SCE-EXR12-30T200 Rotary EXR Enclosure

Product Information:

The EXR enclosure is designed for the following purposes:

To isolate the primary power supply.
To initiate appropriate PPE (Personal Protective Equipment) for
entry.
To prevent unauthorized entry and require the primary door
latch or handle to be closed, latched, and engaged before the
disconnect is restored.
It provides protection from dirt, dust, oil, and water.

The EXR enclosure is available in two models:

SCE-EXR12-30T200: This model is compatible with Compact Fusible
Disconnect with Rotary handle Disconnect 30 to 200 amps
AllenBradley 194R, Square D GS2, Eaton/ Bussmann R9, Siemens CFS
models, and Socomec Fuserbloc models.
SCE-EXR18-400: This model is compatible with Compact Fusible
Disconnect with Rotary handle 400+ amps Allen-Bradley 194R, Square
D GS2, Eaton/Bussmann R9, Siemens CFS models, and Socomec Fuserbloc
models.

Product Usage Instructions:

For installation of the EXR to a Free Standing Enclosure
(Disconnect Enclosure), the following tools will be required:

Phillips Screwdriver
7/16, 11/32, & 3/8 WRENCH
WIRE CUTTERS
NEEDLE NOSE PLIERS
ADJUSTABLE WRENCH

To install the EXR onto the main enclosure, follow these
steps:

First, drill the mounting pattern into the right side of the
main enclosure.
Next, use the disconnect cover plate to line up the clearance
hole drilling location for the quarter turn. The disconnect cover
plate, quarter turn, and nuts will connect to the upper assembly
and hold it in place.
Apply the gasket to the left side of the EXR enclosure outside
the holes to ensure a proper seal.
Use the 128550 master bolt pack to install the EXR to the main
enclosure. Note: There is a keyway cutout on the mounting
provisions to ease installation.

With the EXR now installed onto the main enclosure, the
interlock can be installed as follows:

Attach the EXR assembly to the stud on the inside wall of the
EXR.
Install the Defeater cable and crimp it to lock into place as
shown in Detail C.
Attach the EXR mechanical defeater rod guide with keps nuts
using the PEMs from the disconnect cover plate.
Insert the quarter turn from the outside of the enclosure with
the earth nut.
Attach the EXR disconnect hook arm to the quarter turn.

View Fullscreen

Rotary exr disconnect installation

THE INTENT & PURPOSE OF THE EXR ENCLOSURE IS:

1) Isolate the primary power supply.

2) Initiate appropriate PPE for entry.

NEMA 3R, 4 & 12

3) Prevent unauthorized entry, disconnect power before entry, and requiring the primary door latch or handle to be closed, latched, and engaged before the disconnect is restored.

SCE-EXR12-30T200 Provisions for Compact Fusible Disconnect with Rotary handle Disconnect 30 to 200 amps AllenBradley 194R, Square D GS2, Eaton/ Bussmann R9, Siemens CFS models and Socomec Fuserbloc models. Provides protection from dirt, dust, oil and water.
SCE-EXR18-400 Provisions for Compact Fusible Disconnect with Rotary handle 400+ amps Allen-Bradley 194R, Square D GS2, Eaton/Bussmann R9, Siemens CFS models and Socomec Fuserbloc models. Provides protection from dirt, dust, oil and water.

! WARNING AElpepcrtoripcrailastheoPcPkEarnedqufliraeshd hazards ! ! CLOSE ANRDDCCiesillsarooLcedssoseAetnaoaTannnrneeCdddcdftfHuloalplltyolTcolwhawHtetcrhIahSiblsaleldDilfndoosOoroteorrOruofsicprbRsteetinofFoinnrIsgeRptShoiTws edroor

For installation of an EXR to a Free Standing Enclosure (Disconnect Enclosure) the following tools will be required:

Phillips Screwdriver

7/16″, 11/32″, & 3/8″ WRENCH

WIRE CUTTERS

See page 6 for modifications required for some Allen-Bradley Operating Handles

NEEDLE NOSE PLIERS

ADJUSTABLE WRENCH

Link to video
1

xr-instman.pdf

First drill the mounting pattern into the right side of the main enclosure.
Link to cutouts Next use the disconnect cover plate to line up clearance hole drilling location for quarter turn. Disconnect cover plate, quarter turn, and nuts will connect to the upper assembly and hold it in place.
Apply gasket to the left side of the EXR enclosure outside the holes to ensure a proper seal. Use 128550 master bolt pack to install EXR to the main enclosure. Note: Keyway cutout on mounting provisions to ease installation.
! WARNING
Electrical shock and flash hazards Appropriate PPE required
Read and follow all instructions Close and latch this door first Close and fully latch all doors before power is restored Disconnect power before opening this door
! CLOSE AND LATCH THIS DOOR FIRST !
Label part number 130130
2

! WARNING EAlpepcrtroipcrailastheoPcPkEarnedqufliareshdhazards

RDCCiesillasorodcesseoseatnaoannnrnddeeddcffutloalplltylocolhwawtetchrahilbslaelidlnfodosoortoerrrufosicrpbtseeitonfoninrseg

power this door

! ! CLOSE AND LATCH THIS DOOR FIRST

xr-instman.pdf

WITH THE EXR NOW INSTALLED ONTO THE MAIN ENCLOSURE, THE INTERLOCK CAN NOW BE INSTALLED

10 mm

6 mm

EXR Assembly

Defeater Hook

Upper Assembly

Lower Assembly

Mechanical interlock and defeater kit included ATTACH EXR ASSEMBLY
Attach EXR assembly to stud on inside wall of EXR.
Install Defeater cable and crimp to lock into place as shown in “Detail C”

Detail C
Unlocked

Standard Option

Locked

Allen Bradely NFPA70 Option

xr-instman.pdf

ATTACH UPPER ASSEMBLY
Using the PEMs from the disconnect cover plate. Attach the EXR mechanical defeater rod guide with keps nuts.
Insert quarter turn from outside of enclosure with earth nut.
Attach EXR disconnect hook arm to quarter turn.
Install cable and lock into place. Refer: Detail C above.
UPPER ASSEMBLY (Showing door components)

ADJUST THE MDV TO YOUR FLANGE SIZE
A- 3.50 inch flange is found on freestanding enclosures that are 3 doors and larger. Remove the 8-32 nuts, position at the outer holes.
B- 3.00 inch flange is found on most freestanding enclosures and is the preset location.
Install assembly 3 of the MDV kit with ¼-20 nut on the stud adjacent to the door handle. Slide it all the way to the flange and tighten.
Now adjust the MDV. With the disconnect operating handle still in the “off” position, simply pull the cable down so that the defeater strike is horizontal.
Then tighten the screw to lock in position.
4

lower ASSEMBLY
xr-instman.pdf

– Install Disconnect according to Disconnect Manufactures Installation Instructions. – With the EXR assembly in the “on” position verify the main enclosure door engages the hook and prevents the door from opening.
– Cut rod to length and install

xr-instman.pdf

cutout detail modifications

Standard cutout

Do not scale

Standard cutout

Allen-Bradley

Catalog Number

194R-HM4-L -HM4E-L -HM4-N2-L -HM4E-N2-L

Allen-Bradley
Catalog Number 194R-P… 140U-P…

2.958″ (75mm)
2.958″ (75mm)

Standard hole location dashed

1.469″ (37.5mm)
or
2.958″ (75mm)
