YLDDL-0083-B LED Spotlight
Product Information:
The Yeelight Spotlight is a three-point light fixture designed
to provide focused lighting in various settings. It comes with a
front and reverse view of the light body, a self-tapping screw
mounting hole, a wiring hole, a base plate, a threading hole, a
self-tapping screw, and an expansion tube.
Product Usage Instructions:
Before proceeding with the installation or maintenance of the
Yeelight Spotlight, it is recommended to seek assistance from a
qualified electrical professional to ensure safety.
To install the spotlight:
- Remove the spotlight from the package.
- Refer to the installation instructions provided with the base
and remove the base in the opposite direction. - Ensure the wiring hole and threading hole are aligned with the
desired installation location. - Securely mount the base plate using the self-tapping screw and
expansion tube. - Connect the wiring according to the electrical regulations and
guidelines. - Attach the spotlight onto the base, ensuring it is securely
fixed.
Yeeli ght spotlight User Manual lnstrukcja obstugi trzypunktowego reflektora Yeelight
Product Description
Front view of light body
Reverse view of light body
Self-tapping screw mounting hole
Wiring hole
Base plate
Threading hole
Self-tapping screw
Expansion tu be
Mounting Instructions
1. Take out the spotlight from the package, and remove the base in the opposite direction according to the installation instructions of the base.
tr:
1J
‘In order to avoid any danger, please ask an electrical professional to perform mounting or maintenance.
A · Before mounting, make sure to ill disconnect the power supply to prevent <;::!t peleercfotrrimc sehdoicnks. tMri_octuanctcinogrdshanocueldw,teh the
instructions. Improper mounting is liable to cause accidents such as fall, fire, and electric shock.
Use an impact drill 6 mm in diameter to make two mounting holes with a length of;, 25 mm in the wall (as shown in the following figure). Put the expansion tube into the mounting hole, and then thread the power cord through the wiring hole. Use self-tapping screws to fix the base on the ceiling, and verify the base is securely mounted.
· a
· a
tr: 1J
3. The wiring hole is suitable for power leads with a cross-sectional area of 1.5-2.5 mm2. Strip the power cord by 11-13 mm, and connect the neutral, live, and ground wires to the ceiling light.
11-13mm
·A solid or stranded hard wire is used as the power lead.
=
e
A · This product must
be grounded Connect the neutral, and live wires to the wiring holes marked with N, and Lin turn. (Open the internal junction box at the back of the spotlight, connect the wires and tighten the screws with an electrician’s screwdriver.)
4. Hold both sides of the lamp with both hands, align the lamp with the fixed base, then push the spotlight slightly to the left or right at the same time(depending on the orientation of the base). When you hear a “click”, the installation is complete.
5. Align the bulb with the GUl0 interface in the spotlight tube, and then rotate it clockwise to complete the installation.After completing the installation, please make sure that the spotlight base is securely installed.
· Always check for proper mounting after you have finished. Improper mounting may cause the product to fall.
Specifications
Model:YLDDL-0083, YLDDL-0083-B Lamp Holder:GUl0 Rated lnput:220-240V-S0/60Hz Rated Power:4.SWeach lampholder Maximum wattagere placement bulb: SOW
Model :YLDDL-0084, YLDDL-0084-B Lamp Holder:GUl0 Rated Input:220-240V-S0/60Hz S0mA MRaatxeimd Puomwwear:t4ta.SgWereepaclahcleammepnhtobludlebr: SOW
LMMRRaaaaomttxdeeipmddel:HIPunYoompLwluDdweteD:rar:L2:t4-t2G0a.0S0gU-W8e2lSr4Oee,0YapVLcl~haDScDl0eaL/mm6-00ep0Hnh8ztoSbl-dBuelbr: SOW
Precautions Do not replace the light source of the ceiling light by yourself. The light source should only be replaced by the manufacturer, afer-sales service, or a qualified electrician. The light installation requires a qualified electrician, and the wiring must comply with IEEE electrical standards or national standards. Make sure the voltage is consistent with the ceiling light’s operating voltage before use. Using the mismatched voltage may damage the ceiling light and cause safety hazards. The ceiling light generates heat during working. Please keep it is well ventilated for heat dissipation. The ceiling light should be installed in a stable location to prevent it from dropping down or falling off. Under normal use of condition, this equipment should be kept a separation distance of at least 20cm between the antenna and the body of the user {} For indoor use only.
E( EU Declaration of Conformity
We Qingdao Yeelink Information Technology Co., Ltd., H ereby, declares that this equipment is in compliance with the applicable Directives and European Norms, and amendments.
Ji WEEE Disposal and Recycling
All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive 2012/19/ EU) which should not be mixed with unsorted household waste. Instead, you should protect human health and the environment by handing over your waste equipment to a designated collection point for the recycling of waste electrical and electronic equipment, appointed by the government or local authorities. Correct disposal and recycling will help prevent potential negative consequences to the environment and human health. Please contact the installer or local authorities for more information about the location as well as terms and conditions of such collection points.
