PH3-LLT MK2 Proving Unit
PH3-LLT MK2 Proving Unit
Product Information
The PH3-LLT MK2 Proving Unit is a device that provides a 500V DC
output voltage (depending on battery condition) with a 10mA DC
output current into 2k. The unit has an LED indication of voltage
active and has dimensions of 41mm (h), 82mm (w), and 157mm (d). It
requires a 9V DC PP3 Alkaline Battery for power supply and has an
IP Rating of 40. The unit is compliant with BS EN 61010
standards.
Product Usage Instructions
Before use, ensure that both the PH3-LLT MK2 and the LLT MK2 are
clean and dry. Visually inspect all parts of the PH3-LLT MK2, if
any parts are damaged do not use the PH3-LLT MK2. Do not hold LLT
(Live Line Tester) MK2 between the hand-guard and the contact
electrode as there is an electrical shock risk. Always confirm that
the LED indicator on the proving unit illuminates when the test is
activated.
For maintenance, clean only with a dry cloth and do not use
solvents. Check the battery contacts and compartment for
electrolytic contamination, and clean any contamination with a dry
cloth. If the item becomes faulty, do not open it; instead, return
it to the manufacturer or an authorized Seaward Service Agent.
To maintain the specified performance, the instrument must be
verified at regular intervals by either the manufacturer or an
authorized Seaward Service Agent. The recommended calibration
period is one year.
For help or advice on Service and Calibration, contact:
Service Department
Seaward Electronic
Bracken Hill South West Industrial Estate
Peterlee Co Durham SR8 2SW England
Tel: 0191 5878739 / 0191 5878737
Email: [email protected]
Web: www.seaward.com
Important: In the interest of safety, the PH3-LLT MK2 should
only be used by competent suitably trained personnel after due
consideration of any hazard involved.
The following symbols are used on the PH3-LLT MK2 and in the
operating instructions:
- Warning of electrical danger! Indicates instructions must be
followed to avoid danger to persons. - Important, follow the documentation! This symbol indicates that
the operating instructions must be consulted and adhered to in
order to avoid danger.
4 Specification
Output Voltage
Output Current Indicator Dimensions Power Supply IP Rating Compliance
500V DC (depending on battery condition) 10mA DC into 2k LED indication of voltage active 41mm (h), 82 (w), 157mm (d) 9V DC, PP3 Alkaline Battery 40 BS EN 61010
5 Maintenance Clean only with a dry cloth; do not use solvents. Before use, ensure unit is clean and dry; visually inspect test terminals and case. Any damage must be rectified to preserve user safety.
Check the battery contacts and compartment is free of electrolytic contamination. Any contamination of the battery contacts or compartment should be cleaned with a dry cloth.
Always confirm that the LED indicator on the proving unit illuminates when the test is activated. Should the item become faulty do not open, return it to the manufacturer or an authorised Seaward Service Agent.
6 Battery Replacement · Disconnect all test leads. · Remove the battery compartment cover · Remove the discharged battery. · Insert the replacement battery into the battery compartment ensuring that the battery polarity matches the battery connector. · Replace the battery compartment cover.
7 Service and Calibration To maintain the specified performance, the instrument must be verified at regular intervals by either the manufacturer or an authorised Seaward Service Agent. We recommend a calibration period of one year. For help or advice on Service and Calibration contact:
Service Department Seaward Electronic Bracken Hill South West Industrial Estate Peterlee Co Durham SR8 2SW England
Tel: 0191 5878739 / 0191 5878737 Email: [email protected] Web: www.seaward.com
PH3-LLT MK2 Proving Unit
Operating Instructions
Bracken Hill South West Industrial Estate Peterlee Co Durham SR8 2SW ENGLAND Tel: +44(0)191 5863511 www.seaward.com [email protected] [email protected] Part Number 423A651 Revision 4 © 2022 Seaward Electronic Ltd
Limited Warranty & Limitation of Liability
SEAWARD Electronic Limited guarantees this product to be free from defects in material and workmanship under normal use and service for a period of 1 year. The period of warranty will be effective at the day of delivery.
(c) Copyright 2022 All rights reserved. Nothing from this edition may be multiplied, or made public in any form or manner, either electronically, mechanically, by photocopying, recording, or in any manner, without prior written consent from SEAWARD Electronic Limited. This also applies to accompanying drawings and diagrams.
Due to a policy of continuous development SEAWARD Electronic Limited reserves the right to alter the equipment specification and description outlined in this publication without prior notice and no part of this publication shall be deemed to be part of any contract for the equipment unless specifically referred to as an inclusion within such contract.
1
Important Information
In the interest of safety the PH3-LLT MK2 should only
be used by competent suitably trained personnel after
due consideration of any hazard involved.
The following symbols are used in these operating instructions and on the PH3-LLT MK2.
Warning of electrical danger! Indicates instructions must be followed to avoid danger to persons.
Important, follow the documentation! This symbol indicates that the operating instructions must be consulted and adhered to in order to avoid danger.
Before use, ensure that both the PH3-LLT MK2 and the LLT MK2 are clean and dry. Visually inspect all parts of the PH3-LLT MK2, if any parts are damaged do not use the PH3-LLT MK2.
Do not hold LLT (Live Line Tester) MK2 between the hand-guard and the contact electrode.
Electrical shock risk! Do not touch terminals!
Always prove the LLT MK2 before AND after use.
Always check that the LED indicator on the proving unit is illuminated whilst testing.
If the equipment is not used in a manner specified in the manual, the protection provided may be impaired.
Do not use without battery compartment cover fitted.
Do not energise the proving unit for longer than 5 seconds, to preserve the battery.
WEEE Directive This product has been designed and manufactured with high quality materials and components, which can be recycled and reused. When this symbol is attached to a product it means it is covered by the WEEE Directive. Please familiarise yourself with the appropriate local separate collection system for electrical and electronic products. Please dispose of this product according to local regulations. Do not dispose of this product along with normal waste. The correct disposal of this product will help prevent potential negative consequences for the environment and human health.
2 Environmental conditions PH3-LLT MK2 was designed to perform tests:
· In a dry environment. · At altitude of up to 2000M. · At temperature of 5-40oC without moisture
condensation.
3 Proving The PH3-LLT MK2 is intended to check if a LLT MK2 functions correctly.
1. Insert each probe of the LLT MK2 inside the PH3-LLT MK2 terminals.
2. Press down on the right terminal (closest to the battery compartment) to switch on the PH3-LLT MK2.
3. Confirm the LED on the PH3-LLT MK2 front panel is illuminating.
4. If LED does NOT illuminate, replace the battery by following 6 Battery Replacement instruction.
5. If LED still does NOT illuminate, this suggests PH3-LLT MK2 is faulty. DO NOT USE.
6. Confirm the Dual LEDs on LLT-PH3 are illuminating. If Dual LEDs are NOT illuminating, this suggests LLT MK2 is faulty. DO NOT USE.
7. Disconnect both probes from the terminals after test is complete.
Image above shows PH3-LLT MK2 before switched on.
Image above shows PH3-LLT MK2 switched on when the right terminal is pushed down.
