HJH92S Ble Smart Home Remote Control
Product Information
The Smart Home HJH92S Ble is a remote-controlled device designed
for use in a smart home environment. It features multiple motors
for controlling the head and foot movements, as well as a built-in
bedlight. The remote control allows for easy operation and
customization of various functions.
- Head motor extend/stop
- Head motor retract/release/stop
- Lock/Unlock remote control
- Reset all motors to minimum stroke position
- Foot motor extend/stop
- Foot motor retract/release/stop
- Bedlight on/off
- Head and foot motor extend/release/stop
- Head and foot motor retract/release/stop
- Lower strength of head massager
- Turn on foot massager/increase strength
- Reduce strength of foot massager/close
- Mode switching (CONSTANT Low speed WAVE Medium speed WAVE High
speed WAVE)
Product Usage Instructions
- To extend or stop the movement of the head motor, press the
corresponding button. - To retract, release, or stop the movement of the head motor,
press the appropriate button. - To lock the remote control, press and hold the lock button for
about 5 seconds. The backlight will flash three times to indicate
the locked state. In this state, all buttons except for the
flashlight are locked. To unlock, press and hold the unlock button
for about 5 seconds. The backlight will flash three times to
indicate the unlocked state. - To reset all motors to the minimum stroke position and close
the massager, press the FLAT button. The massager will retain its
previous state before pressing the button, and this reset function
only works when the device is powered on. - To extend or stop the movement of the foot motor, press the
corresponding button. - To retract, release, or stop the movement of the foot motor,
press the appropriate button. - To turn on or off the bedlight, use the bedlight button. The
bedlight remains on continuously. - To simultaneously extend, release, or stop the movement of both
head and foot motors, press the corresponding button. - To simultaneously retract, release, or stop the movement of
both head and foot motors, press the appropriate button. - To lower the strength of the head massager, press the specific
button. There are three available strength levels. Pressing the
massager again will close it when it reaches the minimum strength
level. - If the foot massager is not turned on, press the foot massager
button to turn it on. The foot massager will default to its
previous state when it was last turned off. If the foot massager is
already turned on, press the same button to increase its
strength. - To reduce the strength of the foot massager by three levels,
press the specific button. When the strength reaches the minimum
level, pressing the massager again will close it. - To switch between different modes (CONSTANT Low speed WAVE
Medium speed WAVE High speed WAVE), use the mode switching button.
The strength setting remains unchanged after mode switching.
Precautions
To protect the reliability and safety of the motor and control
box, avoid frequently switching buttons.
Caution
This device complies with Part 15 of the FCC Rules. It must not
cause harmful interference and must accept any received
interference without undesired operation. Unauthorized changes or
modifications to the device may void the user’s authority to
operate the equipment.
Product function manual
Smart home HJH92S Ble
Remote control button map
Remote control function description
Button label
Features
Press the flashlight to light up, release the flashlight to extinguish (default 10S) Reuse function: Press and hold the key for 5s, the backlight will flash and enter the memory mode. Press ZG/SNORE/M1 within 2s, the buzzer will ring, and the current motor position, the status of the massager and the light bar can be memorized. Press and hold the flashlight+LOCK for about 11s at the same time, the backlight will flash, and all the buttons on the remote control will enter the one button release mode. You can reset all the memory positions to the factory default memory positions at the same time. At the same time, press and hold the flashlight+FLAT for about 6s, the backlight flashes, all buttons on the remote control enter the continuous pressing mode, and release the button to stop the motor.
The head motor extends and stops when it is released
Head motor retracted, released and stopped
Press the key for about 5s, the backlight flashes for 3 times, and the remote control is locked (except for the flashlight, the other keys are locked, and the backlight flashes when pressing); Press the button for about 5s, the backlight flashes 3 times, and the remote control is unlocked; FLAT one button reset, all motors retract to the minimum stroke position, close the massager, and keep the state before pressing the button (no reset when powered on)
The foot motor extends and stops when it is released
Foot motor retracted, released and stopped
Bedlight on/off (always on)
Head and foot motors extend, release and stop
Head and foot motors retract, release and stop
The motor runs to the SNORE position with one key. In the one key release mode, the motor is leveled and closed 15 minutes later. Press any key to exit the timing; The continuous pressing mode has no timing. Reuse function: long press the flashlight for about 5s, the backlight will flash, press SNORE within 2s, the buzzer will ring, and the current motor position, massager and light bar status will be recorded to SNORE. (Power off without clearing) The motor runs to the ZG position with one key. Reuse function: long press the flashlight for about 5s, the backlight will flash, press ZG within 2s, the buzzer will ring, and the current motor position, massager and light bar status will be recorded to ZG. (Power off without clearing) The motor moves to the M position with one key. Reuse function: long press the flashlight for about 5s, the backlight will flash, press M within 2s, the buzzer will ring, and the current motor position, massager and light bar status will be recorded to M. (Power off without clearing) If the head massager is not opened, press the key to open the massager. The massager defaults to the state when it was last closed. If the massager is opened, press the key to increase the strength of the head massager
Press the key to lower the strength of the head massager, 3 strengths, and press the massager again to close when the minimum strength is reached
If the foot massager is not turned on, press the key to turn on the massager. The massager defaults to the state when it was turned off last time. If the massager is turned on, press the key to increase the strength of the foot massager
Reduce the strength of the foot massager by 3. When the strength reaches the minimum, press the massager again to close
Mode switching — CONSTANT Low speed WAVE Medium speed WAVE High speed WAVE Strength remains unchanged after mode switching Coding method:
Single control box/single remote controller: press the head up and foot down buttons until the backlight flashes, and clear the code matching information of the remote controller; Power on the control box again, and the control box will be in the code matching state within 60s. Keep pressing the head down and foot up buttons of the remote control until the buzzer rings and the backlight flashes, indicating successful code matching Note: If any key is pressed for more than 50s, the remote control will go into sleep. If it is released and pressed again, the function can be resumed (if it is pressed for 3s, the backlight will flash all the time, and if it is pressed for 50s, the remote control will go into sleep)
Precautions: To protect the reliability and safety of the motor and control box, do not switch the buttons frequently.
Caution:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: –Reorient or relocate the receiving antenna. –Increase the separation between the equipment and receiver. –Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. –Consult the dealer or an experienced radio/TV technician for help.
