TD10018C Veronica 19.7 in 5 Light Chandelier

Product Information:

The 5-Light Chandelier is a lighting fixture that comes with all
the necessary mounting hardware for installation. The package
contents include Fixture Loop, Top Assembly, Rod, Socket Assembly,
Plate, Bottom Box, Allen Screw, Lock Ball, Bottom Arm, Mounting
strap, Wire nuts, Outlet Box Screw, Canopy, Quick link, and Fixture
chain. The estimated assembly time is 30 minutes and tools required
for assembly include a flathead screwdriver, Phillips screwdriver,
pliers, electrical tape, wire cutters, and safety glasses.

Product Usage Instructions:

  1. Before beginning the assembly of the product, make sure all
    parts are present. Compare parts with the package contents list and
    hardware contents list. Do not attempt to assemble the product if
    any part is missing or damaged.
  2. Unfold the side arms in Top Assembly (B) and install Socket
    Assembly (D), Rod (C), Top Assembly (B), and Fixture Loop (A)
    together. Thread wire and Fixture chain (FF) through Canopy (DD)
    and link Loop (A) and Mounting Strap (AA) by Fixture chain
    (FF).
  3. Unscrew the nuts on Top Assembly (B) and install Bottom Arm (I)
    to Top Assembly (B), then lock them with these nuts.
  4. Install Bottom Arms (I) to Bottom Box (F) and lock them with
    Lock Ball (H). Install Plate (E) to Bottom Box (F), lock it with
    Allen Screw (G).
  5. Strip 3/4 in. of insulation from wire ends. Twist stripped ends
    together with pliers, black to black (power) and white to white
    (neutral). Attach copper wire to ground wire. If necessary, attach
    copper ground wire to grounded outlet box. Attach wire nuts and
    tape wire nuts and wires together.
  6. Fix Canopy (DD) to Mounting strap (AA) with canopy lock
    ring.

If you have any questions or concerns, please contact Customer
Service at [email protected]

5 -Light Chandelier

Instruction Manual
MOUNTING HARDWARE

Print in china

PACKAGE CONTENTS
A. Fixture Loop x 1
C.Rod x 1
B. Top Assembly x 1

D.Socket Assembly x 1
E.Plate x 1
F.Bottom Box x 1

G.Allen Screw x 1
H.Lock Ball x 5
I.Bottom Arm x 5

AA. Mounting strap x 1

BB. Wire nuts x 3

CC. Outlet Box Screw x 2

DD. Canopy x 1

EE. Quick link x 2

FF. Fixture chain x 1

SAFETY INFORMATION

Please read and understand this entire manual before attempting to assemble, operate or install the product.

WARNING
· TURN OFF ELECTRICITY at main fuse box (or circuit breaker box) before beginning installation by removing fuse (or switching off circuit breaker). · MINIMUM 90°C SUPPLY CONDUCTORS.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Times: 30 minnutes Tools Required for Assembly (not included): Flathead screwdriver , Phillips screwdriver, Pliers, Electrical tape, Wire cutters, Safety glasses. Helpful Tools (not included): Wire strippers, Step ladder.
Customer Service: [email protected]

ASSEMBLY INSTRUCTIONS

ASSEMBLY INSTRUCTIONS

1. Unfold the side arms in Top Assembly (B). 1

B

Install Socket Assembly (D), Rod (C), Top

4. Fix Mounting strap (AA) to outlet box with 4

Screw (CC).

CC

AA

Assembly (B), Fixture Loop (A) together.

Thread wire and Fixture chain (FF) through

A

Canopy (DD).

DD
Link Loop (A) and Mounting Strap (AA) by

FF
Fixture chain (FF).

C

A

D

2. Install Bottom Arms (I) to Bottom Box (F), 2 lock them with Lock Ball (H).

Install Plate (E) to Bottom Box (F), lock it

with Allen Screw (G).

I H

F
G E

5. Strip 3/4 in. of insulation from wire ends. 5 Twist stripped ends together with pliers (not included), black to black (power) and white to white (neutral). Attach copper wire to ground wire. Helpful hint: If necessary, attach copper ground wire to grounded outlet box. Attach wire nuts. Tape wire nuts and wires together.

3. Unscrew the nuts on Top Assembly (B), 3 Install Bottom Arm (I) to Top Assembly (B), then lock them with these nuts.

6. Fix Canopy (DD) to Mounting strap (AA) 6 with canopy lock ring.
B

Print in china

I
