CBU Master Bus and Repeater

Product Information:

Product	Product Code	Input Voltage	Input Command	Output Command
CBU MASTER DALI IP	CBU-MASTER-DALI-IP	230Vac	APP CASAMBI	CONVERTER
CBU MASTER DMX IP	CBU-MASTER-DMX-IP	230Vac	APP CASAMBI	DMX CONVERTER
CBU REPEATER IP	CBU-REPEATER-IP	230Vac	APP CASAMBI	REPEATER

Product Usage Instructions:

1. Address/Channel Management:

The management of Addresses (DALI Variant) or Channels (DMX
Variant) depends on the Casambi module configuration.

2. Protection:

The product provides the following protection mechanisms:

OVP (Over voltage protection)
IFP (Input fuse protection)

3. Technical Specifications:

Nominal Voltage	Voltage Range	Mains Frequency	Nominal Power @230V	Power loss in standby mode	Storage Temperature	Ambient Temperature	Protection Grade	Mechanical Dimensions	Casing Material	Weight	I out (only for DALI)	V out (only for DALI)
230 Vac	100…240 Vac	50/60 Hz	3W max	–	–	–	–	–	–	–	For DALI variant only	For DALI variant only

View Fullscreen

CBU MASTER BUS & CBU REPEATER
Device Manual

Made in Italy
Rev.17/04/2023 Pag.1 / 15

FEATURES
· CONVERTER+CASAMBI+BUS · REPEATER CASAMBI · Input: 230Vac · Command: APP CASAMBI · Signal converter from Casambi to DALI o DMX, in MASTER Variant · Signal repeater, in REPEATER Variant · Possibility to control DALI or DMX device, by Casambi APP · Extended temperature range · 100% Functional test 5 Years warranty

PRODUCT CODE

CODE

Input Voltage

Input Command

Output Command

CBU-MASTER-DALI-IP

230Vac

APP CASAMBI

DALI (DT6 DT8)

CONVERTER

CBU-MASTER-DMX-IP

230Vac

APP CASAMBI

DMX

CONVERTER

CBU-REPEATER-IP

230Vac

APP CASAMBI

REPEATER

The management of Addresses (DALI Variant) or Channels (DMX Variant) depends on the Casambi module configuration.

PROTECTION
OVP Over voltage protection1 IFP Input fuse protection 1

CBU-MASTER-DALI/DMX

REPEATER

TECHNICAL SPECIFICATION
Nominal Voltage Voltage Range Mains Frequency Nominal Power @230V2 Power loss in standby mode Storage Temperature Ambient Temperature2 Protection grade Mechanical dimensions Casing material Weight
I out (only for DALI) V out (only for DALI)

CBU MASTER & CBU REPEATER 230 Vac
100…240 Vac 50/60 Hz 3W max <500mW
min: -40 max: +60 °C min: -25 max: +60 °C
IP66 90 x 90 x 65 mm
Plastic 88g
Only for BUS DALI 150mA 15V

1 Only control logic protection 2Maximum value, dependent on the ventilation conditions.
DALCNET S.r.l, Registered office: Via Lago di Garda, 22 36077 Altavilla Vicentina (VI) Italy Headquarters: Via Lago di Garda, 22 36077 Altavilla Vicentina (VI) Italy
VAT: IT04023100235 Tel. +39 0444 1836680 – www.dalcnet.com [email protected]

CBU MASTER BUS & CBU REPEATER
Device Manual

Made in Italy
Rev.17/04/2023 Pag.2 / 15

TECHNICAL NOTE
Installation: · Isolate the mains supply before the installation or adjusting the switches. Installation and maintenance must be performed in the absence
of AC Voltage. · Installation and maintenance must be performed only by qualified personnel in compliance with current regulations. · The product must be installed inside an electrical cabinet protected against overvoltages. · The external supply must be protected. The product must be protected from Fuse and/or Circuit Breaker with overcurrent protection
correctly dimensioned · The product must be installed only in a vertical or horizontal position with the cover / label pointing upwards or vertically; No other positions
are allowed. Button-up positive is not permitted (downward label). · The use of the product in harsh environments could limit the output power. · Keep 230V circuits (LV) and non-SELV circuits separate from safety extra low voltage (SELV) circuits and from all connections of this product.
It’s absolutely forbidden to connect for any reason, directly or indirectly, the 230V mains voltage to the bus or to other parts of the SELV circuit.
Command · The length and type of the connection cables at the BUS (DMX512, DALI or other) must comply with the specification of the respective
protocols and regulations and they should be isolated from every wiring or parts at voltage not SELV. It is suggested to use double insulated shielded and twisted cables. · All the product and the control signal connect at the bus (DMX512, DALI, or other) must be SELV (the devices connected must be SELV or supply a SELV signal)
WARNING: Do not compromise the correct functioning of the device, the product must not be in any way shielded and/or installed inside metal and aluminium boxes. As any other Casambi product, should not be placed in a metal enclosure or next to large metal structures. Metal will effectively block all radio signals which are crucial to the operation of the product.

MECHANICAL DIMENSIONS

DALCNET S.r.l, Registered office: Via Lago di Garda, 22 36077 Altavilla Vicentina (VI) Italy Headquarters: Via Lago di Garda, 22 36077 Altavilla Vicentina (VI) Italy
VAT: IT04023100235 Tel. +39 0444 1836680 – www.dalcnet.com [email protected]

CBU MASTER BUS & CBU REPEATER
Device Manual

INSTALLATION
Install the product following the below scheme

DMX BUS CONNECTION

Made in Italy
Rev.17/04/2023 Pag.3 / 15

DALI BUS CONNECTION

REPEATER CONNECTION

CBU MASTER BUS & CBU REPEATER
Device Manual
CBU-REPEATER-IP SETUP CASAMBI SIGNAL REPEATER

Made in Italy
Rev.17/04/2023 Pag.4 / 15

Characteristics:
The CBU-REPEATER-IP is a Casambi Repeater. The device receives a Casambi Bluetooth signal and repeats it.

Status Led: The status of LED is fixed on to indicate the correct power connection to the device.

Type # Profile Name of Profile

REPEATER 9948

REPEATER

TYPE OF PROFILE
Description It works as a repeater, forwarding the Casambi signal.

CBU MASTER BUS & CBU REPEATER
Device Manual
CBU-MASTER-DALI-IP SETUP CASAMBI SIGNAL CONVERSION INTO DALI PROTOCOL

Made in Italy
Rev.17/04/2023 Pag.5 / 15

CHARACTERISTICS: The CBU-MASTER-DALI-IP is a Casambi to DALI Converter. The device receives a command signal from Casambi APP and converts the signal into a DALI command. Send DT6 and DT8 command. See the following table “ADDRESS MAP DALI” for reference of Casambi-DALI conversion addresses.
STATUS LED: o When the status of the LED is steady on, the Casambi module is configuring and addressing the SLAVE DALI devices connected to the bus. o When the LED status flashes quickly, the Casambi module is sending the command set via the Casambi APP to the SLAVE DALI devices connected to the bus. o When the LED status flashes slowly, it means the DALI bus is shorted. o When the LED status is off there is no communication in the DALI bus.
AUTOMATIC DETECTION OF SHORT CIRCUITS IN THE DALI BUS: When the device detects a short circuit on the DALI bus, it automatically switches off the power of bus and the LED signal flashes slowly. At 15 seconds after the detection of the short circuit, CBU-MASTER-DALI tries to reactivate the power supply of the bus. If the short circuit has been solved, the system returns to work correctly, otherwise the bus remains unpowered and cyclically, every 15 seconds, the device tries again to reactivate the power supply of bus. NOTE: CBU-MASTER-DALI-IP do not need a DALI Bus power Supply.
At switching on, all channels are set at same value 254.
DALCNET S.r.l, Registered office: Via Lago di Garda, 22 36077 Altavilla Vicentina (VI) Italy Headquarters: Via Lago di Garda, 22 36077 Altavilla Vicentina (VI) Italy
VAT: IT04023100235 Tel. +39 0444 1836680 – www.dalcnet.com [email protected]

CBU MASTER BUS & CBU REPEATER
Device Manual
TYPE OF PROFILE

Made in Italy
Rev.17/04/2023 Pag.6 / 15

Type

# Profile

9942 (*)

13820

13818

13816
DALI 12992

12993 19060 12994 (*) Default Profile

Name of Profile

Description

DALI BROADCAST

Basic DALI broadcast dimmer. DALI Dimming Curve: Logarithmic. Set power on level at maximum level (100% – 254). No short addressing required.

W AUTOMATIC

One channel dimmer: – Dimmer 1: address A0
DALI Dimming Curve: Logarithmic. Set power on level at off (0% – 0). The short address is automatically assigned to the driver, if needed.

WW AUTOMATIC

Two channel dimmers: – Dimmer 1: address A0 – Dimmer 2: address A1
DALI Dimming Curve: Logarithmic. Set power on level at off (0% – 0). The short address is automatically assigned to the driver, if needed.

WWW AUTOMATIC

Three channel dimmers. – Dimmer 1: address A0 – Dimmer 2: address A1 – Dimmer 3: address A2
DALI Dimming Curve: Logarithmic. Set power on level at off (0% – 0). The short address is automatically assigned to the driver, if needed.

WWWW AUTOMATIC

Four channel dimmers. – Dimmer 1: address A0 – Dimmer 2: address A1 – Dimmer 3: address A2 – Dimmer 4: address A3
DALI Dimming Curve: Logarithmic. Set power on level at off (0% – 0). The short address is automatically assigned to the driver, if needed.

TW AUTOMATIC 2700-6000K

Two channel dimmers. – Dimmer 1: address A0-Warm White – Dimmer 2: address A1-Cool White
DALI Dimming Curve: Logarithmic. Set power on level at off (0% – 0). The short address is automatically assigned to the driver, if needed.

TW AUTOMATIC 2700-6000K [NEW]

Two channel dimmers. – Dimmer 1: address A0-Warm White – Dimmer 2: address A1-Cool White
DALI Dimming Curve: Quadratic. Set power on level at off (0% – 0). The short address is automatically assigned to the driver, if needed.

RGB AUTOMATIC

Three channel dimmers. – Dimmer 1: address A0-Red – Dimmer 2: address A1-Green – Dimmer 3: address A2-Blue
DALI Dimming Curve: Logarithmic. Set power on level at off (0% – 0). The short address is automatically assigned to the driver, if needed.

CBU MASTER BUS & CBU REPEATER
Device Manual

Made in Italy
Rev.17/04/2023 Pag.7 / 15

12995 12996 12998 DALI 12999 13000
15539

RGB+W AUTOMATIC
WWWW GROUP TW GROUP 2700-6000K RGB GROUP RGB+W GROUP
8xW GROUP SPECIAL

Four channel dimmers. – Dimmer 1: address A0-Red – Dimmer 2: address A1-Green – Dimmer 3: address A2-Blue – Dimmer 4: address A3-White
DALI Dimming Curve: Logarithmic. Set power on level at off (0% – 0). The short address is automatically assigned to the driver, if needed.
Four group luminaires. – Dimmer 1: group G0 – Dimmer 2: group G1 – Dimmer 3: group G2 – Dimmer 4: group G3
DALI Dimming Curve: Logarithmic. Set power on level at off (0% – 0). The short address needs to be assigned to the control gear using a DALI Master device.
Two group luminaires. – Dimmer 1: group G0-Warm White – Dimmer 2: group G1-Cool White
DALI Dimming Curve: Logarithmic. Set power on level at off (0% – 0). The short address needs to be assigned to the control gear using a DALI Master device.
Three group luminaires. – Dimmer 1: group G0-Red – Dimmer 2: group G1-Green – Dimmer 3: group G2-Blue.
DALI Dimming Curve: Logarithmic. Set power on level at off (0% – 0). The short address needs to be assigned to the control gear using a DALI Master device.
Four group luminaires. – Dimmer 1: group G0-Red – Dimmer 2: group G1-Green – Dimmer 3: group G2-Blue – Dimmer 4: group G3-White
DALI Dimming Curve: Logarithmic. Set power on level at off (0% – 0). The short address needs to be assigned to the control gear using a DALI Master device.
Eight group luminaires. – Dimmer 1: group G0 – Dimmer 2: group G1 – Dimmer 3: group G2 – Dimmer 4: group G3 – Dimmer 5: group G4 – Dimmer 6: group G5 – Dimmer 7: group G6 – Dimmer 8: group G7
DALI Dimming Curve: Logarithmic. Set Power on Level at 255 (Mask) Memory Function at Power On. Set System Failure at 255 (Mask) In case of bus loss, there isn’t change of LED output. The short address needs to be assigned to the control gear using a DALI Master device.

CBU MASTER BUS & CBU REPEATER
Device Manual

Made in Italy
Rev.17/04/2023 Pag.8 / 15

DALI 24688

8xW GROUP

Eight group luminaires. – Dimmer 1: group G0 – Dimmer 2: group G1 – Dimmer 3: group G2 – Dimmer 4: group G3 – Dimmer 5: group G4 – Dimmer 6: group G5 – Dimmer 7: group G6 – Dimmer 8: group G7
DALI Dimming Curve: Logarithmic. Set power on level at maximum level (100% – 254). The short address needs to be assigned to the control gear using a DALI Master device.

18823
21458 DALI 21459 DT8
24058
24008

DALI BC DT8 TW

1 Address to control 2-channel TW. Send DALI DT8 BROADCAST commands for device that supporting “Colour Temperature Tc”: Dim Level and Colour Temperature channels. DALI Dimming Curve: Logarithmic. Set power on level at maximum level (100% – 254). No short addressing required.

DALI DT8 RGB LINEAR

1 Address to control 3-channel RGB. Send DALI DT8 commands for device that supporting “RGBWAF colour-type”: Dim and RGBWAF channels. DALI Dimming Curve: Linear. Set power on level at maximum level (100% – 254). The short address is automatically assigned to the driver, if needed.

DALI DT8 RGBW LINEAR

1 Address to control 4-channel RGBW. Send DALI DT8 commands for device that supporting “RGBWAF colour-type”: Dim and RGBWAF channels. DALI Dimming Curve: Linear. Set power on level at maximum level (100% – 254). The short address is automatically assigned to the driver, if needed.

DALI DT8 BC RGB LINEAR

1 Address to control 3-channel RGB. Send DALI DT8 BROADCAST commands for device that supporting “RGBWAF colour-type”: Dim and RGBWAF channels. DALI Dimming Curve: Linear. Set power on level at maximum level (100% – 254). No short addressing required.

DALI DT8 BC RGB+W LINEAR

1 Address to control 4-channel RGBW. Send DALI DT8 BROADCAST commands for device that supporting “RGBWAF colour-type”: Dim and RGBWAF channels. DALI Dimming Curve: Linear. Set power on level at maximum level (100% – 254). No short addressing required.

CBU MASTER BUS & CBU REPEATER
Device Manual

ADDRESSES MAP DALI

FIXTURE AUTOMATIC The Fixture “AUTOMATIC” of the CBU-MASTER-DALI-IP addressing automatically the devices connected to the DALI BUS.

Profile Type: BROADCAST Addr Function

+ALL

Broadcast

Dimmer (Brightness Value) 0 .. 254

Made in Italy
Rev.17/04/2023 Pag.9 / 15

Profile Type: W AUTOMATIC Fixture for only 1 DALI address

Addr Function

Dimmer

Dimmer 1

Dimmer (Brightness Value) 0 .. 254

Profile Type: WW AUTOMATIC Fixture for 2 DALI address

Addr Function

Dimmer

Dimmer 1

Dimmer 2

Dimmer (Brightness Value) 0 .. 254
Dimmer (Brightness Value) 0 .. 254

Profile Type: WWW AUTOMATIC Fixture for 3 DALI address

Addr Function

Dimmer

Dimmer 1

Dimmer 2

Dimmer 3

Dimmer (Brightness Value) 0 .. 254
Dimmer (Brightness Value) 0 .. 254
Dimmer (Brightness Value) 0 .. 254

Profile Type: WWWW AUTOMATIC Fixture for 4 DALI address

Addr Function

Dimmer

Dimmer 1

Dimmer 2

Dimmer 3

Dimmer 4

Dimmer (Brightness Value) 0 .. 254
Dimmer (Brightness Value) 0 .. 254
Dimmer (Brightness Value) 0 .. 254
Dimmer (Brightness Value) 0 .. 254

Profile Type: TW AUTOMATIC 2700-6000K TW AUTOMATIC 2700-6000K NEW

Addr Function

Tunable White

Warm White

Dimmer (Brightness Value) 0 .. 254

Cool White

Dimmer (Brightness Value) 0 .. 254

CBU MASTER BUS & CBU REPEATER
Device Manual

Profile Type: RGB AUTOMATIC

Addr Function

RGBW

Red

Green

Blue

R 0 .. 254
G 0 .. 254
B 0 .. 254

Profile Type: RGB+W AUTOMATIC

Addr Function

RGBW

Red

Green

Blue

White

R 0 .. 254
G 0 .. 254
B 0 .. 254
W 0 .. 254

Made in Italy
Rev.17/04/2023 Pag.10 / 15

FIXTURE GROUP With “Group” Fixture the CBU-MASTER-DALI-IP sends group commands. The SLAVE devices to be controlled correctly by these Fixture must be previously addressed and assigned to the desired group through a Master DALI.

Profile Type: WWWW GROUP

Group Function

Dimmer

Dimmer 1

Dimmer 2

Dimmer 3

Dimmer 4

Dimmer (Brightness Value) 0 .. 254
Dimmer (Brightness Value) 0 .. 254
Dimmer (Brightness Value) 0 .. 254
Dimmer (Brightness Value) 0 .. 254

Profile Type: TW GROUP 2700-6000K

Group Function

Tunable white

Warm White

Cool White

Dimmer (Brightness Value) 0 .. 254
Dimmer (Brightness Value) 0 .. 254

Profile Type: RGB GROUP

Group Function

RGB

Red

Green

Blue

R 0 .. 254
G 0 .. 254
B 0 .. 254

CBU MASTER BUS & CBU REPEATER
Device Manual

Profile Type: RGB+W GROUP

Group Function

RGBW

Red

Green

Blue

White

R 0 .. 254
G 0 .. 254
B 0 .. 254
W 0 .. 254

Made in Italy
Rev.17/04/2023 Pag.11 / 15

Profile Type: 8xW GROUP 8xW GROUP SPECIAL

Group Function

Dimmer

Dimmer 1

Dimmer 2

Dimmer 3

Dimmer 4

Dimmer 5

Dimmer 6

Dimmer 7

Dimmer 8

Dimmer (Brightness Value) 0 .. 254
Dimmer (Brightness Value) 0 .. 254
Dimmer (Brightness Value) 0 .. 254
Dimmer (Brightness Value) 0 .. 254
Dimmer (Brightness Value) 0 .. 254
Dimmer (Brightness Value) 0 .. 254
Dimmer (Brightness Value) 0 .. 254
Dimmer (Brightness Value) 0 .. 254

The 8xW GROUP SPECIAL profile send SET POWER ON LEVEL and SET SYSTEM FAILURE LEVEL command at 255 (MASK). These commands are sent at the DALI bus when you change the profile, by Casambi APP. For Control Gear to receive these commands correctly, they must be connected to the DALI bus before changing profile.

Profile Type: DALI BROADCAST DT8 TW

Addr Function

Broadcast Colour Temperature Tc DT8

+ALL

Broadcast TW Colour Temperature Tc

Dimmer (Brightness Value) 0 .. 254

Profile Type: DALI DT8 RGB LINEAR

Addr Function

RGB DT8

RGB Colour Type

Dimmer (Brightness Value) 0 .. 254

Profile Type: DALI DT8 RGBW LINEAR

Addr Function

RGBW DT8

RGBW Colour Type

Dimmer (Brightness Value) 0 .. 254

Profile Type: DALI DT8 BC RGB LINEAR

Addr Function

Broadcast RGB DT8

+ALL

Broadcast RGB Colour Type

Dimmer (Brightness Value) 0 .. 254

Profile Type: DALI DT8 BC RGB+W LINEAR

Addr Function

Broadcast RGB+W DT8

+ALL

Broadcast RGB+W Colour Type

Dimmer (Brightness Value) 0 .. 254

CBU MASTER BUS & CBU REPEATER
Device Manual
CBU-MASTER-DMX-IP SETUP CASAMBI SIGNAL CONVERSION INTO DMX PROTOCOL

Made in Italy
Rev.17/04/2023 Pag.12 / 15

Characteristics: The CBU-MASTER-DMX-IP is a Casambi to DMX Converter. The device receives the command signal from Casambi APP and convert it into a DMX command. See the following “CHANNELS MAP DMX” table for the reference of the Casambi-DMX conversion addresses.
Status Led: Status LED is fixed on when the Casambi command is right transmitted. Status LED slowly flashes (1 flash per second), when the device is powered.

CBU MASTER BUS & CBU REPEATER
Device Manual

Type

# Profile Name of Profile 13808 W

13807 WWWW

13809 TW

13810 RGB

DMX

13811 RGB+W

13812 MRGB+S

13813 MRGBW+S

TYPE OF PROFILE
Description
One channel dimmer: – Dimmer 1: channel 1
Four channel dimmers. – Dimmer 1: channel 1 – Dimmer 2: channel 2 – Dimmer 3: channel 3 – Dimmer 4: channel 4
Two channel dimmers. – Warm White Dimmer: channel 1 – Cool White Dimmer: channel 2
Three channel dimmers. – Red Dimmer: channel 1 – Green Dimmer: channel 2 – Blue Dimmer: channel 3
Four channel dimmers. – Red Dimmer: channel 1 – Green Dimmer: channel 2 – Blue Dimmer: channel 3 – White Dimmer: channel 4
Five channel dimmers. – Master Dimmer: channel 1 – Red Dimmer: channel 2 – Green Dimmer: channel 3 – Blue Dimmer: channel 4 – Strobe Rate Channel: channel 5
Six channel dimmers. – Master Dimmer: channel 1 – Red Dimmer: channel 2 – Green Dimmer: channel 3 – Blue Dimmer: channel 4 – White Dimmer: channel 5 -Strobe Rate Channel: channel 6

Made in Italy
Rev.17/04/2023 Pag.13 / 15

CBU MASTER BUS & CBU REPEATER
Device Manual

Profile Type: W 1 DMX channel

Ch. Function

Dimmer

Dimmer 1

CHANNEL MAP DMX
Dimmer (Brightness Value) 0 .. 255

Profile Type: WWWW 4 DMX channel

Ch. Function

Dimmer

Dimmer 1

Dimmer 2
