Act Connectivity Ea9911 One Click Fiber Cleaners Instruction Manual

EA9911 One Click Fiber Cleaners

Product Information

The One Click Fiber Cleaners are designed for cleaning FC/ST/SC
and LC/MU connectors. These cleaners are specifically designed to
work well with female connectors and effectively remove dust, oil,
and other debris from the ferrule end faces without causing any
damage.

The product is available in two different part numbers: EA9911
for SC, FC, and ST connectors, and EA9910 for LC and MU
connectors.

Here are some key features of the One Click Fiber Cleaners:

• Easy pushing motion engages connector and initiates
  cleaner
• Disposable with 800+ cleanings per unit
• Made from anti-static resin
• Cleaning microfibers are densely stranded and debris-free
• Extendable tip reaches recessed connectors
• Cleaning system rotates 180 degrees for a full sweep
• Audible click when engaged

The One Click Fiber Cleaners can be used in various
applications, including fiber network panels and assemblies,
outdoor FTTX applications, cable assembly production facilities,
and testing laboratories.

Specifications:

Product Usage Instructions

To use the One Click Fiber Cleaner, follow these steps:

1. Select the appropriate cleaner based on the connector type (SC,
   FC, ST, LC, or MU).
2. Ensure that the connector to be cleaned is disconnected from
   any active equipment.
3. Gently push the cleaner onto the connector, applying a slight
   pressure.
4. Rotate the cleaner in a full 180-degree motion to ensure a
   thorough cleaning.
5. You will hear an audible click when the cleaner is
   engaged.
6. After cleaning, retract the extendable tip if applicable.
7. If the cleaning performance decreases or the cleaner becomes
   visibly dirty, replace it with a new one.

Note: Each One Click Fiber Cleaner can be used for more than 800
cleanings. Dispose of the cleaner after it reaches its cleaning
limit.

One Click Fiber Cleaners For FC/ST/SC and LC/MU Connectors
Designed to specially work well with the female connectors, this instrument cleans the ferrule end faces removing Dust,oil and other debris without nicking or scratching the end face.

Part number
EA9911 (SC,FC,ST)
EA9910 (LC,MU )


Application Ferrule & Adapter 2.5mm 800+ times Ferrule & Adapter 1.25mm 800+ times

Features:
Easy pushing motion engages connector and initiates cleaner Disposable with 800+ cleanings per unit Made from anti static resin Cleaning micro fibers are densely stranded and debris free Extendable tip reaches recessed connectors Cleaning system rotates 180 for a full sweep Audible click when engaged
Applications:
Fiber network panels and assemblies Outdoor FTTX applications Cable assembly production facility Testing laboratories
Specifications:
· 800+ cleaning per unit · Cleans 2.5mm and 1.25mm ferrule connectors with PC, UPC and APC polishes · Cleans connectors loaded in a bulkhead adapter and on cable assemblies

FC/SC/ST Application MU/LC Application
