Sea Gull Lighting 7605401-115 Malone One Light Flush Mount Instruction Manual

7605401-115 Malone One Light Flush Mount

Installation Instructions for Malone Flush Mount

General Product Information:

• Intended to be installed utilizing NEC compliant junction
  boxes
• Safety listed for damp locations
• Typical installation shown in this instruction
• CAUTION – RISK OF FIRE: This product must be installed in
  accordance with the applicable installation code by a person
  familiar with the construction and operation of the product and the
  hazards involved.

SAVE THESE INSTRUCTIONS!

7400 Linder Ave., Skokie, IL 60077
T 847.410.4400 | F 847.410.4500
www.generationlighting.com

Product Usage Instructions:

1. First, ensure that you have a NEC compliant junction box
   available for installation.
2. Attach the mounting plate (5) to the junction box using screws
   (not included).
3. Attach the fixture base (2) to the mounting plate (5) using
   screws (not included).
4. Connect the wires from the fixture to the wires from the
   junction box according to the installation code.
5. Attach the shade (5) to the fixture base (2) using screws (not
   included).
6. Attach the diffuser (6) to the shade (5) using the collar nut
   (2).
7. Turn on power and test the fixture to ensure it is working
   properly.

Note: It is important to follow all safety guidelines and
installation codes when installing this product. If you are not
familiar with the construction and operation of the product or the
hazards involved, seek professional assistance.

Installation Instructions for
Malone Flush Mount
FLUSHMOUNT

MALONE_FLUSH
7505401, 7605401, 7705401 1.0

GENERAL PRODUCT INFORMATION:
These fixtures are intended to be installed utilizing NEC compliant junction boxes. This product is safety listed for damp locations. This instruction shows a typical installation.

CAUTION – RISK OF FIRE This product must be installed in accordance with the applicable installation code by a person familiar with the construction and operation of the product and the hazards involved.
Use minimum 90°c supply conductors.
SAVE THESE INSTRUCTIONS!

©2022 Visual Comfort & Co., L.L.C. All rights reserved. The Visual Comfort & Co. logo is a registered trademark of Visual Comfort & Co. Visual Comfort & Co. reserves the right to change specifications for product improvements without notification.

7400 Linder Ave., Skokie, IL 60077 T 847.410.4400 | F 847.410.4500
www.generationlighting.com

Install the Fixture
1A

JUNCTION BOX 4

MOUNTING PLATE

5

2 3
FIXTURE BASE FIXTURE SCREW
5

SHADE

DIFFUSER 6

COLLAR NUT

1 Secure the mounting plate to the junction box. 2 Connect the fixture to a suitable ground in accordance with local electrical codes. 3 Connect the white fixture wire (square and/or rigid) to the neutral power line wire with a wire nut. 4 Connect the black fixture wire (round and/or smooth) to the hot power line wire with a wire nut. 5 Neatly place all the wires into the junction box, place the fixture base onto the mounting studs, and secure it in place using the fixture screws. 6 Place the shade and diffuser onto the socket, then secure them in place by screwing the collar nut onto the socket. 7 Screw the lamp into the socket. Refer to the label on the socket for Max Wattage Information.

2
