Kopis X8 Cinelifter 5 (Ducted Version) Assembly Guide
Part List
- #510204 Upper Plate
- #510205 Lower Plate With 9 Pressure riveting nut
- #510213 Arm 4pcs
- #510210 Bottom Support Plate
- #510207 Bottom Plate
- #510214 Reinforcement Arm 4pcs
- #510206 Top Reinforcement Plate 4pcs
- #510215 Motor Holder 8pcs
- #510208 Bottom Reinforcement Plate 4pcs
- #510155 Camera Mounting Plate
- #510212 Side Support Plate R
- #510211 Side Support Plate L
- #510209 Top Plate
- #31117 TPU 3D print set 17pcs
- FPV Camera Mount
- GPS Holder
- Antenna Holder
- SMA Antenna Mount L
- SMA Antenna Mount R
- Positioning Sleeve 8pcs
- Landing Gear 4pcs
- Gummie M8 9pcs
- Gummie M3 8pcs
- Nylon Standoff M3*5 4pcs
- Screw M3*10 10pcs
- Screw M3*8 50pcs
- Screw M3*16 4pcs
- Hand Screw M3*8 2pcs
- Locknut M2 4pcs
- Screw M3*35 4pcs
- Locknut M3 17pcs
- Flat Head Screw M3*8 4pcs
- Socket Cap Screw M3*5 34pcs
- Screw M2*14 4pcs
- Metal Stud M3*16 22pcs
- Screw M3*12 26pcs
- Aluminum Standoffs M3*37.5 34pcs
- Aluminum Standoffs M3*100 4pcs
- Aluminum Standoffs M3*60 4pcs
Product Usage Instructions
- Before assembly, please make sure to check the orientation of
the parts. - Attach the Reinforcement Arm (2) to the Upper Plate (3), making
sure the side with grooves is facing downwards. - Attach the Arm (4) to the Reinforcement Arm (2).
- Attach the Bottom Plate (5) with the pressure riveting nut to
the Arm (4). - Attach the Bottom Reinforcement Plate (8) to the Bottom Plate
(5). - Attach the Motor Holder (15) to the Bottom Reinforcement Plate
(8). - Attach the Aluminum Standoffs (7) to the Motor Holder (15)
using blue threadlocker on the metal studs (10). - Attach the Gummie M3 (8) and Locknut M3 (9) to the Aluminum
Standoffs (7). - Attach the Metal Stud (10) to the Locknut M3 (9).
- Attach the Nylon Standoff M3*5 (11) to the Metal Stud
(10). - Attach the Side Support Plate R (12) and Side Support Plate L
(13) to the Upper Plate (3). - Attach the Top Reinforcement Plate (6) to the Upper Plate
(3). - Attach the Camera Mounting Plate (1) to the Top Reinforcement
Plate (6). - Attach the SMA Antenna Mount L (19), SMA Antenna Mount R (20),
and GPS Holder (41) to the Top Plate (18). - Attach the Positioning Sleeve (27) to the Top Plate (18).
- Attach the Injection Molded Duct (29) to the Bottom
Reinforcement Plate (8). - Attach the Landing Gear (38) to the Bottom Reinforcement Plate
(8). - Attach the Battery Pad (35) and Bottom Reinforcement Plate (36)
to the Bottom Plate (33). - Attach the Carbon Fiber Tube (37) to the Bottom Reinforcement
Plate (36). - Attach the Antenna Holder (39) to the Top Reinforcement Plate
(6). - Install propellers with proper direction.
- Use zipties as a backup to secure heavy loads.
Kopis X8 Cinelifter 5″( Ducted Version) Assembly Guide
PART LIST
#510204 Upper Plate
#510205 Lower Plate With 9 Pressure riveting nut
#510213 Arm 4pcs
#510210 Bottom Support Plate
#510207 Bottom Plate
#510214 Reinforcement Arm 4pcs
#510206 Top Reinforcement Plate 4pcs
#510215 Motor Holder 8pcs
#510208 Bottom Reinforcement Plate 4pcs
#510155 Camera Mounting Plate
#510217 Carbon fiber tube 7mm×60mm 4pcs
11
#510212 Side Support Plate R
#510211 Side Support Plate L
#510209 Top Plate
#31117 TPU 3D print set 17pcs
FPV Camera Mount
GPS Holder
Antenna Holder
SMA Antenna Mount L
SMA Antenna Mount R
Positioning Sleeve 8pcs
Landing Gear 4pcs
Gummie M8 9pcs
Gummie M3 8pcs
Nylon Standoff M3*5 4pcs
Screw M3*10 10pcs
Screw M3*8 50pcs
Screw M3*16 4pcs
Hand Screw M3*8 2pcs
Locknut M2 4pcs
Screw M3*35 4pcs
Locknut M3 17pcs
Flat Head Screw M3*8 4pcs
Socket Cap Screw M3*5 34pcs
Screw M2*14 4pcs
Metal Stud M3*16 22pcs
Screw M3*12 26pcs
Aluminum Standoffs M3*37.5 34pcs
Aluminum Standoffs M3*100 4pcs
11
Aluminum Standoffs M3*60 4pcs
Pag e | 1
www.holybro.com
1
Please mind the orientation
before assembly
4. Arm 4pcs
The side with these grooves should be facing downward
3. Upper Plate
5. Screw M3*12 9pcs
2. Reinforcement Arm 4pcs
The lower plate has pressure riveting nut
1. Lower Plate
6. Screw M3*35 4pcs Pressure riveting nut 5. Screw M3*12 4pcs
2
7. Aluminum Standoffs
Recommendation: Use blue threadlocker on the metal studs
M3*37.5 32pcs
8. Gummie M3 8pcs
FC
9. Locknut M3 4pcs
ESC ESC
10. Metal Stud M3*16 16pcs
11. Nylon Standoff M3*5 4pcs
3
12. SMA Antenna MountR
M2
13. Screw M3*16 4pcs
M1 M4
M3
Front Back
16. Socket Cap Screw M3*5 32pcs
15. Motor Holder 4pcs
M8
14. SMA Antenna MountL 9. Locknut M3 4pcs
Pag e | 2
M5
5. Screw M3*12 8pcs M7
www.holybro.com
4
26. Camera Mounting Plate
17. Bottom Support Plate
Match the sides of
21
the plates
This facing forward
25. Aluminum Standoffs M3*100 2pcs
21. Screw M3*8 16pcs
27. Positioning Sleeve 8pcs
24. Metal Washer-Big 2pcs 23. Hand Screw M3*8 2pcs
28. Side Support Plate
R
18
25. Aluminum Standoffs
M3*100 2pcs
22. Side Support PlateL
DJI unit Type-c
21. Screw M3*8 6pcs
9. Locknut M3 6pcs 20. Screw M3*10 6pcs
5
29. Injection Molded Duct 8pcs
19. Gummie M8 8pcs Zipties can be used as a backup to secure heavy loads
30. Metal Washer 4pcs
31. Top Reinforcment Plate 4pcs
18. Top Plate
21. Screw M3*8 12pcs
NoteDuct’s curve side should be up
6
Please note the bottom plate orientation for battery strap
32. Flat Head Screw M3*8 4pcs
33. Bottom Plate
21. Screw M3*8 8pcs
34. Aluminum Standoffs M3*60 4pcs 10. Metal Stud M3*16 4pcs
35. Battery Pad 36. Bottom Reinforcment Plate 4pcs
30. Metal Washer 4pcs
Pag e | 3
www.holybro.com
7
21. Screw M3*8 4pcs
37. Carbon Fiber Tube 4pcs Install propellers with proper direction
38. Landing Gear( TPU) 4pcs
CCW Propeller
CW Propeller
CW Propeller
CCW Propeller
8
20. Screw M3*10 4pcs
CCW
40. Screw M2*14 2pcs
CW Propeller
39. Antenna Holder 40. Screw M2*14 2pcs
Extended antenna T-shaped antenna
CCW
5. Screw M3*12 3pcs
9. Locknut M3 2pcs
43. FPV Camera Mount
42. Locknut M2 4pcs
(SMA) 41. GPS Holder
Pag e | 4
www.holybro.com
