Enclo Ec18029 Box Contents Instruction Manual

EC18029 Box Contents

Product Information

The product is an EC18029 Screen Frame, which includes various
components designed for installation and usage.

Box Contents:

• A Post (3) – Three wooden stakes measuring 3 x 3 x 48 inches,
  pressure-treated for enhanced durability when installed in the
  ground.
• ACCENT PIECES:
  • B Board (20) – Twenty boards used as accent pieces for the
    screen frame.
  • C – Unspecified accent piece(s).
  • D Dowel (6) – Six dowels used for connecting and reinforcing
    the screen frame structure.
• SCREWS:
  • F (4) – Four screws for attaching various components of the
    screen frame.
  • Bag (F) – A bag containing the screws.
• E Post Cap (3) – Three post caps used to cover the top of the
  wooden stakes.
• SPACER:
  • H Wood Spacer (2) – Two wooden spacers used to create gaps or
    provide support between components of the screen frame.

Product Usage Instructions

Follow these instructions to properly use the EC18029 Screen
Frame:

1. Determine the desired location for the screen frame
   installation.
2. Prepare the ground by clearing any debris and ensuring it is
   level.
3. Take the A Post (3) wooden stakes and insert them into the
   ground, evenly spaced apart according to your desired screen frame
   dimensions.
4. Use the F screws (4) from the Bag (F) to attach the B Boards
   (20) as accent pieces to the A Posts (3), creating the main
   structure of the screen frame.
5. Insert the D Dowels (6) into the pre-drilled holes on the B
   Boards (20) to reinforce the screen frame structure.
6. If necessary, use the H Wood Spacers (2) to create gaps or
   provide support between components of the screen frame.

Ensure that all components are securely attached and properly
aligned to create a sturdy and functional screen frame.

Refer to the user manual for additional information and safety
guidelines.

SCREEN FRAME

Box Contents
EC18029

The wooden stakes are pressure treated to be more durable when installed in the ground.

A Post (3) 3″ x 3″ x 48″
ACCENT PIECES

B Board (20)

C
Stake (2) 1 ¼” x 1″ x 16″

D Dowel (6)
SCREWS
F (4)
Bag (F)

E Post Cap (3)
G #8 2 ½” Wood Screw (16) Bag (G)

SPACER
H Wood Spacer (2)
