48CWRT124 CompR 12 Inch 2-Ohm DVC Subwoofer
Product Information
The product is a CWRT Mounting Hole Cover Install Sheet for
sealed enclosures. The user manual provides information about the
minimum and maximum sealed volume and power handling for different
models of CWRT speakers – CWRT67, CWRTB, CWRT10, and CWRT12. The
panel dimensions for minimum sealed enclosures using 3/4 (1.9cm)
thick MDF are also provided. The manual also includes instructions
for adding triangular bracing between each of the larger
unsupported panels and using the template inside the CWRT’s
shipping carton to mark the mounting hole.
The manual also provides information about vented enclosures. It
states that for vented enclosures, the displacement of the port
must be calculated and added to the internal volume of the final
design. It also provides an example calculation for the CWRT10
Vented Minimum design’s external port dimensions using 3/4 (1.9cm)
MDF.
Product Usage Instructions
To use the product, follow the below instructions:
- Refer to the manual to determine the minimum and maximum sealed
volume and power handling for your specific model of CWRT speaker –
CWRT67, CWRTB, CWRT10, or CWRT12. - Use the panel dimensions provided in the manual for minimum
sealed enclosures using 3/4 (1.9cm) thick MDF to construct the
enclosure. - Add triangular bracing between each of the larger unsupported
panels as instructed in the manual. - Use the template inside your CWRT’s shipping carton to mark the
mounting hole, then cut directly on the line as instructed in the
manual. - If you plan to use a vented enclosure, calculate the
displacement of the port and add it to the internal volume of the
final design as instructed in the manual. Use the outer dimensions
of the port and multiply X x Y x Z, then convert to cubic feet. For
example, the CWRT10 Vented Minimum design’s external port
dimensions are, using 3/4 (1.9cm) MDF: (10.5 + 1.5 total MDF wall
thickness) x (2 + 1.5 total MDF wall thickness) x (20) x (1 ft3 /
1728 in3 ) = .49 ft3.
-CD
0)-
-®
CWRT Mounting Hole Cover Install Sheet 48CWRT+B-20200617
Sealed Enclosures ICaja Sellados I Geschlossenen Gehausen IEnceintes Closes
Minimum Sealed
Volume 113 [L] and Power Handling
Minimale Sealed
Volumen L und Belastbarke1t
Minimo Sellado
Volumen, p1es3 [L] y Procesamiento de potencia
Minimum Etanches
Volume pied au cube [L] et Puissance admissible
Maximum Sealed
Volume 113 [L] and Power Handling
Maximale Sealed
Volumen L und Belastbarkeit
Maxima de Sellado
Volumen, p1es3 [L] y Procesamiento de potencia
Maximum Etanches
Volume pied au cube [L] et Puissance admissible
CWRT67 CWRTB CWRT10 CWRT12
.18 [5] .2 [5.66] .4 (11 .3] .55 (15.6]
150WRMS 300WRMS 400WRMS 500WRMS
CWRT67 CWRTB CWRT10 CWRT12
.75 [21.24] 1 (28.32] 1.25 [35.4] 2 (56.64]
150W RMS 300WRMS 400WRMS 500WRMS
Panel Dimensions for Minimum Sealed Enclosures using 3/4″ (1.9cm) thick MDF Dimensiones del panel para las cajas selladas minimas recomendadas con MDF de 3/4 de pig. (1 .9cm) Plattengr6Ben fur GeschlosseneGehauseKompakt mit 1,9 cm dicken Faserplatten Dimensions de panneau pour enceintes hermetiques avec carton dur de densite moyenne d’une epaisseur de 1,9 cm
Volume ft3 [L]
Panel A in. [cm]
Volumen, pies3 [L]
Panel A, pig [cm]
Volumen L
Platte A, cm
Volume pied au cube [L] Panneau A pouce [cm]
Panel B in. [cm] Panel B, pig [cm] Platte B, cm Panneau B pouce [cm]
Panel C in. [cm] Panel C, pig [cm] Platte C, cm Panneau C pouce [cm]
CWRT67
.18 [5]
9.5×13.5 [24.1 x34.3]
13.5×3 [34.3×7.62]
8×3 [30.5×7.62]
CWRTB
.2 [5 .66]
11.5×13 [29.2×33]
13×3 [33×7.62]
10×3 [25.4×7.62]
CWRT10 CWRT12
.4 [11.3] .55 (15.6]
12.5×17.25 [31.75×43.8] 15.5×18.5 [39.37×47]
17.25×4 [43 .8×10.5] 18.5×4 [47×10.16]
11×4 [28.16×10.5] 14×4 [35.6×10.16]
Add triangular bracing between each of the larger unsupported panels.
Anada refuerzos triangulares entre cada uno de los paneles no soportados.
Fugen Sie dreieckige Abstutzungen zwischen alien groBeren, nicht abgestutzten Paneelen ein.
Ajoutez un renfort triangulaire entre chacun des grands panneaux non soutenus.
Use the template inside your CWRT’s shipping carton to mark the mounting hole, then cut directly on the line.
Utilice la plantilla dentro del carton de empaque de su Comp para marcar el orificio de montaje; luego, corte directamente sobre la lfnea.
Nutzen Sie die Schablone, die Sie im Versandkarton lhres CWRT finden, um das Montageloch anzuzeichnen und schneiden Sie es dann genau entlang der Linien aus.
a Utilisez le modele situe l’interieur du carton d’expedition de
votre Comp pour marquer le trace de montage, puis decoupez directement la ligne.
D
C
CWRT10, CWRT12: D = 3″ x 3″ (8cm x 8cm)
A
CWRT67, CWRT8: D = 2″ x 2″ (5cm x 5cm)
Vented Enclosures I Caja Ventilados I Bassreflex-Gehause IEnceintes Aerees
For the vented enclosures the displacement of the port must be calculated and added to the internal volume of
the final design. Use the outer dimensions of the port and multiply “X x Y x Z”, then convert to cubic feet. For example, the CWRT10 Vented Minimum design’s external port dimensions are, using 3/4″ (1 .9cm) MDF:
(10.5″ + 1.5″ total MDF wall thickness) x (2″ + 1.5″ total MDF wall thickness) x (20″) x (1 ft3 / 1728 in3 ) = .49 ft3 ,
Then, add this number to the internal volume of the enclosure. 1.25 ft3 + .49 ft3 = 1.74 ft3
Todas las medidas de pies cubicos (L) en este manual, incluyen el desplazamiento del woofer. Para las cajas ventiladas, se debe calcular el desplazamiento del puerto, y anadirlo al volumen intemo del diseno final. Use las dimensiones extemas del Puerto y multipliquelas “X x Y x Z”, y luego haga la conversion a pies cubicos. Por ejemplo, las dimensiones del puerto extemo del diseno de CWRT10 Minimo Ventilado son, utilizando 3/4″ (1,9cm) MDF:
(10,5″ + 1,5″ grosor total de la pared MDF) x (2″ + 1,5″ grosor total de la pared MDF) x (20″) x (1 pie3 / 1728 pulg3 ) = 0,49 pie3 ,
Luego, anada este numero al volumen intemo de la caja. 1,25 pie3 + 0,49 pie3 = 1,74 pie3 .
Fur ventilierte Gehause muss die Verschiebung des Ports gesondert berechnet und zum lnnenvolumen des endgultigen Designs hinzugefugt werden .
Nutzen Sie die AuBenabmessungen des Ports und multiplizieren Sie ,,X x Y x Z”, dann rechnen Sie die Zahl in KubikfuB um. Zurn Beispiel beim Design CWRT10 Vented Minimale werden die extemen Portabmessungen mit einer 1,9 cm dicken mittelfesten Spanplatte folgendermaBen berechnet:
——- X —–
(10,5″ + 1,5″ Gesamtwanddicke der MDF) x (2″ + 1,5″ Gesamtwanddicke der MDF) x (20″) x (1 FuB3 / 1728 Zoll3) = 0,49 FuB3 .
Diese Zahl addieren Sie zum lnnenvolumen des Gehauses. 1,25 FuB3 + 0,49 FuB3 = 1 74 FuB3 .
Pour les enceintes aerees, le deplacement du port doit etre calcule et ajoute au volume inteme du design final. Utilisez les dimensions extemes du port et effectuez la multiplication” X x Y x Z », puis convertissez le resultat en pieds cubiques. Par exemple, en utilisant une MDF epaisse de 3/4″ / 1,9 cm, les dimensions du port exteme du design minimum aere du CWRT10 sont :
(Epaisseur totale paroi MDF 10,5″ + 1,5″) x (epaisseur totale paroi MDF 2″ + 1,5″) x (20″) x (1 pied3 / 1728″3) = 0,49 pied3 .
Ajoutez ensuite ce nombre au volume inteme de l’enceinte. 1,25 pied3 + 0,49 pied3 = 1,74 pieds3 .
Wiring I Cabe/ado I Verkabelung I Cab/age
Warranty I Garantia I Garantie
Series ISerieller ISerie
Dual 20 Voice Coils = 40 Load Dual 40 Voice Coils = 80 Load
Doble bobina de voz de 2 O = Carga de 4 O Doble bobina de voz de 4 O = Carga de 8 O
Doppelte 20 = 40 Lastwiderstand Doppelte 40 = 80 Lastwiderstand
Doubles bobines de 20 = charge de 40 Doubles bobines de 40 = charge de 80
Parallel I Para/e/o Para/le/er I Parallele
Dual 20 Voice Coils= 1o Load
Dual 40 Voice Coils = 20 Load
Doble bobina de voz de 2 0 = Carga de 1 0
Doble bobina de voz de 4 O = Carga de 2 O
Doppelte 20 = 10 Lastwiderstand Doppelte 40 = 20 Lastwiderstand
Doubles bobines de 20 = charge de 10
Doubles bobines de 40 = charge de 20
KICKER products are warranted against defects. Duration and terms of warranty depend on the laws in the country in which it was purchased. For details see your local KICKER Dealer or www.kicker.com/warranty.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law . You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
Los productos KICKER estan garantizados contra defectos. La duraci6n y los terminos de la garantfa dependen de las leyes del pafs en donde se realiz6 la CWRTa. Para mas detalles consulte a su distribuidor local de KICKER o visite www.kicker.com/warranty.
KICKER-Produkte haben eine Garantie gegen Material- und Verarbeitungsfehler. Dauer und Bedingungen der Garantie hangen von den Gesetzen des Landes ab, in dem sie erworben wurden. Bzgl. Einzelheiten wenden Sie sich bitte an lhren brtlichen KICKER-Handler oder besuchen Sie www.kicker.com/warranty
Les produits KICKER sont garantis contre les defauts. La duree et les modalites de la garantie dependent des lois du pays dans lequel le produit a ete achete. Pour plus d’information veuillez verifier aupres de votre distributeur local KICKER ou visiter le site : www.kicker.com/warranty.
WARNING: KICKER products are capable of producing sound levels that can permanently damage your hearing! Please use common sense when controlling volume.
ADVERTENCIA: Los excitadores KICKER son capaces de producir niveles de sonido que pueden danar permanentemente el ofdo. Subir el volumen del sistema hasta un nivel que produzca distorsi6n es mas danino para el ofdo que escuchar un sistema sin distorsi6n al mismo volumen. El dolor es siempre una indicaci6n de que el sonido es muy fuerte y que puede danar permanentemente el ofdo. Sea precavido cuando controle el volumen.
WARNUNG: KICKER-Treiber kbnnen einen Schallpegel erzeugen, der zu permanenten Gehbrschaden fuhren kann! Wenn Sie ein System auf einen Pegel stellen, der hbrbare Verzerrungen erzeugt, schadet das lhren Ohren mehr, als ein nicht verzerrtes System auf dem gleichen Lautstarkepegel. Die Schmerzschwelle ist immer eine Anzeige dafur, dass der Schallpegel zu laut ist und zu permanenten Gehbrschaden fuhren kann. Seien Sie bei der Lautstarkeeinstellung bitte vemunftig!
AVERTISSEMENT: Les haut-parleurs KICKER ont la capacite de produire des niveaux sonores pouvant endommager l’ou’i’e de fa<;:on irreversible! Laugmentation du volume d’un systeme jusqu’a un niveau presentant une distorsion audible endommage davantage l’ou’i’e que l’ecoute d’un systeme sans distorsion au meme volume. Le seuil de la douleur est toujours le signe que le niveau sonore est trop eleve et risque d’endommager l’ou’1e de fa<;:on irreversible. Reglez le volume en faisant prevue de bon sens !
Vented Enclosures I Caja Ventilados IBassreflex-Gehiiuse IEnceintes Aerees
Vented Minimum Box Volume, ft3 [L] Port Opening, in. x in. [cm x cm] Port Length, in. [cm] Power Handling, RMS
Vented Maximum Box Volume, ft3 [L] Port Opening, in. x in. [cm x cm] Port Length, in. [cm] Power Handling, RMS
CWRT67
N/A N/A N/A N/A
CWRT67
N/A N/A N/A N/A
CWRTB .8, 22.7 1.5×8, 3.8×20.3 20.75, 52 300
CWRTB 1.2, 34 2×8, 5.1 x20.3 19.125, 48.6 300
CWRT10 1.25, 35.4 2×10.5, 5.1×26.7 20, 50.8 400
CWRT10 1.75, 49.6 2.5×10.5, 6.4×26. 7 20, 50.8 400
CWRT12 1.75, 49.6 2.5×12.5, 6.4×31 .8 20, 50.8 500
CWRT12 2.25, 63.7 3×12.5, 7.6×31.8 20.5 , 52.1 500
Ventilada Minimo Caja Volumen, pies3 [L] La apertura del puerto, in x in [cm x cm] Puerto de Longitud, in [cm] Procesamiento de potencia, RMS
Ventilada Maxima Caja Volumen, pies3 [L] La apertura del puerto, in x in [cm x cm] Puerto de Longitud, in [cm] Procesamiento de Potencia, RMS
CWRT67
N/A N/A N/A N/A
CWRT67
N/A N/A N/A N/A
Ventilierte Minimale Gehause Volumen, L Port Offnung , cm x cm Port Lange, cm Belastbarkeit, RMS
Ventilierte Maximale Gehause Volumen, L Port Offnung, cm x cm Port Lange, cm Belastbarkeit, RMS
CWRT67
N/A N/A N/A N/A
CWRT67
N/A N/A N/A N/A
Minimum aere
Volume de Caisson, tt3 [L]
Port D’ouverture, pouce x pouce [cm x cm] Port Longueur, pouce [cm] Puissance admissible, RMS
CWRT67
N/A N/A N/A N/A
Maximum aere
Volume de Caisson, tt3 [L]
Port D’ouverture, pouce x pouce [cm x cm] Port Longueur, pouce [cm] Puissance admissible, RMS
CWRT67
N/A N/A N/A N/A
CWRTB .8, 22.7 1.5×8, 3.8×20.3 20.75, 52 300
CWRTB 1.2, 34 2×8, 5.1 x20.3 19.125, 48.6 300
CWRTB .8, 22.7 1.5×8, 3.8×20.3 20.75, 52 300
CWRTB 1.2, 34 2×8, 5.1 x20.3 19.125, 48.6 300
CWRTB .8, 22.7 1.5×8, 3.8×20.3 20.75, 52 300
CWRTB 1.2, 34 2×8, 5.1 x20.3 19.125, 48.6 300
CWRT10 1.25, 35.4 2×10.5, 5.1×26.7 20, 50.8 400
CWRT10 1.75, 49.6 2.5×10.5, 6.4×26. 7 20, 50.8 400
CWRT12 1.75, 49.6 2.5×12.5, 6.4×31.8 20, 50.8 500
CWRT12 2.25, 63.7 3×12.5, 7.6×31.8 20.5, 52.1 500
CWRT10 1.25, 35.4 2×10.5, 5.1×26.7 20, 50.8 400
CWRT10 1.75, 49.6 2.5×10.5, 6.4×26.7 20, 50.8 400
CWRT12 1.75, 49.6 2.5×12.5, 6.4×31.8 20, 50.8 500
CWRT12 2.25, 63.7 3×12.5, 7.6×31 .8 20.5, 52.1 500
CWRT10 1.25, 35.4 2×10.5, 5.1×26.7 20, 50.8 400
CWRT10 1.75, 49.6 2.5×10.5, 6.4×26. 7 20, 50.8 400
CWRT12 1.75, 49.6 2.5×12.5, 6.4×31 .8 20, 50.8 500
CWRT12 2.25, 63.7 3×12.5, 7.6×31.8 20.5, 52.1 500
(fKICKER CWRT8′ Subwoofer
Recommended Amplifier Power [Watts RMS] Peak Power Handling [Watts] Rated Impedance [O] Outer Frame Dimension [in, cm] Mounting Depth [in, cm] Mounting Cutout [in, cm] Frequency Response [Hz]
CWRT67 75-150 300 2 or 4 6-13/16, 17.3 2-3/4, 7 5-5/8, 14.3 30-500
CWRTB 150-300 600 2 or 4 8-1/2, 21.6 2-11/16, 6.7 6-15/16, 17.7 30-500
CWRT10 200-400 800 2 or 4 10-11 /16, 27 .1 3-7/16, 8.8 9-1/8, 23.2 25-500
CWRT12 250-500 1000 2 or 4 12-9/16, 31 .9 3-3/4, 9.6 11, 27.9 25-500
CWRT67
Potencia recomendada del amplificador [Watts RMS] 75-150
Manejo de potencia maxima [Watts]
300
lmpedancia nominal [O]
2o4
Dimension externa Marco [pig., cm]
6-13/16, 17.3
Montaje Profundidad [pig., cm]
2-3/4, 7
Montaje de recorte [pig., cm]
5-5/8, 14.3
Respuesta de frecuencia [Hz]
30-500
CWRTB 150-300 600 2o4 8-1/2, 21.6 2-11/16, 6.7 6-15/16, 17.7 30-500
CWRT10 200-400 800 2o4 10-11/16, 27.1 3-7/16, 8.8 9-1/8, 23.2 25-500
CWRT12 250-500 1000 2o4 12-9/16, 31.9 3-3/4, 9.6 11 , 27.9 25-500
Empfohlene Verstarkerleistung [Watts RMS] lmpulsbelastbarkeit [Watts] Nennimpedanz [O] AuBenrahmen Dimension [zoll, cm] Einbautiefe [zoll, cm] Montageausschnitt [zoll, cm] Frequenzgang [Hz]
CWRT67 75-150 300 2 oder 4 6-13/16, 17,3 2-3/4, 7 5-5/8, 14,3 30-500
CWRTB 150-300 600 2 oder 4 8-1/2, 21,6 2-11/16, 6,7 6-15/16, 17,7 30-500
CWRT10 200-400 800 2 oder 4 10-11/16, 27,1 3-7/16, 8,8 9-1/8, 23,2 25-500
CWRT12 250-500 1000 2 oder 4 12-9/16, 31,9 3-3/4, 9,6 11,27,9 25-500
CWRT67
Puissance d’amplificateur recommandee [Watts RMS] 75-150
Puissance admissible de pointe [Watts]
300
Impedance nominale [O]
2 OU 4
Dimension de cadre exterieur [po, cm]
6-13/16, 17,3
Profondeur de montage [po, cm]
2-3/4, 7
Montage Decoupe [po, cm]
5-5/8, 14,3
Reponse en frequence [Hz]
30-500
CWRTB 150-300 600 2 OU 4 8-1/2, 21,6 2-11/16, 6,7 6-15/16, 17,7 30-500
CWRT10 200-400 800 2 OU 4 10-11/16, 27,1 3-7/16, 8,8 9-1/8, 23,2 25-500
CWRT12 250-500 1000 2 OU 4 12-9/16, 31,9 3-3/4, 9,6 11,27,9 25-500
Thiele-Small parameters available at www.kicker.com Para.metros Thiele-Small disponibles en www.kicker.com Thiele -Small-Parameter finden Sie unter www.kicker.com Parametres Thiele-Small disponibles sur www.kicker.com
