POTTER SB-24 Switch Board
Features
- 24 programmable push buttons for speaker zone and ECS message assignment.
- Includes bracket for secure and accessible mounting
- Maximum of four (4) SB-24’s can be installed per IPA-4000V and LOC-1000
Description
The SB-24 provides 24 programmable push buttons for speaker zone and ECS message assignment. Each button has two corresponding status LEDs to indicate activity and trouble conditions. The SB-24 is equipped with a bracket for secure mounting. A maximum of four (4) SB-24’s may be installed on the IPA-4000V and LOC-1000.
Technical Specifications
| Standby Current | 4 mA |
| Alarm Current | 27 mA |
| Operating Temperature | 0°C-49°C (32°F-120°F) |
| Operating Humidity Range | 10%-93% @ 30°C (86°F) noncondensing humidity |
Installation
The SB-24 connects to the SB-8 through a 10 pin ribbon cable. The connections are power limited and supervised. The SB-24 is equipped with a bracket to securely mount to the IPA-4000V and LOC-1000 dead front.
Ordering Information
| Model | Description | Stock No. |
| SB-24 | SB-24 SWITCH BOARD W/24 PROGRAMMABLE SWITCHES | 3520652 |
Potter Electric Signal Company, LLC • St. Louis, MO • Phone: 800-325-3936 • www.pottersignal.com
8830184 – REV A
