Actiontec Api7220 11ax 2x2 Indoor Access Point User Manual

Actiontec API7220 11ax 2×2 Indoor Access Point

Overview

This document specifies the hardware features and requirements for ACTIONTEC API7220 11ax 2×2 indoor AP.

Model	Enclosure	Features
API7220 AM2		Chipset: IPQ6000; 5G radio: QCN5052 a/n/ac/ax, 2×2 , 1.2Gbps; 2.4G radio: QCN5022 b/g/n/ac/ax , 2×2, 574Mbps; 1x BLE5.0: nRF52810; 2x Integrated dual-band antennas; 1x BLE antenna; 16MB SPI NOR Flash; 128MB BGA NAND Flash; 512MB 16bit DDR3L RAM;
		** According to QCA, 256MB DDR has the
		limitation: 4 VAPs/ Radio, 64 STA/ Radio
		1x RJ45 GbE WAN, with 802.3at PoE(PD); 1x RJ45 GbE LAN; 1 x Reset button; 1 x DC Jack: [email protected]; 4x LED (5G, 2.4G, WAN, PWR); Ceiling mounting;
		Operational temperature: -10℃ ~ +45℃
		Size: 158mmx158mmx 28 mm

LED and Label

LED can be fully controlled by SW. The GbE RJ-45 is without link/active LED.

Interface Panel

WAN/PoE, LAN, DC Jack, RESET

Hardware feature

4-	Power
4-1	AP can be powered from 802.3 at PoE (PD)	Supports CAT-5e or above 100m For GE port
		Power consumption less than 18W.
		Voltage range: 50V~ 57V
		PoE has the high priority than DC, if both of them are connected.
4-2	AP can be powered from external 12V DC input	The AP support the external AC/DC adapter with following specification: 12 VDC nominal, +/- 5%, 1.5A FCC/UL/CE certificated
4-3	Power consumption	Max 11W
5-	Environment
5-1	Operating temperature	-10°C ~ +45°C
5-2	Operating humidity	5% ~ 95% non-condensing
5-3	Storage temperature	-40°C to +70°C
5-4	Elevations	86kPa～106kPa
5-5	Environment	Shall be RoHS 2011/65/EU compliant (RoHS 11 compliant, no Pb); WEEE 2002/96/EC recyclable materials requirements
5-6	Thermal	-10°C ~ +45°C
5-7	Dustproof and Waterproof	IP30
5-8	Surge	GE port with PoE support ±4KV common mode/ ±500V differential mode surge with 10-700us / 40Ohm waveform.
5-9	ESD	±4 KV (Contact Discharge) / ±8 KV (Air Discharge)
6-	Enclosure
6-1	Mechanical Enclosure / Housing
6-2	Size	158mm x 158mm x 28mm
6-3	Weight	454g
6-4	Mounting	Ceiling mounting
6-5	Material	PC+ABS(fireproof)+diecast（ bottom shell）
7-	Reliability
7-1	MTBF	300,000 Hours Telcordia SR-332, Reliability Prediction Procedures for Electronic Equipment, Issue 3, Method 1, Case 3, GB/GC (Ground Benign, Controlled) environment, 25ºC ambient temperature. Steady state, not including software failure.
7-2	Service life	> 5 years@ 35℃, full load.

Federal Communications Commission (FCC) Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generate, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and
2. this device must accept any interference received, including interference that may cause undesired operation.

FCC Caution

Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate this equipment.

RF exposure warning

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter.

ISED

CAN ICES-003 (B)/NMB-003(B)
Canadian Compliance Statement This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two conditions:

1. This device may not cause interference, and
2. This device must accept any interference, including interference that may cause undesired operation of the device.

Caution:

1. The device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems;
2. The high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.
3. DFS (Dynamic Frequency Selection) products that operate in the bands 5250-5350 MHz, 5470-5600MHz, and 5650-5725MHz.

IMPORTANT NOTE:
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.
