1 VT-60006 Backlit Surface Mounted Panel

VT-60006 Backlit Surface Mounted Panel

Product Information:

The LED Backlit Surface Mounted Panel is a lighting fixture that
has a round or square shape. It is available in different models
with varying SKU numbers. It has a wattage ranging from 6W to 24W
and provides a high lumens output. The Color Rendering Index (CRI)
is not specified. The product has a plastic body with an IP20
rating and is suitable for indoor use only. The product has a long
life span of 20,000 hours with an on/off cycle of more than 15,000
times. The product dimensions vary according to the model.

The product must be used with caution and must not be disposed
of with other household wastes. Direct exposure to the LED light
beam should be avoided, and the product must only be supplied by
rated voltage or voltage within the range provided. It is forbidden
to use the product with damaged protective cover and must not be
used in unfavorable conditions such as dust, water, moisture,
vibrations, explosive air atmosphere, fumes, or chemical fumes,
etc.

Product Usage Instructions:

Any maintenance work must be performed when the power supply is
cut off and the product has cooled down.
Clean only with a soft and dry cloth. Do not use chemical
detergents.
Do not cover the product and ensure free air access as it may
heat up to a higher temperature.
Read the manual before mounting and have it installed by a
qualified electrician.
Switch off the power before starting the installation.
Confirm the installation position of the bracket and drill a
hole.
Plug in expansion bolt and fix the bracket on the ceiling with
screws.
Connect the wiring as per wiring diagram.
Fix the panel onto the bracket and fix the light and bracket
with screws.
Switch on the power and test the light.

If there are any queries or issues with the product, reach out
to the manufacturer at [email protected].

View Fullscreen

INSTRUCTION MANUAL
LED BACKLIT SURFACE MOUNTED PANEL

TECHNICAL DATA

MODEL

SKU

SHAPE

WATTS LUMENS

CRI

BEAM IP ANGLE RATING

BODY TYPE

TOTAL CURRENT

INPUT POWER

LIFE SPAN

ON/OFF CYCLE

DIMENSION (LxWxH)

7873,7874
VT-60012 7875,97173
97178

7876,7877
VT-60018 7878,97174,97175
97179,97180

7879,7880

VT-60024

7881 97176,97177

97181,97182

ROUND SQUARE ROUND SQUARE ROUND
SQUARE

12W 1200LM >80 120° 18W 1800LM >80 120° 24W 2400LM >80 120°

IP20 PLASTIC IP20 PLASTIC IP20 PLASTIC

71mA 103mA 160mA

AC:220-240 50/60Hz

20000H

>15000 167.4×30.7mm

AC:220-240 50/60Hz

20000H

>15000 215.6×30.8mm 214x214x31mm

AC:220-240 50/60Hz

20000H

>15000 288.6×31.2mm

287x287x30.7mm

INTRODUCTION & WARRANTY Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully before starting the installation and keep this manual handy for future reference. If you have any another query, please contact our dealer or local vendor from whom you have purchased the product. They are trained and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no warranty against damage to any surface due to incorrect removal and installation of the product. The products are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This product is warranted for manufacturing defects only.

WARNING · Please make sure to turn off the power before starting the installation. · Installation must be performed by a certified person. · The light source of this luminaire is not replaceable, when the light source reaches its end of life the whole luminaire should be replaced. · For Indoor use only · If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by the manufacturer or his service agent or a similar qualified person in order to avoid a hazard. · Method of attachment of the cable or cord such that any replacement can only be made by the manufacturer, his service agent or similar qualifed person.

This marking indicates that this product should not be disposed of with other household wastes.

Caution, risk of electric shock.

ATTENTION! Do not look directly at LED light beam. Product can only be supplied by rated voltage or voltage within the range provided. It’s forbidden to use the product with damaged protective cover. Product must not be used in unfavorable conditions, e.g. dust, water, moisture, vibrations, explosive air atmosphere, fumes, or chemical fumes, etc. In the area of strong electromagnetic interference, the functioning of the product may be disrupted.
USAGE GUIDELINES/MAINTENANCE Any maintenance work must be performed when the power supply is cut off and the product has cooled down. Clean only with so and dry cloths. Do not use chemical detergents. Do not cover the product. Ensure free air access. Product may heat up to a higher temperature.
MOUNTING Read the manual before mounting. Mounting should be performed by a qualified electrician. Exercise caution. Product has a protective contact /terminal. Failure to connect the protective lead may lead to electric shock. Mounting diagram: see pictures. Check for proper mechanical fastening and connection to electrical power prior to first use.
SURFACE PANEL INSTALLATION DIAGRAM

1.Switch OFF the power before starting the installation

2.Confirm the installation position of the bracket

3.Drill a hole.

4.Plug in expansion bolt.

5.Fix the bracket ( Included) on the ceiling with screws.

6.Connect the wiring as per wiring diagram

7.Fix the panel onto the bracket

8.Fix the light and bracket with screws.

9.Switch ON the power and test the light.

IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: [email protected]

LED

SKU
