MAL05 150W Area Light

AREA LIGHT(MAL05)

Specifications
Construction:
° Rugged one-piece, die-cast aluminum housing secures the thermally conductive LED panel and electrical chamber
° Low profile, 3G vibration rated compact design minimizes wind load requirements. ° Housing is completely sealed against moisture and environmental contaminants.
Optics:
° Available in IES Type III, IV, V distributions ° Light engines are available in standard 4000 K and 5000 K (70 CRI) configurations. ° Scalable Lumen Packages from 13,900 to 42,000 Lumens replaces up to 1000W Metal Halide. ° Optics is precisely designed to shape the distribution, maximizing efficiency and
application spacing. ° The optics can conform to dark sky requirement.
Electrical:
° Universal 120-277 VAC or 347-480 VAC input voltage ° Standard with 1-10V dimming driver(s) ° THD: 20% ° Power Factor: 90%
Controls:
° Optional occupancy sensor ° Optional Photocell
Ambient Temperature:
° Ambient operating temperature -40° C to 40° C (-40 to 104).
Installation:
° Suitable for mounting heights ranging from 26-50′ in area lighting applications ° Round pole, Square pole, slipfitter, wall mount and yoke are available. ° The design can be operated by one person to install the whole lamp
Lifespan:
° Estimated 100,000-hour LED lifespan based on IES LM-80 results and TM-21 calculations
Finish:
° It’s available in black or optional dark bronze, silvery gray or white.

Black

Dark Bronze

Certi cations:
° UL wet location listed

Silver Gray

White

Small Size: 100W
Medium Size: 150W
Large Size: 250W/300W
Note:
Actual performance may differ as a result of end-user environment and application. All values are design or typical values, measured under laboratory conditions at 25¥(±5¥ ) specifications subject to change without notice.

Applications:
Auto dealerships, parking lots, walkways, roadways, campuses, facade lighting, grocery stores and other public areas.

PERFORMANCE DATA

SYSTEM WATTS
100W

VOLTAGE 120-277V/347-480V 120-277V/347-480V

120-277V/347-480V

150W

120-277V/347-480V 120-277V/347-480V

120-277V/347-480V

250W

120-277V/347-480V 120-277V/347-480V

120-277V/347-480V

300W

120-277V/347-480V 120-277V/347-480V

120-277V/347-480V

ELECTRICAL DATA

Number Of Drivers

Driver Current (mA)

850 1
2520

1200 1
2600

1

4300

1

5200

EPA OF AREA LIGHT

DIST.TYPE 3 4 5 3 4 5 3 4 5 3 4 5

4000K(70CRI)

LUMENS

LPW

14100lm 14000lm 14200lm 21000lm 20500lm 21000lm 35000lm 35000lm 36000lm 42000lm 41000lm 42000lm

141 lm/W 140 lm/W 142 lm/W 140 lm/W 137 lm/W 140 lm/W 140 lm/W 140 lm/W 144 lm/W 140 lm/W 137 lm/W 140 lm/W

5000K(70CRI)

LUMENS

LPW

14100lm 13900lm 14200lm 21000lm 20500lm 21000lm 35000lm 35000lm 35000lm 42000lm 41000lm 42000lm

141 lm/W 139 lm/W 142 lm/W 140 lm/W 137 lm/W 140 lm/W 140 lm/W 140 lm/W 140 lm/W 140 lm/W 137 lm/W 140 lm/W

Nominal Power (W)
100 100 100 100 100 100 150 150 150 150 150 150 250 250 250 250 250 250 300 300 300 300 300 300

INPUT VOLTAGE (V)
120 208 240 277 347 480 120 208 240 277 347 480 120 208 240 277 347 480 120 208 240 277 347 480

CURRENT (Amps)
0.83 0.48 0.42 0.36 0.29 0.21 1.25 0.72 0.63 0.54 0.43 0.31 2.08 1.20 1.04 0.90 0.72 0.52 2.50 1.44 1.25 1.08 0.86 0.63

Item
100W 150W 250W/300W

1 0.2751 0.3111 0.4097

2 @90° 0.5267 0.6343 0.7227

2 @120° 0.7321 0.6464 0.9919

2@180° 0.6164 0.6222 0.8856

3 @90° 0.9577 0.9335 1.1986

3 @120° 0.9837 0.9696 1.3049

4 @90° 0.9577 0.9335 1.1986

BUG

SYSTEM WATTS

VOLTAGE

DIST.TYPE

B

U

G

3

100W

120-277V/347-480V

4

3

150W

120-277V/347-480V

4

3

250W

120-277V/347-480V

4

3

300W

120-277V/347-480V

4

2

0

2

2

0

3

3

0

3

3

0

3

4

0

4

4

0

5

4

0

5

4

0

5

MOUNTING
° Standard versatile mounting arm accommodates multiple drilling patterns as well as square and round poles ° Optional for cast aluminum slipfitter mounting adapter
Mounting Options

Arm Mount (4″and 5″Square and Round poles)
Standard versatile mounting arm is simple to install and can be used with existing poles for retrofit installations.
Mounting Dimensions

Slipfitter Mount
An optional cast aluminum mast arm adapter secures fixture head to nominal 2-3/8”O.D. horizontal steel tenon arm.

Wall Mount
Wall Mount is easy to install for direct wall mounting with 1/2′ conduit wiring or standard J-box mounting

Yoke Mount
Die-cast aluminum trunnion is easily adapted to many surfaces and allows easy fixture aiming angles.

Round pole 5″ 0.D.

Connecting piece

Luminaire

Square pole

Luminaire

Drilling Template
1-1/4″ (32mm)
1″ (25mm) 1-1/4″ (32mm)

9/16″ DIA.HOLE 9/16″ HOLE

3-7/16″ (88mm)

PHOTOMETRICS
Type 3 optics produce an asymmetrical pattern that directs the majority of the light forward and equally on both sides of the luminaire. In a back-to-back configuration, it creates a rectangular pattern which can extend pole spacings.

Type 4 is suitable for applications where light is primarily required forward with minimal backlight. Typical installations include perimeter poles.

Type 5 optics produce a symmetrical square distribution pattern that distributes light equally on all sides of the luminaire. Type 5 luminaires is universal for most area lighting applications

Type 3

Type 4

Type 5

DIMENSION
unit: inch/mm
100W (Slipfitter Mount)
235mm [9.25in.]

100W (Wall Mount)
235mm [9.25in.]

100W (Pole Mount)
235mm [9.25in.]

100W (Yoke Mount)
235mm [9.25in.]

443mm [17.46in.] 321mm [12.63in.]

405mm [15.94in.] 321mm [12.63in.]

410mm [16.14in.] 321mm [12.63in.]

516mm [20.32in.] 321mm [12.63in.]

62.5mm [2.46in.] 203mm [8in.] 165mm [6.5in.]

85mm[3.35in.]

85mm[3.35in.]

Ø62.mm [Ø2.44in.]

Net Weight 100W:8.18 lb

Ø10.2mm [Ø0.40in.]

152mm [5.98in.] 122mm [4.80in.]

177mm [6.97in.] 203mm [7.99in.]

Net Weight 100W: 10.89 lb

62.5mm [2.46in.]

150W (Slipfitter Mount)
297mm [11.69in.]

150W (Wall Mount)
297mm [11.69in.]

62.5mm [2.46in.] 183mm [7.19in.]

90mm [3.54in.]

177mm [6.97in.] Net Weight 100W: 8.49 lb

Ø11mm [Ø0.43in.] Ø14mm [Ø0.55in.]

60mm [2.36in.] Ø22mm [Ø0.87in.]

51mm [2in.] 95mm [3.74in.]

Net Weight 100W: 8.15 lb

150W (Pole Mount)
297mm [11.69in.]

150W (Yoke Mount)
297mm [11.69in.]

481mm [18.94in.] 358mm [14.11in.]

443mm [17.43in.] 358mm [14.11in.]

448mm [17.62in.] 358mm [14.11in.]

554mm [21.8in.] 358mm [14.11in.]

58mm [2.28in.] 203mm [8in.] 165mm [6.5in.]

85mm[3.35in.] Net Weight 150W: 8.84 lb Ø62mm [Ø2.44in.]

Ø10.2mm [Ø0.40in.]

90mm [3.54in.] 152mm [5.98in.] 122mm [4.8in.]

177mm [6.97in.] 203mm [7.99in.]

Net Weight 150W: 11.56 lb

58mm [2.28in.]

250W/300W (Slipfitter Mount)
311mm [12.23in.]

250W/300W (Wall Mount)
311mm [12.23in.]

90mm [3.54in.]

177mm [6.97in.]

58mm [2.28in.] 178mm [7in.]

Net Weight 150W: 9.15 lb
250W/300W (Pole Mount)
311mm [12.23in.]

136mm [5.37in.]

60mm [2.36in.]

Ø11mm [Ø0.43in.] Ø14mm [Ø0.55in.] Ø22mm [Ø0.87in.]

51mm [2in.] 95mm [3.74in.]

Net Weight 150W: 8.82 lb

250W/300W (Yoke Mount)
311mm [12.23in.]

85mm[3.35in.]

676mm [26.6in.] 592mm [23.3in.] 714mm [28.13in.] 592mm [23.3in.]

681mm [26.8in.]

787mm [31in.] 592mm [23.3in.]

62.5mm [2.46in.] 183mm [7.22in.] 591.71mm [23.30in.] Ø10.2mm [Ø0.40in.] 165mm [6.5in.] 203mm [8in.] 85mm [3.35in.]

85mm[3.35in.]

62.5mm [2.46in.]

Ø62mm [Ø2.44in.]

Net Weight 250W: 15.98 lb 300W: 16.84 lb

62.5mm [2.46in.]

152mm [5.98in.] 122mm [4.80in.]

177mm [6.97in.] 203mm [7.99in.] Net Weight 250W: 18.69 lb 300W: 19.56 lb

90mm [3.54in.]

177mm [6.97in.]

Net Weight 250W: 16.29 lb 300W: 17.15 lb

136mm [5.37in.]

60mm [2.36in.]

Ø11mm [Ø0.43in.] Ø14mm [Ø0.55in.] Ø22mm [Ø0.87in.] 51mm [2in.] 95mm [3.74in.]

Net Weight 250W: 15.96 lb 300W: 16.82 lb

ORDERING GUIDE

Fixture Type

Wattage

Voltage

CCT

Finish

Photocell (Option)

Sensor (Option)

Example: MAL05100W 27V XXK Y Y Y Y Y Y

Mounting

Photometry

Surge Protection (Option)

MAL05 Area Light Series

100 100W

27V 120-277V 48V 347-480V

40K 4000K 50K 5000K

D Dark Bronze B Black W White SG Silver Gray

P0 120-277V Photocell M With 120-277V Sensor SQ Square Pole Mount

P3 347V Photocell

Blank Without Sensor

SP Slipfitter Mount

P4 480V Photocell

WM Wall Mount

Blank Without Photocell

YK Yoke Mount

T3 TYPE ü Photometry T4 TYPE ý Photometry T5 TYPE þ Photometry

S Surge protection (Blank) No Surge protection

Fixture Type

Wattage

Voltage

CCT

Finish

Photocell (Option)

Sensor (Option)

Example: MAL05 150W 27V XXK Y Y Y Y Y

Mounting

Photometry

MAL05 Area Light Series

150 150W 250 250W 300 300W

27V 120-277V 48V 347-480V

40K 4000K 50K 5000K

D Dark Bronze B Black W White SG Silver Gray

P0 120-277V Photocell P3 347V Photocell P4 480V Photocell Blank Without Photocell

M With 120-277V Sensor Blank Without Sensor

SQ Square Pole Mount SP Slipfitter Mount WM Wall Mount YK Yoke Mount

T3 TYPE ü Photometry T4 TYPE ý Photometry T5 TYPE þ Photometry

ADDITIONAL MOUNTING ACCESSORIES

222.5mm(8.76in.) 101.6mm(4in.)

POLE BRACKET · For mounting one xture on an existing pole

60mm(2 3/8in.) 10(42.±in1.m) m

183.6mm(7.228in.)

4″ Square Pole Mount with 2-3/8″ O.D. Tenon No. 4SQ-SP-D Finish: Dark Bronze USE: For use with square, non-tapered steel and aluminum poles. Furnished with four 5/16″ hex head stainless-steel bolts. Vertical tenon measures 2-3/8″ O.D., and is made of steel tubing. Fixtures mounted to this bracket can be adjusted both vertically and horizontally.

76mm(3in.)

60mm(2 3/8in.) 106.68mm(4.2in.)

76mm(3in.)

222.5mm(8.76in.) 101.6mm(4in.)

60mm(2 3/8in.) 12(57±in1.m) m

183.6mm(7.228in.)

5″ Square Pole Mount with 2-3/8″ O.D. Tenon No. 5SQ-SP-D Finish: Dark Bronze USE: For use with square, non-tapered steel and aluminum poles. Furnished with four 5/16″ hex head stainless-steel bolts. Vertical tenon measures 2-3/8″ O.D., and is made of steel tubing. Fixtures mounted to this bracket can be adjusted both vertically and horizontally.

60mm(2 3/8in.) 131.86mm(5.19in.)

Pole Bracket Accessories ­Angle-Adjustment Adapter NO. SQA-ALDA Finish: Dark Bronze USE: Durable brackets are engineered to provide versatile mounting options. These arms are made from rugged die-cast aluminum. They allow optimal positioning of the light fixture to maximize the lighting effectiveness vertically and horizontally.

154.5±1mm(6.08 in.) 63mm(2.48in.)

WALL BRACKET

· Attaches to any flat surface · Provides wiring access

Mid-Pole tenon Bracket

60mm(2 3/8in.)

102±1mm(4.in.)

60mm (2 3/8in.) 227.2mm(7.76 in.)

152.4mm(6in.)

90° Wall Mount Bracket with 2-3/8″ O.D. Tenon NO. WM-SP-D Finish: Dark Bronze USE: The 90° wall mount bracket with 2-3/8″ tenon attaches a floodlight to almost any surface: wall, roof, or wood pole. Provides wiring access and abuilt-in 2-3/8″ O.D. tenon to mount a fixture with our adjustable slipfitter. Suggested 3/8″ diameter bolts for mounting. Mounting holes are spaced 3-1/4″ apart.

180mm(7.086 in.)

185mm(7.28in.) 100mm(3.94 in.)

Round External Mount Horizontal Tenon · To mount 2/3/4 xtures on a existing pole

184mm(7.25in.)

101.6mm(4in.) 63.5mm(2.5in.)
101.6mm(4in.)
63.5mm(2.5in.)

60mm(2 3/8in.)

60mm(2 3/8in.)

Double 90` Horizontal Tenon Adaptor NO. R60-SP2-90-D Finish:Dark Bronze USE:The Bracket is designed to mount over 2-3/8″ (60mm) O.D. vertical tenon. Two fixtures can be mounted to the Round External Mount Horizontal Tenon and adjusted horizontally
Double 180` Horizontal Tenon Adaptor NO. R60-SP2-180-D Finish:Dark Bronze USE:The Bracket is designed to mount over 2-3/8″ (60mm) O.D. vertical tenon. Two fixtures can be mounted to the Round External Mount Horizontal Tenon and adjusted horizontally

60mm(2 3/8in.)

60mm(2 3/8in.)

101.6mm(4in.)
63.5mm(2.5in.) 101.6mm(4in.)
63.5mm(2.5in.)

184mm(7.25in.)

60mm(2 3/8in.)

184mm(7.25in.)

101.6mm(4in.) 63.5mm(2.5in.)

Triple 90′ Horizontal Tenon Adaptor NO. R60-SP3-90-D Finish:Dark Bronze USE:The Bracket is designed to mount over 2-3/8″ (60mm) O.D. vertical tenon. Three fixtures can be mounted to the Round External Mount Horizontal Tenon and adjusted horizontally

108.6mm(4.28in.) 1(042i±n.1)mm

184mm(7.25in.)

184mm(7.25in.)

4″ Round Pole Mount with 2-3/8″ O.D. Tenon NO. 4SQR-SP-D Finish:Dark Bronze USE: For use with Round, non-tapered steel and aluminum poles. Furnished with three 3/8″ hex head stainless-steel bolts. Vertical tenon measures 2-3/8″ O.D., and is made of steel tubing. Fixtures mounted to this bracket can be adjusted both vertically and horizontally.
5″ Round Pole Mount with 2-3/8″ O.D. Tenon NO. 5SQR-SP-D Finish:Dark Bronze USE: For use with Round, non-tapered steel and aluminum poles. Furnished with three 3/8″ hex head stainless-steel bolts. Vertical tenon measures 2-3/8″ O.D., and is made of steel tubing. Fixtures mounted to this bracket can be adjusted both vertically and horizontally.
Pole Bracket accessories-Tenon & Yoke Adaptor NO. SP-TR-D Finish: Dark Bronze USE: The 2-3/8″ OD Tenon Mount Adaptor for Yoke Fixtures is designed to mount light fixtures that are equipped with a yoke mount onto a 2-3/8″ OD tenon.
2-3/8″ OD Horizontal Tenon Mid-Pole Bracket NO. SQ-SP-D Finish:Dark Bronze USE:2-3/8″ OD Horizontal Tenon Mid-Pole Bracket is designed to mount light fixture that is equipped with a adjustable slipfitter onto a 2-3/8″ OD horizontal tenon
Triple 120′ Horizontal Tenon Adaptor NO. R60-SP3-120-D Finish:Dark Bronze USE:The Bracket is designed to mount over 2-3/8″ (60mm) O.D. vertical tenon. Three fixtures can be mounted to the Round External Mount Horizontal Tenon and adjusted horizontally
Quad 90′ Horizontal Tenon Adaptor NO. R60-SP4-90-D Finish:Dark Bronze USE:The Bracket is designed to mount over 2-3/8″ (60mm) O.D. vertical tenon. Four fixtures can be mounted to the Round External Mount Horizontal Tenon and adjusted horizontally
