufacturer’s instructions.
Note: The controller and motor may be located no more than 100′ (30.5 m) away from each other.
3 Connect power in conduit to the controller. 4 Connect power in conduit from the controller to the motor mechanism. 5 Set the clock to the correct time per manufacturer’s instructions.
Electrical Installation 4

4 Replacement Parts

Refer to the following table for standard and optional replacement parts.

Description
Clock Movement, 36″ (B28G7-MI) Clock Movement, 48″ (B28G7-MI) Clock Movement, 60″ (B28G7-MI) Clock Movement, 72″ (B28G7-MI) Electric Time Analog Clock Controller (99B-MI)

Part Number
A-2034 A-2035 A-2036 A-2037 A-2038

Clock Model #
DA-1101-3 DA-1100-4, DA-1102-4 DA-1100-5, DA-1101-5 DA-1100-6, DA-1102-6 All

Replacement Fuses

Primary fuse: · Daktronics: P/N FUSE-99BMI-2.5-250-F · Digikey: P/N WK4713-ND FUSE 2.5/250V SLO 5X20 UL/CSA · WICKMAN: 1971250000 Secondary fuse: · Daktronics: P/N FUSE-99BMI-1.0-250-F · Digikey: P/N WK4709-ND FUSE 1.00 250V FAST 5X20 UL · WICKMAN: 1911100000
Routine/Preventative Maintenance

Perform an annual visual inspection of each clock and check the following: · Check and tighten fasteners or replace them as required. · Check the electrical components for proper connection and any signs of corrosion.

Replacement Parts 5

This page intentionally left blank.

A Reference Drawings
Refer to Resources (p1) for information regarding how to read the drawing number. Any contract-specific drawings take precedence over the general drawings. Reference Drawings:
System Riser; Clock Assy…………………………………………………………………………. DWG-263976 Assy: DA-1100-4……………………………………………………………………………………… DWG-272682 Attachment- DA-1100-4 to DA-1004-XX ………………………………………………….. DWG-272683
Reference Drawings 7

This page intentionally left blank.
