True Fine Td90036c, Td90032c 4-light Chandelier Instruction Manual

TD90036C, TD90032C 4-Light Chandelier

Product Information

The 4-Light Chandelier comes with the following parts:

• Outlet box Black
• Wire nuts Smooth
• [GROUP A] J.Screw
• Green(Ground)
• White Ribbed
• [GROUP B]
• Bare copper wire(Ground)
• I.Mounting strap
• H.Canopy G.Canopy lock ring
• F.Fixture chain E.Loop
• D.Shade
• C.Stem
• B.Iron sleeve
• A.Fixture body

Product Usage Instructions

1. Screw Stem (C) onto the Fixture body (A), install Iron sleeve
   (B) to the lamp holder.
2. Thread the wires through the hole in the top of Shade (D), then
   screw Loop (E) to Stem (C).
3. Fix Mounting strap (I) to outlet box with Screw (J).
4. Thread the wires through Canopy (H) and Mounting strap (I),
   link Loop (E) and Mounting strap (I) by Fixture chain (F).
5. Connect the wires according to the picture above. (Please refer
   to the wiring instruction for details)
6. Fix Canopy (H) to Mounting strap (I) with Canopy lock ring
   (G).

Wiring Instructions

1. Insert the green grounding screw into the hole with two raised
   dimples on the mounting bar. Wrap the ground wire from the fixture
   (if supplied) around the green grounding screw, then connect it to
   ground wire from the outlet box (if not fixed on the outlet box)
   using a wire connector (not supplied). If ground wire from the
   fixture is not supplied, wrap the ground wire (if not fixed on the
   outlet box) from the outlet box around the green grounding screw
   and tighten it.
2. Take note of the color of the wire(s) on your fixture. Identify
   which group your fixture wire(s) falls into and connect the wires
   according to the directions below:
   • [GROUP A]: Connect to Black House Wire
   • [GROUP B]: Connect to White House Wire
3. Take your fixture wire(s) from [Group A] and place evenly
   against the black wire from the outlet box. Do NOT twist wires
   together before using wire connectors.
4. Fit a wire connector over the wires and screw the connector
   clockwise until you feel firmness.
5. Try gently to pull the connector off the wires. If you can pull
   the connector off, carefully re-do steps 3 and 4 as above, and
   check again for a firm connection.
6. Connect the fixture wire from [Group B] to the white wire from
   the outlet box in the same manner. Make sure no bare wires can be
   seen outside wire connectors.

Product Specifications

Product Packaging: Not specified

Cleaning Instructions

To clean, wipe fixture with a soft cloth. Clean glass with a
mild soap. Do not use abrasive materials such as scouring pads or
powders, steel wool or abrasive paper.

Safety Information

Always switch off the electricity supply and allow to cool for
10 minutes before changing the light bulbs.

Contact Information

E-mail: [email protected]

Printed in China

Instruction Manual
4-Light Chandelier

Overview
Outlet box Black
Wire nuts Smooth
[GROUP A] J.Screw

Green(Ground)

White Ribbed

Bare copper wire(Ground)

I.Mounting strap

H.Canopy G.Canopy lock ring

F.Fixture chain E.Loop

D.Shade

C.Stem
B.Iron sleeve
A.Fixture body
Assembly Instruction
1.Screw Stem (C) onto the Fixture body (A), install Iron sleeve (B) to the lamp holder.
2.Thread the wires through the hole in the top of Shade (D), then screw Loop (E) to Stem (C).
2.Fix Mounting strap (I) to outlet box with Screw (J). 3.Thread the wires through Canopy (H) and Mounting strap (I),
link Loop (E) and Mounting strap (I) by Fixture chain (F). 4.Connect the wires according to the picture above.
(Please refer to the wiring instruction for details ) 5.Fix Canopy (H) to Mounting strap (I) with Canopy lock ring (G).

Wiring Instruction

1. Insert the green grounding screw into the hole with two raised dimples on the mounting bar. Wrap the ground wire from the fixture (if supplied) around the green grounding screw, then connect it to ground wire from the outlet box (if not fixed on the outlet box) using a wire connector(not supplied). If ground wire from the fixture is not supplied, wrap the ground wire (if not fixed on the outlet box) from the outlet box around the green grounding screw and tighten it.

NEVER CONNECT GROUND WIRE TO BLACK OR WHITE POWER SUPPLY WIRES.

2.Take note of the color of the wire(s) on your fixture. Identify which group your fixture wire(s) falls into and connect the wires according to the directions below:

BLACK

WHITE

*PARALLEL WIRE (round & smooth) *PARALLEL WIRE (square & ridged)

WHITE OR GREY WITH TRACER WHITE OR GREY WITHOUT TRACER

BROWN, GOLD OR BLACK WITHOUT TRACER

BROWN, GOLD OR BLACK WITH TRACER

3.Take your fixture wire(s) from [Group A] and place evenly against the black wire from the outlet box. Do NOT twist wires together before using wire connectors. 4.Fit a wire connector over the wires and screw the connector clockwise until you feel firmness. 5.Try gently to pull the connector off the wires. If you can pull the connector off, carefully re-do steps 3 and 4 as above, and check again for a firm connection.
6.Connect the fixture wire from [Group B] to the white wire from the outlet box in the same manner. Make sure no bare wires can be seen outside wire connectors.

Product Specifications

Input voltage 120V Rated power 40 MAX × 4 Lamp socket E12
Product Packaging
Fixture body × 1 Mounting strap × 1 & Canopy × 1 Shade × 1 & Loop × 1 Screw × 2 & Wire nut × 3 Iron sleeve × 4 Lamp instruction × 1

Cleaning
To clean, wipe fixture with a soft cloth. Clean glass with a mild soap. Do not use abrasive materials such as scouring pads or powders, steel wool or abrasive paper.
Safety Information
Always switch off the electricity supply and allow to cool for 10 minutes before changing the light bulbs.

CONTACT US
E-mail:[email protected]

Print in china
