Dynasty Stair Rod Collection
Product Information:
- Product Name: Stair Rod Collection
- Finial Options: Pineapple, Ball, Urn, Acorn
- Rod Gauge: 1 3/4″ and 1 1/2″
- Rod Diameter: .063″ and 5/8″
- Finial Length: 1 3/4″, 1 3/4″, .55″, 2.25″, 0.45″, 0.45″,
2.25″ - Installation: For decorative use only, not for installing the
carpet runner - Finial Material: Lacquer coated to resist tarnishing
- Cleaning Instructions: Wipe with a soft dry cloth, do not use
brass cleaner or abrasives
Product Usage Instructions:
- The carpet runner must be installed using another method of
installation. Zoroufy Stair Rods are for decorative use only. - Locate the desired position of the brackets by inserting the
rod into the brackets and laying it on the stairs. The most
preferable position is to position both the left and right bracket
an equal distance from the side edges of the runner. - Separate the top portion from the bottom portion of the bracket
by sliding it off laterally to expose the installation screw holes.
Install one bracket at a time to avoid mixing individual
pieces. - Install one bottom portion of a bracket onto the stairs in the
desired position using screws provided or other anchors suitable
for the stair material. It is recommended to drill a pilot hole
first. Insert the rod into the installed bottom portion of the
bracket. Slide the top portion of the bracket laterally back into
place. - Secure the top portion to the bottom portion of the bracket by
screwing the finial into the side of the assembled bracket. - Install the remaining bracket using the same method as
above. - Periodically check and tighten all screws and hardware.
FINIAL
Pineapple Ball Urn Acorn
ROD GAUGE ROD DIAMETER
Dynasty®
STAIR ROD COLLECTION SPECIFICATIONS
LENGTH
1 3/4″ 1 1/2″ 1 3/4″ 1 3/4″
.063″ 5/8″
.55” 2.25”
0.45”
0.45”
Zoroufy® Stair Rods slide into each bracket approximately ½”. Finials attach to the bracket.
2.25”
INSTALLATION INSTRUCTIONS
Finial measurements vary by style.
Finial
Installation Screws
1. The carpet runner must be installed using another method of installation. Zoroufy Stair Rods are for decorative use only.
2. Locate desired position of the brackets by inserting the rod into the brackets and laying on the stairs. Positioning both the left and right bracket an equal distance from the side edges of the runner is the most preferable position.
3. Separate the top portion from the bottom portion of the bracket by sliding it off laterally exposing the installation screw holes. (Each top and bottom portion of the brackets were manufacturered together to fit securely with each other. Open and install one bracket at a time so individual pieces do not get mixed.)
Top Portion of Bracket
Bottom Portion of Bracket
4. Install one bottom portion of a bracket onto stairs in desired position using screws provided or other anchors suitable for stair material. Drilling a pilot hole first is recommended. Insert the rod into the installed bottom portion of the bracket. Slide top portion of bracket laterally back into place.
5. Secure the top portion to the bottom portion of the bracket by screwing the finial into the side of the assembled bracket.
6. Install remaining bracket using the same method as above.
ALL PARTS ARE LACQUER COATED TO RESIST TARNISHING. DO NOT USE BRASS CLEANER OR OTHER ABRASIVES. TO CLEAN, SIMPLY WIPE WITH A SOFT DRY CLOTH. PERIODICALLY CHECK AND TIGHTEN ALL SCREWS AND HARDWARE.
2140 W. GREENVIEW DR. SUITE 5, MIDDLETON, WI 53562-0345 · 800-762-1525 · [email protected] · www.zoroufy.com
