VDY24-18NMP Duzy 24-18 Inch Hearth Kit

Product Information

The Duzy 24/18 Hearth Kit is a gas fireplace kit manufactured by
Hearth and Home Technologies. It is available in different models
and control options:

• VDY24/18NMP (Natural Gas Manual Control) – Ending Manufacturing
  Date: April 2019
• VDY24/18PMP (Propane Manual Control) – Ending Manufacturing
  Date: April 2019
• VDY24/18NVP (Natural Gas Millivolt Control) – Active
• VDY24/18PVP (Propane Millivolt Control) – Active

The kit includes various service parts necessary for
installation and maintenance. These parts are not sold directly to
consumers but can be ordered from a dealer or distributor. When
requesting service parts, provide the model number and serial
number.

Service Parts

Product Usage Instructions

To use the Duzy 24/18 Hearth Kit, follow these steps:

1. Ensure the gas supply is turned off and the valve is
   closed.
2. If using a manual control model, locate the regulator and
   control valve. If using a millivolt control model, locate the
   control valve, on/off switch, and wire harness.
3. Connect the appropriate gas supply line to the regulator or
   control valve.
4. If using a manual control model, connect the injector to the
   control valve. If using a millivolt control model, connect the
   injector to the control valve and wire harness.
5. Install the pilot assembly according to the instructions
   provided. Use the appropriate pilot assembly based on your gas type
   (NG or Propane) and control type (manual or millivolt).
6. Attach the thermocouple/thermopile to the pilot assembly.
7. Once all connections are secure, turn on the gas supply and
   open the valve.
8. If using a manual control model, ignite the pilot flame using
   the piezo igniter and adjust the flame using the control knob.
9. If using a millivolt control model, turn on the on/off switch
   to ignite the pilot flame. Use the control knob to adjust the
   flame.

Always refer to the user manual for specific instructions and
safety precautions before operating the Duzy 24/18 Hearth Kit.

Service Parts
Duzy 24/18″ Hearth Kit

DUZY
Beginning Manufacturing Date: N/A Ending Manufacturing Date: Active

VDY24/18NMP (Natural Gas Manual Control) – Ending Manufacturing Date: April 2019 VDY24/18PMP (Propane Manual Control) – Ending Manufacturing Date: April 2019 VDY24/18NVP (Natural Gas Millivolt Control) – Active VDY24/18PVP (Propane Millivolt Control) – Active
1

2 7

6

5

3

4

IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.

ITEM

DESCRIPTION

Pilot Assembly (Manual Control) 1
Pilot Assembly (Millivolt Control)

2 Thermocouple/Thermopile

3 Control Knob

4 Regulator (Manual Control)
5 Control Valve (Manual Control)
6 Control Valve (Millivolt Control)
Switch, On/Off (Millivolt Control) Wire Harness (Millivolt Control)
Injector (Manual Control) 7
Injector (Millivolt Control)
Piezo Igniter

COMMENTS NG
Propane NG
Propane Manual Control Manual Control Millivolt Control
NG Propane NG & Propane
NG Propane
NG Propane
NG Propane

PART NUMBER 27D8972K 27D8971K SRV27D8974 SRV27D8973 SRV28D0400 SRV27D0602 SRV18D0603 SRV24D0305 SRV24D0306 SRV27D8951 27D8006K 27D8005K SRV32D0232 SRV32D0240 SRV32D0100 SRV32D0118 SRV32D0100 SRV32D0507 SRV14D0503

Stocked at Depot
Y Y Y Y
Y Y Y Y Y Y Y Y
Y
Y 5/23
